Entering Pressure
Reference Values
2-26
Use the steps below to change the reference values for pressure
inputs. (Figure 3-19 on page 3-32 for a menu map.)
Do not adjust pressure reference data unless instructed
to do so by the factory.
IMPORTANT: You should record this data on the Program
Information List supplied in Appendix A of the
Startup Guide, or on a separate sheet of paper, and
keep it in a safe place.
1. At the Reference Menu (see Table 2-4 on page 2-21), press the
PROBE menu key until the Pressure Reference Table appears (see
Figure 2-13 below).
PRESSURE REFERENCE TABLE
Ch HIGH
1
2
3
4
5
6
AutoCal Interval:
Reference Menu
HELP INTERVAL
Figure 2-13: Reference Menu for Pressure
2. Compare the data on the Series 1 screen to the reference data for
the pressure input. If the data is incorrect, use the following
procedure to correct it. If the data is correct, do one of the
following:
•
continue to enter reference values for moisture and oxygen
inputs as described in Entering Moisture Reference Values on
page 2-22 and Entering the Delta F Oxygen Cell Reference
Values on page 2-24.
•
press the DONE menu key until Main Menu appears on the
message line; then see Displaying Measurements on page 2-28.
When you exit, the Series 1 automatically calibrates each
channel.
Caution!
LOW
(HH.MM): 01:00
11:15
PROBE
Basic Programming
6/2/00
DONE
