使用说明书 Operating Instructions 电动按摩椅 (家用) Massage Lounger (Household) 型号 EP-MA01 Model No. 简体中文 English 在使用本按摩椅之前,请仔细阅读使用说明书。 Before operating this unit, please read these instructions completely.
Page 31
Contents SAFETY PRECAUTIONS ....................E3 GROUNDING INSTRUCTIONS ..................E6 SPECIFICATIONS ......................E6 PART NAMES AND FUNCTIONS ..................E7 SETTING UP THE UNIT ....................E9 BEFORE EVERY MASSAGE (CHECK THE UNIT) ............E12 SELECTING A MENU AND STARTING THE MASSAGE ..........E14 USING “FULL BODY”...
SAFETY PRECAUTIONS These must be observed Be sure to follow these precautions to prevent injury to people or damage to property. The following precautions are classified according to the extent of possible harm or damage resulting from misuse of the product. WARNING If not observed, may result in death or serious injury. CAUTION If not observed, may result in minor injury or property damage.
Page 33
WARNING • The following persons should not use the unit. People who are prohibited from receiving massage by a physician (Example: people with thrombosis or embolism, serious aneurism, acute varicose veins, any type of dermatitis or skin infection [including hypodermic infection], etc.) Failure to observe this may worsen the symptoms.
Page 34
CAUTION • Use the unit on the flat area. Failure to observe this precaution may result in accidents or injuries due to the unit fallen down. • If the unit does not work or if an abnormality is felt, stop using it immediately, unplug the unit and request an inspection/repair. Failure to observe this may result in electric shock or fire.
GROUNDING INSTRUCTIONS The unit must be properly grounded. If it should malfunction or break down, grounding provides a path of least resistance for electric current in order to reduce the risk of electric shock. This unit is equipped with a cord with an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that has been properly installed in accordance with all local codes and ordinances.
PART NAMES AND FUNCTIONS Main unit Front Back 1 Lower Back Cover 11 Wheels 2 Armrest 12 Controller 3 Seat 13 Safety Precaution Label 4 Leg/Foot Massage Section 14 Controller Holder Calf Section Controller holder clamp screw Sole Section 15 Controller Stand 16 Power Switch Section • See page E12. Heater Section Shiatsu Projections Section •...
Page 37
Controller Display 1 “FULL BODY” Program Display • When selecting a program: mark for the currently selected program is displayed. • During the massage: The current program is displayed. 2 “SELECTED AREA” Program Display • When selecting a program: mark for the currently selected program is displayed. •...
SETTING UP THE UNIT TO START WITH (INSTALLATION LOCATION) Before taking the unit out of the box, decide where it is going to be set up. Ensure that there is enough space for the unit power switch to be operated. (Approx. 10 cm of space in both the rear and on both sides) Keep at least 3 cm away from the wall.
Page 39
2. Moving the unit and setting it up. • Since the unit is very heavy (approximately 63 kg), be careful to avoid back injuries. (The unit must be carried by two persons.) • Put the unit down slowly and carefully watch your step. • Do not drag or push the unit in an installed state. The floor may be damaged.
Page 40
3. Assembly Attach the controller holder and place the controller into the controller stand. 1 I nsert the controller holder into the controller holder until it clicks in to place. 2 F asten the controller stand with the controller holder clamp screws. 3 P lacing the controller into the controller stand. • Do not allow children to use the controller holder clamp screw. Failure to observe this may result in accidental swallowing, or accident or injury due to tampering.
BEFORE EVERY MASSAGE (CHECK THE UNIT) Check the surrounding area. Make sure there are no objects, people, or pets in the vicinity of the unit. Flip up the pillow. Make sure there is no foreign matter Backrest between the unit. • Sit on the unit after confirming there is no foreign matter Seat between the parts of the unit. (Check that there is no foreign matter stuck in the backrest, seat, leg/foot massage section or the rear of the pillow and the lower back cover.)
Page 42
Touch the massage heads with your hands Check to make sure that they are retracted. • Sit on the unit after checking that the massage heads are in the retracted position. Failure to observe this may result in accident or injury. When the massage heads are not in the retracted position • Press the button twice to return the massage heads to the retracted position. Lower Back Check that the fabric of the unit where Cover...
SELECTING A MENU AND STARTING THE MASSAGE • Be sure to start on the gentle massage program “ 舒展放松(RELAX)” when using the unit for the first time. • The unit must not be used for more than a total of 15 minutes. • Avoid massaging any one part of your body for more than 5 minutes at a time.
USING “FULL BODY” PROGRAM [Program Selection Mode] Press the button to enter the program selection mode for FULL BODY Programs. (The power will turn off automatically if no operation is performed within 3 minutes after entering the program selection mode.) Press to select a program. Select one of “缓和酸痛 (DEEP)”, “舒展放松 (RELAX)”, “活力畅快 (REFRESH)” and “8分钟速按 (QUICK (8 min.))”. A flashing arrow indicates the currently selected program. The leg/foot massage start simultaneously no matter which programs are selected. “FULL BODY” Program characteristics 缓和酸痛...
Page 45
3 The massage heads rise up and stop where they least contact the body. Massage Head 4 A double beep and the flashing of indicate that the massage heads are being finely adjusted to the shoulder position. [Shoulder Position Adjustment Mode] <How to adjust> Press to adjust the position. (Each press moves the massage heads approximately 1.5 cm.) 5 When the shoulder position is matched, press to begin the program. • The program will begin automatically in 15 seconds if the button is not pressed. Notes <Target shoulder position>...
Page 46
To Customize When turning off the the Leg/foot (Heat/Air) massage Press the button. (See page E21.) To adjust the intensity of the Leg/foot (Air) massage Press the button. (See page E21.) When turning off the sole heat function only. Press the button. (See page E21.) To change the content of the massage To select a different program from “FULL BODY” massage Press the button, and select a different program. Upper body massage will stop temporarily. (See page E15.) To change to “ ” massage SELECTED AREA Press the button and select a program.
USING “SELECTED AREA” MASSAGE [Program Selection Mode] Press the button to enter the program selection mode for SELECTED AREA. (The power will turn off automatically if no operation is performed within 3 minutes after entering the program selection mode.) Press the buttons to select a program. Select either “肩颈(NECK SHOULDER)” or “腰部(LOWER BACK)”. A flashing arrow indicates the currently selected program. The leg/foot massage start simultaneously no matter which programs are selected. Select a program and press the button. The unit will automatically recline to the correct massage position. (See page E15.) To Customize ...
USING “MANUAL” MASSAGE • Avoid massaging any one part of your body for more than 5 minutes at a time. Failure to observe this may result in an adverse effect or injury. Press the button to select preferred massage operating mode. (The power will turn off automatically if no operation is performed within 3 minutes.) Basic massage (when used with a single operation) Select the types of massage using the buttons. Select the types of massage from Neck roll, Neck knead, Knead, Tap and Back roll. <Types of massage>...
Page 49
To Customize To adjust the upper and lower positions of the massage heads Press buttons to adjust. • Each press moves the massage heads Flashing indicates the approximately 1.5 cm. approximate current position. • When you hold down the button, the operation will continue until you release it. To adjust the massage width Just operates with the “tap” and “back roll” massages. Press buttons to adjust.
USING LEG/FOOT (HEAT/AIR) MASSAGE For a person with sensitive skin, wear thick socks. 1. P ress the button to turn on the power. 2. P ress the button. The leg/foot massage begins. • The massage begins with the intensity at “2” and heat function “on”. • When the upper body massage is not being used, even if button is pressed, “Off”...
Page 51
Operations of leg/foot (heat/air) massage Calf Sole Calves will be compressed by pressing against from both Position your feet in the footrests so that the shiatsu nodules are in sides. contact with the soles of your feet. Foot will be compressed from bottom using the shiatsu projections. This operation warms up the soles and makes you feel comfortable.
END THE MASSAGE Timer function The massage will complete automatically approximately 15 minutes after the start of operations. • The leg/foot massage section will be lowered automatically • The massage heads move to the retracted position. • Backrest will not rise automatically. Backrest will rise by pressing button twice. Interrupting the massage Press the button. • The leg/foot massage section lowers automatically. The massage heads move to the retracted position. •...
Page 53
Disconnecting the power • Store the lock switch key out of the reach of children. Failure to observe this may result in accidental swallowing, or accident or injury due to tampering. • After use, be sure to slide the power switch to the “off” position and turn the lock switch to the “lock” position, and remove the key and power plug.
CLEANING AND MAINTENANCE • Unplug the power plug from the outlet when cleaning the unit and replacing the covers. Failure to observe this may result in electric shock or injury. Never use chemicals such as thinner, benzine, alcohol, etc. Synthetic Leather, Plastic Area Routine cleaning and maintenance Wipe off dust and mild dirt with a soft dry cloth. When dirty 1 Soak a soft cloth in water or a mild detergent diluted to 3 – 5 % with warm water, and wring out thoroughly.
Q&A Can I use the unit if I am going to hospital due to an illness? Consult with your physician before using the unit. Massaging uses “contact pressure stimulation” to relax the muscles by applying pressure and to improve blood circulation.
Page 56
Why doesn't the backrest return to its original position after finishing the massage? When the massage ends with the timer, in accordance with the settings, the backrest does not become upright to maintain the reclining position. To return the massage lounger to its original position, press the button on the controller twice and the chair will automatically returns to its original position.
Page 57
When transporting the unit what should I do, if it cannot pass through the door? Please try the following methods: • Before moving the unit into the room, please confirm that there is enough space nearby the doorway. When moving the unit in, please be careful not to let the unit touch the wall or the pillar nearby. •...
TROUBLESHOOTING Inspect and remedy the following items. Contact the service center if something is still wrong after attempting to remedy a problem. Problem Cause and Remedy Motor Noises 1. Operational noises in the kneading region (upper body) • The massager's kneading and tapping operational noises •...
Page 59
Sometimes the power won’t turn on when is pressed again when a massage has finished. Approximately 5 seconds are required for program termination after a massage finishes. Wait at least 5 seconds once all movement has stopped before pressing The unit has been damaged. Stop using the unit immediately. The power cord or power plug is abnormally hot. Stop using the unit immediately. Error display Error display Contents Operation is terminated because there is a problem with internal communication.
