Quick Start Guide
HDMI KVM over IP
Remote User
Console Station
Este guía esta disponible en español en la página de Tripp Lite:
Ce guide est disponible en français sur le site Web de Tripp Lite :
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
surge protector in our monthly drawing!
tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2020 Tripp Lite. All rights reserved.
Model: B064-000-STN
tripplite.com/support
tripplite.com/support
1
Advertisement
Table of Contents
Related Manuals for Tripp Lite B064-000-STN
Summary of Contents for Tripp Lite B064-000-STN
- Page 1 Console Station Model: B064-000-STN Este guía esta disponible en español en la página de Tripp Lite: tripplite.com/support Ce guide est disponible en français sur le site Web de Tripp Lite : tripplite.com/support WARRANTY REGISTRATION Register your product today and be...
-
Page 2: Product Features
• HDMI port supports HD resolutions up to 1920 x 1200 @ 60 Hz. • Included mounting plate enables wall mounting or space-saving 0U rack mounting. Package Contents • B064-000-STN Console Station • Rubber Feet (x4) • Mounting Plate • External Power Supply (100V-240V) with C13 to NEMA 5-15P Power... -
Page 3: System Requirements
System Requirements • Tripp Lite’s B064-IPG-Series KVM over IP Switch(es)* • USB Mouse/Keyboard & HDMI monitor *B064-IPG KVM over IP Switches require firmware version V1.1.102 or above to support the B064-000-STN. Introduction Front Panel: Reset Switch Cascade Port USB 2.0 Peripheral Ports... -
Page 4: Mounting Instructions
Mounting Instructions The B064-000-STN can be rack mounted or wall mounted. The following section will guide you through the proper steps. Rack Mounting The KVM over IP Console Station is designed to be mounted at the rear of a rack, where it occupies 0U to save space. -
Page 5: Wall Mounting
Mounting Instructions Wall Mounting 1. Remove two bottom screws on the unit. Use the screws to secure the mounting plate to the bottom of the unit. M3 x L5 (Countersunk Head) Figure 3: Secure Mounting Plate to Unit 2. With a user-supplied screw, use the mounting plate’s center screw hole to mount the unit to a wall. -
Page 6: Installation
Cat5e/6 Ethernet cable into the port labeled Cascade on the first stage unit, then plug the other end of the Ethernet cable into the LAN port of a second stage B064-000-STN unit. The added unit will gain the first stage unit’s internet connection but configuration and control of each unit is separate. - Page 7 Installation Figure 5: Installation...
-
Page 8: Operation
Operation Logging In The B064-000-STN is a central control station used to monitor several or all of the B064-IPG-Series KVM switches in your network. A valid user name and password are required to login (Figure 6). The default username and password are administrator and password, respectively. -
Page 9: Warranty And Product Registration
THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or... - Page 10 • Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user’s authority to operate this equipment. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without...
- Page 12 1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support 20-03-261 93-3C63_RevA...
