Craftsman 65018 Assembly Instructions Manual page 15

Shed Assembly – Walls/
14
Tip left back corner (F) back to vertical position and align
lower tabs on left side with slots in floor. Left back corner
should align and overlap previously installed side panel.
16
Continued
F
4
R
x4
15
Before proceeding, make sure
corner is square (top view) where it
meets the floor and that panel is flush
(side view) with floor.
If not, repeat Steps 12–14
until square and flush.
Top view Top view
Secure panels with four easy bolts (R), working from
floor to roof. DO NOT use torque wrench. Use easy bolt
easy driver and hand tighten. Easy bolt head will be flush
when fully seated. DO NOT over tighten easy bolts.
Note: You may hear a click when easy bolt has been
tightened completely.
15
Side view Side view
F
