English CONTENTS GENERAL POWER TOOL SAFETY WARNINGS ........22 SYMBOL ...................... 25 SPECIFICATIONS ..................26 STANDARD ACCESSORIES ..............27 OPTIONAL ACCESSORIES (sold separately)..........28 APPLICATIONS ................... 29 PRIOR TO OPERATION ................29 INSPECTIONS PRIOR TO USE ..............30 ATTACHING PARTS ................... 30 USING DIFFERENT NOZZLES ..............
Page 23
Using accessories and attachments other than those specifi ed in the instruction manual or in Hitachi catalogs may result in accidents or injuries and must be avoided at all costs. 19. High Pressure Washer repairs to be performed only by experts.
Page 24
31. Do not hold the trigger gun when fi xing it in place. 32. If the washer is not functioning normally or is emitting strange noises or vibrations switch it off immediately and contact Hitachi authorized service centers to request inspections or repairs.
English CAUTION Purge all of the pressure within the washer before disconnecting the high-pressure hose. Attach all supplied accessories correctly in accordance with the instruction manual. Failure to observe this may result in the accessories becoming detached or in injury. Check to make sure that no foreign matter is adhering to the object being washed.
English SPECIFICATIONS Model AW130 Single-phase AC 50/60 Hz Voltage (by areas)* Voltage 220 V to 240 V Power input* 1600 W Max. discharge pressure 9.0 MPa (1MPa: 10.2 kgf/cm Max permissible pressure 13.0 MPa Max feed pressure 0.7 MPa Max water discharge 6.0 L/min...
English STANDARD ACCESSORIES In addition to the main unit (1 unit), the package contains the accessories listed in the below. Trigger gun High-pressure hose (10 m) Variable nozzle Turbo nozzle Detergent bottle nozzle One-touch joint (black) (For use with the strainer hose) Water feed connector Nozzle cleaner pin Cord holder...
English OPTIONAL ACCESSORIES (sold separately) Items shown in are sold separately. Contact Hitachi authorized service centers for replacements if the standard accessories become damaged or broken. Variable nozzle Trigger gun [Standard accessory] [Standard accessory] Turbo nozzle High-pressure [Standard accessory] extension hose (10 m)
English APPLICATIONS ○ Cleans screen doors, window glass, fl oors, walls, etc. ○ Cleans automobiles, motorbikes, etc. ○ Cleans mud off gardening equipment and agricultural equipment. PRIOR TO OPERATION Installation of an earth leakage circuit breaker It is recommended that an earth leakage circuit breaker is connected to the washer to shut off...
English Attaching the handle (Fig. 3) Handle Use a Phillips screwdriver to fi rmly tighten all four screws. Screw Screw Fig. 3 INSPECTIONS PRIOR TO USE WARNING Check the following before using the washer. Check the items listed in 1 and 2 before plugging into the power socket.
Page 31
English Attaching the high-pressure hose to the washer’s water outlet (Fig. 6) Both ends of the high-pressure hose have Water outlet cap the same confi guration, so either end may be connected. Water outlet Remove the water outlet cap from the washer, insert the high-pressure hose into Tighten the water outlet and then rotate the high-...
English USING DIFFERENT NOZZLES Spray Variable nozzle (Fig. 10) The variable nozzle can be used to alternation between “Jet” and “Spray”. Rotate the end on the nozzle clockwise for “Jet”, and counter- clockwise for “Spray”. • Jet washer A water jet is discharged in a direct line to remove stubborn Fig.
USING THE STRAINER HOSE SET (sold separately) The separately-sold strainer hose set is equipped with a function that will automatically suck water from a water tank, etc., when attached to the AW130. The maximum height of suction (lifting range) is approximately 0.5 m.
English Starting the suction hose water suction process (Fig. 15) Sink the strainer hose set into a container fi lled with water. Start off the suction process (introduce water to the suction hose.) NOTE ○ Do not use anything other than clean water Strainer Accumulated water (river or pond water, muddy water containing...
Page 35
English CAUTION ○ Set the switch to “OFF” immediately if the hose becomes detached from the faucet or washer, and if water is no longer being fed to the washer. Failure to observe this may result in immediate malfunctions (dry operations.) ○...
English Pull the trigger (Fig. 20) Hold the trigger gun fi rmly in both hands, point the nozzle at the item to be washed, and then pull the trigger. The high-pressure water jet will spray out. Adjust the nozzle between “Jet” and “Spray” in accordance with need.
English Removing the high-pressure hose (Fig. 22) Loosen the ring. Remove the high-pressure hose from the washer’s water outlet. Water outlet Drain all residual water from the high- pressure hose. Drain the water from the washer (Fig. 23) Ring High-pressure Tilt the washer to drain out the residual hose water.
Do not store in locations containing volatile substances that may ignite or explode. Replacing supply cord If the replacement of the supply cord is necessary, it has to be done by a Hitachi Authorized Service Center to avoid a safety hazard.
Repair, modifi cation and inspection of Hitachi Power Tools must be carried out by a Hitachi Authorized Service Center. This Parts List will be helpful if presented with the tool to the Hitachi Authorized Service Center when requesting repair or other maintenance.
Page 40
English Water is not being The trigger stopper is locked. Remedy the problem in accordance discharged. with the details listed in “Trigger Stopper” on page 36. The faucet it turned off . Open the faucet fully. The nozzle is blocked. Clean the end of the nozzle with the nozzle cleaner pin supplied.
English SERVICE PARTS LIST 501 502 503 504 22 23 20 21 15 16 38 39...
Page 42
ITEM ITEM PART NAME Q’TY PART NAME Q’TY PUMP ASS'Y 38 O-RING (φ8.5×1.8) 39 SEAL RING MOTOR (AW130) 40 FRONT CLAMP MOTOR COVER BACK MOTOR FILTER 41 HANDLE 42 HANDLE HOOK CARBON BRUSH 43 KNOB COVER FRONT MOTOR FILTER TAPPING SCREW D5.5×25...
