VT3210LED/VT4210LED
LED TV
IMPORTANT: Please read this User Guide to obtain important
information on installing and using your product in a safe manner,
as well as registering your product for future service. Warranty
information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on
our web site at http://www.viewsonic.com in English, or in specific
languages using the Regional selection box in the upper right
corner of our website.
"Antes de operar su equipo lea cuidadosamente las instrucciones
en este manual"
- User Guide
- Guide de l'utilisateur
- Guida dell'utente
Model No. : VS13772-1M
VS13776-1M
Advertisement
Table of Contents
Related Manuals for ViewSonic VS13772-1M
Summary of Contents for ViewSonic VS13772-1M
-
Page 1: User Guide
User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website. -
Page 2: Table Of Contents
Installing the LED TV ... 11 Disconnecting the stand ... 11 Installing the stand ... 11 Mounting ViewSonic LED TV to the wall ... 12 Wall Mount Kit Specifications (VESA) ... 13 Front and side View ... 14 Rear View ... 15 Connecting the LED TV ... - Page 3 Customizing the Preferences Settings ... 29 Customizing the Locks Settings ... 30 Customizing the Setup Settings ... 32 Cleaning the LED TV ... 34 Disclaimer ... 34 Troubleshooting ... 35 Specifications ... 38 Limited Warranty ... 41 Mexico Limited Warranty ... 42 ViewSonic VT3210LED/VT4210LED...
-
Page 4: Compliance Information
Keeping the TV at its factory default settings that meet ENERGY STAR criteria. Enabling certain features and functionality of LED TV will increase its energy consumption, possibly beyond the limits required for ENERGY STAR qualification. ViewSonic VT3210LED/VT4210LED... -
Page 5: Declaration Of Rohs Compliance
4. Lead as an allotting element in steel containing up to 0.35% lead by weight, aluminium containing up to 0.4% lead by weight and as a cooper alloy containing up to 4% lead by weight. ViewSonic Proposed Maximum Actual Concentration Concentration 0.1%... -
Page 6: Copyright Information
Purchase Date: Product disposal at end of product life ViewSonic respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit ViewSonic website to learn more. USA & Canada: http://www.viewsonic.com/company/green/recycleprogram/ Europe: http://www.viewsoniceurope.com/uk/support/recyclinginformation/... -
Page 7: Tv Wall Mount
TV Wall Mount To find the perfect mount for VT3210LED / VT4210LED, please browse www.viewsonic.com or call our service team: United States 1-800-688-6688, Canada 1-866-463-4775. Safety Instructions The symbol is intended to alert the user to presence of un-insulated “Hazardous Voltage”... -
Page 8: Warning
SAFETY • Operate the TV on 120V AC only. • Use the AC power cord specified by ViewSonic and suitable for the voltage where you use it. • The plug is designed, for safety purposes, to fit into the wall outlet only one way. -
Page 9: Use
• When disconnecting the power cord, grasp the plug instead of pulling the power cord. • Use only an original ViewSonic AC power cord, not other brands. • Do not use the supplied AC power cord on any other equipment. - Page 10 TV. To remove dust near the screen, wipe it gently with a soft cloth. Stubborn stains ViewSonic may be removed with a cloth slightly dampened with a solution of mild soap and warm water. Never use strong solvents such as thinner or benzine for cleaning.
- Page 11 • Do not let this TV get wet. Never spill liquid of any kind on the TV. If water penetrates into the product, unplug the power cord and contact ViewSonic. • Do not operate the TV when wet. It may result in electric shock or damage to the TV.
- Page 12 Do not throw anything at the TV. Doing so may break the screen glass and cause serious injury. If the surface of the TV cracks, unplug the AC ViewSonic power cord before touching the TV. Otherwise electric shock may result. Handling of broken glass and liquid...
-
Page 13: List Of Features
Please keep this Quick Start Guide for your future reference. Cable Programming Contact ViewSonic service team at: http://www.ViewSonic.com or call our service team: United States 1-800-688-6688, Canada 1-866-463-4775 Contact ViewSonic service team at: http://www.ViewSonic.com or call our service team: United States 1-800-688-6688, Canada 1-866-463-4775... -
Page 14: Installing The Led Tv
2. Remove the screw securing the base to the stand. 3. Remove the base. Installing the stand 1. Place the TV face down on a soft cloth or cushion on a table. 2. Attach the base to the stand with 4 screw. ViewSonic VT3210LED/VT4210LED... -
Page 15: Mounting Viewsonic Led Tv To The Wall
Install the wall mount plate to the LED TV using screws NO LONGER than 10mm, as longer screws • found in universal (non-ViewSonic) wall mount kits may damage the power supply causing the unit to fail. The wall-mount screw type is M6 x L13 or M6 x L10. -
Page 16: Wall Mount Kit Specifications (Vesa)
LED TV VT3210LED LED TV VT4210LED ViewSonic provides the standard dimensions for wall mount kits as shown in the table above. • When purchasing our wall mount kit, a detailed install manual and all parts necessary for assembly are •... -
Page 17: Front And Side View
MENU (ENTER) EXIT CHANNEL pq VOLUME + - INPUT ViewSonic Description Power LED (Green) = Power indicator Point the remote control toward this remote sensor. To access photo files. Press to turn the TV on and off. If the TV stops responding... -
Page 18: Rear View
Power Cord Item VGA IN VGA/HDMI-1 (AUDIO) IN VIDEO IN HDMI ® Digital Audio OUT ViewSonic DIGITAL AUDIO DIGITAL AUDIO Description For use when connecting a personal computer. VGA audio input terminal is shared with HDMI-1 analog audio input terminal, and its use can be configured in the Audio Setup menu. -
Page 19: Getting Started
Connect the VGA cable and audio cable from the VGA Signal Input and VGA Audio Input to the corresponding ports on your A/V device. VIDEO: VGA Signal Input [1] • AUDIO: VGA Audio Input [2] • ViewSonic DVI-to-HDMI cable DVI-to-HDMI adapter Audio cable Audio (L/R) with Mini-Pin VT3210LED/VT4210LED... -
Page 20: Connecting The Led Tv
Cable System and VHF/UHF Antenna System Use an optional A-B RF switch (not supplied) to switch between the cable and antenna programming as shown below. Cable Antenna ViewSonic Rear of TV VHF/UHF/CABLE input Rear of TV VHF/ UHF/CABLE input VT3210LED/VT4210LED... -
Page 21: Hd Cable Box/Hd Satellite Box
If the equipment has a DVI jack rather than an HDMI jack, connect the DVI jack to the HDMI jack [4] • and connect the audio jack to the AUDIO In jacks of HDMI [2]. ViewSonic HD cable box/ Rear of TV... -
Page 22: Personal Computer
THIS DAMAGE IS NOT COVERED BY YOUR WARRANTY. The DIGITAL AUDIO OUT terminal may not output some digital audio sources because of copy restrictions. • ViewSonic Rear of TV Audio cable ®... -
Page 23: Other Equipments
Getting Started Other Equipments Home Theater DVD Player/ VCD Player/ Game System *Note: For DVI connection please use DVI-to-HDMI cable/adapter. ViewSonic DIGITAL AUDIO DIGITAL AUDIO Speakers VHF/UHF Cable Digital Blu-ray Disc Satellite Receiver Player/PS3 Audio System Player Digital Cable Box... -
Page 24: Acceptable Signal Formats For Vga In And Hdmi Terminals
1280 × 1024 480i 720 × 480i 480p 720 × 480p 720p 1280 × 720p 1080i 1920 × 1080i 1080p 1920 × 1080p 1080p 1920 × 1080p ViewSonic V. Frequency H. Frequency 59.940Hz 31.469kHz 60.317Hz 37.879kHz 60.004Hz 48.363kHz 59.870Hz 47.776kHz 60.015Hz 47.712kHz V. -
Page 25: Remote Control And Tv Controls
Dispose of the battery in accordance with local laws and regulations. • Keep the batteries away from children or pets. • When the remote control will not to be used for an extended period, remove the batteries. • ViewSonic VT3210LED/VT4210LED... -
Page 26: Remote Control And Tv Controls
Using TV Features Remote Control and TV Controls CV-90283T ViewSonic Button Press to turn the power on from standby mode. POWER Press again to return to the standby mode. Use to key in the channel number. See “Changing Channel keys Channels”... -
Page 27: Operation
Note: 1 minute before switching to standby, a warning message will appear. No Signal Power Down The TV will automatically turn itself off after 15 minutes when no signal is detected. Note: 1 minute before switching to standby, a warning message will appear. ViewSonic VT3210LED/VT4210LED... -
Page 28: Using The Osd Menu
Selects the picture mode. Five modes are available: Sports, Standard, Movie, PC, and Mode Preference. Contrast Controls the difference between the brightest and darkest regions of the picture. Picture Settings Backlight Changes the backlight of the TV set. ViewSonic VT3210LED/VT4210LED... - Page 29 MEMC 120Hz Doubles the frame rate from 60 frames per second to 120 frames per second to eliminate motion blur and judder. ViewSonic Dynamic Contrast - Dynamic Contrast detects changes in picture quality that affect the appearance of your contrast settings and then automatically adjusts the video.
-
Page 30: Customizing The Audio Settings
This temporarily overrides the audio track chosen by the language option under Audio Setup. Bass Controls the relative intensity of low-pitched sounds. Treble Audio Settings Controls the relative intensity of high-pitched sounds. Balance Adjusts the relative volume of the speakers in a multiple speaker system. ViewSonic VT3210LED/VT4210LED... - Page 31 This dynamic range control feature causes Dolby Digital dynamic range to be further compressed, allowing you to switch from digital to analog broadcasts at the same dynamic range. ViewSonic available, it will be output. If not, the TV will automatically detect and output analog audio from the PC Audio input.
-
Page 32: Customizing The Preferences Settings
Chooses from three different languages (English, Français and Español) for the on- Menu Language screen display of menus and messages. ViewSonic Captions—An on-screen display of the dialogue, narration, and sound effects of TV programs and videos that are closed captioned (usually marked "CC" in program guides). -
Page 33: Customizing The Locks Settings
TV-G TV-Y7, TV-Y7FV TV-Y ViewSonic Description and Content themes Mature Audience Only (This program is specifically designed to be viewed by adults and therefore may be unsuitable for children under 17.) L) Crude or indecent language S) Explicit sexual activity V) Graphic violence Parents Strongly Cautioned (This program contains some material that many parents would find unsuitable for children under 14 years of age.) - Page 34 When the control panel lock is On, none of the controls on the TV control panel will operate except POWER. New PIN Code Changs your PIN code ViewSonic Description and Content themes X-rated (For adults only) Not intended for anyone 17 and under...
-
Page 35: Customizing The Setup Settings
Time Zone • Allows you to specify the correct time zone for your region. System Status System Information • — — ViewSonic Support Information- View the system status. Factory Defaults- Reset all settings and channels to their factory default values. VT3210LED/VT4210LED... - Page 36 Highlight this item then press ENTER to get an optimum adjustment automatically. * The default settings may vary depending on the input signal format. You can enjoy photos contents stored on a USB storage device. Media Player ViewSonic Photo Viewer specifications: • Data type: JPEG Exif ver2.1...
-
Page 37: Cleaning The Led Tv
LED TV screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the LED TV. ViewSonic will not be liable for damage resulting from use of any ammonia or alcohol- based cleaners. -
Page 38: Troubleshooting
Other Information Troubleshooting Please contact ViewSonic service team directly if you have questions, service needs, or require technical assistance related on the use of your television. Contact ViewSonic Service Team at: http://www.ViewSonic.com Or call our service team: United States 1-800-688-6688... -
Page 39: Other Information
Other Information Picture problems Sound problems Remote control problems ViewSonic Poor color or no color The station may have broadcast difficulties. Try another channel. • Check the AV Input mode when you use Video or YPbPr (page 29). • Adjust the Tint and/or Color (page 26). - Page 40 Closed caption problems Rating blocking (V-Chip) problems No HDMI-CEC operation HDMI problems Media Player problems ViewSonic The channel may have been erased from the channel memory by the • Programming channels automatically feature. Add the channel to the channel memory (page 32).
-
Page 41: Specifications
Full Scan Dimensions Physical(W) x (H) x (D) Weight Regulations Power consumption Standby ViewSonic 32” HD Active Matrix RGB Pixel Pitch: 0.17025 (H) x 0.51075 (V) mm RGB vertical stripe Anti-Glare 1366 x 768 697.6845 mm (H) x 392.256 mm (V) 27.47”... - Page 42 Warning: Do not set the graphics card in your computer to exceed these refresh rates; doing so may result in permanent damage to the LED TV. Note: Product Specifications are subject to change without notice. ViewSonic 15-Pin D-sub Analog RGB, Separate Sync. NTSC standard ATSC standard (8VSB) Digital Cable (64 QAM, 256 QAM;...
-
Page 43: Customer Support
Renta y Datos, 29 SUR 721, COL. LA PAZ, 72160 PUEBLA, PUE. Tel: 01.222.891.55.77 CON 10 LINEAS Electroser, Av Reforma No. 403Gx39 y 41, 97000 Mérida, Yucatán. Tel: 01.999.925.19.16 Other places please refer to http://www.viewsonic.com/la/soporte/index.htm#Mexico Latin America (Peru) www.viewsonic.com/la/... -
Page 44: Limited Warranty
Replacement product or parts may include remanufactured or refurbished parts or components. How long the warranty is effective: ViewSonic LED TVs are warranted for 1 year for all parts excluding the light source and 1 year for labor from the date of the first customer purchase. Who the warranty protects: This warranty is valid only for the first consumer purchaser. -
Page 45: Mexico Limited Warranty
& accessories. How long the warranty is effective: ViewSonic LED TVs are warranted for 1 year for all parts excluding the light source and 1 year for labor from the date of the first customer purchase. - Page 46 Tel: (52) 999-925-1916 E-Mail: rrrb@sureste.com Tijuana: Av Ferrocarril Sonora #3780 L-C Col 20 de Noviembre Tijuana, Mexico 4.3: ViewSonic Mexico Limited Warranty ViewSonic Villahermosa: Compumantenimietnos Garantizados, S.A. de C.V. AV. GREGORIO MENDEZ #1504 COL, FLORIDA C.P. 86040 Tel: 01 (993) 3 52 00 47 / 3522074 / 3 52 20 09 E-Mail: compumantenimientos@prodigy.net.mx...
