ViewSonic N1930W Comparison Manual

ViewSonic Commercial TVs Comparison Guide
®
VT3205LED
Entertain and message, anywhere
ViewSonic's Commercial TVs feature
connectivity and control in a ruggedized
package. Designed for 24/7 operation,
these commercial displays fit in anywhere
you need up to the minute messaging
and entertainment. LED models deliver
brilliant image clarity, high contrast with
saturated colors while consuming very low
power. Versatile connectivity is provided
through HDMI inputs in addition to PC
and traditional YPbPr component video.
For maximum control in hospitality and
commercial installations, choose from
several that feature a RS232 control port
combined with IR pass through. Internal
programming is offered for users to control
the specific operation of the TV.
.
Sales: (888)881-8781 salesinfo@ViewSonic.com
For the most current product accessories and specifications visit ViewSonic.com. Three-year limited warranty on parts, labor and LCD light source. Specifications subject to change without notice. Selection, offers and programs may vary
by country; see your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2012 ViewSonic Corporation. All rights reserved. [15996-00B-01/12]
16"
N1630w
Panel Size (in.) 15.6
Brightness - nits (typ) 250
Contrast Ratio (typ) 500:1
Dynamic Contrast Ratio (typ) 10,000:1
Video Response (ms) 8
View Angles (Horz. / Vert.) 160º / 160º
Aspect Ratio 16:09
Panel Resolution 1366 x 768
Computer Interface VGA
Optimum PC Resolution 1366 x 768 @ 60Hz
Video Interface
S-video, Composite,
Component, YPbPr/
YCbCr, HDMI, RGB,
RF (TV) x1, RCA
Audio, PC
TV Tuner NTSC / ATSC / QAM
Parental Control / Closed Caption Yes / Yes
Integrated Speakers 2 x 2.5W
VESA Wall Mount (mm) 75 x 75
®
Net Weight WITH Stand (lb.) 6.4
Net Weight WITHOUT Stand (lb.) 5.9
Physical Dimensions
14.8 x 11.8 x 4.7
WITH Stand - W x H x D (in.)
Physical Dimensions
14.8 x 10.0 x 2.6
WITHOUT Stand - W x H x D (in.)
Power Consumption - Watts (typ) 48
Black
Cabinet Color
Special Features Progressive Scan, 3D
Comb Filter, Remote,
Dolby Digital Sound,
®
HDTV built-in with
QAM TV Tuner
.
ViewSonic.com
24"
VT2430 VT2405LED
23.6 23.6
300 300
1000:1 1000:1
10,000:1 N/A
5 5
176º / 170º 176º / 160º
16:09 16:9
1920 x 1080 1920 x 1080
VGA VGA
1920 x 1080 @ 60Hz 1920 x 1080 @ 60Hz
S-video, Composite, Composite,
Component, YPbPr/ Component, 3.5mm
YCbCr, HDMI, RGB, Mini Stereo, HDMI,
RF (TV) x1 DVI, RS232
NTSC / ATSC / QAM NTSC / ATSC / QAM
Yes / Yes Yes / Yes
2 x 5W 2 x 5W
100 x 100 200 x 100
15.4 10.3
14.3 9.8
22.3 x 17.4 x 8.3 22.1 x 16.2 x 8.5
22.3 x 15.2 x 3.3 22.1 x 14.0 x 1.5
60 28
Black Black
Progressive Scan, 3D Commercial TV,
Comb Filter, Remote, LED Backlight,
Dolby Digital Sound, RS232 Control Port
®
HDTV built-in with with IR, HDMI x3,
QAM TV Tuner SRS TruSurround
Sound, Hospitality
Programming, USB
Cloning
Page 1 of 1
27" 32"
VT2730 VT3205LED
27.0 31.5
300 400
1200:1 3000:1
12,000:1 N/A
3.4 8.5
160º / 170º 176º / 176º
16:09 16:09
1920 x 1080 1366 x 768
VGA VGA
1920 x 1080 @ 60Hz 1366 x 768 @ 60Hz
S-video, Composite,
S-video, Composite,
Component, YPbPr/
Component, YPbPr/
YCbCr, HDMI, RGB,
YCbCr, HDMI, RGB,
RF (TV) x1, RCA
RF (TV) x1, RCA
Audio, PC, USB,
Audio, PC
RS232
NTSC / ATSC / QAM NTSC / ATSC / QAM
Yes / Yes Yes / Yes
2 x 5W 2 x 10W
100 x 100 200 x 100
15.4 22.8
12.2 26.8
25.4 x 18.3 x 0.9 30.5 x 22.1 x 8.2
25.4 x 16.1 x 2.9 30.5 x 19.5 x 1.6
70 90
Black Black
Progressive Scan, 3D Commercial TV,
Comb Filter, Remote, LED Backlight,
Dolby Digital Sound, RS232 Control Port
®
HDTV built-in with with IR, HDMI x3,
QAM TV Tuner SRS TruSurround
®
Sound, Hospitality
Programming, 3 year
limited warranty
2012
42"
VT4210LED
42.0
450
6000:1
N/A
5.5
176º / 176º
16:09
1920 x 1080
VGA
1920 x 1080 @ 60Hz
S-video, Composite,
Component, YPbPr/
YCbCr, HDMI, RGB,
RF (TV) x1, RCA
Audio, PC, USB
NTSC / ATSC / QAM
Yes / Yes
2 x 10W
200 x 200
29.7
25.7
39.6 x 25.8 x 8.9
39.6 x 24.0 x 1.4
80
Black
LED Backlight,
Remote, Dolby Digital
®
Sound, HDTV built-in
with QAM TV Tuner
