  • Page 1: High Pressure Washer

    High Pressure Washer AW 100 Do not use the appliance without reading the handling instruction. Handling instructions...
  • Page 2 & &...
  • Page 3 &...
  • Page 4 14 to 15 mm Nozzle 20 mm or less Protrusion Gun holder Spray Cord holder Washer protrusion Detergent nozzle Handle Water supply pipe Screw Bottle Power plug Center of the trigger Switch Push Water feed inlet Trigger Water feed inlet cap Trigger stopper Water feed connector Lock...
  • Page 5 Using accessories and attachments other than those 5. Store the washer in a safe place when not in use. specifi ed in the instruction manual or in Hitachi catalogs Store the washer in a dry, high location or protected with may result in accidents or injuries and must be avoided at a lock out of the reach of children.

  • Page 6: Specifications

    Failure to observe this may result in the labels peeling off . emitting strange noises or vibrations switch it off 5. Grip the handle fi rmly when carrying the washer. immediately and contact Hitachi authorized service 6. Children should be supervised to ensure that they centers to request inspections or repairs.

  • Page 7: Standard Accessories

    STANDARD ACCESSORIES (1) Trigger gun ..............1 (2) High-pressure hose (5 m) ..........1 (3) Variable nozzle ............1 (4) Detergent bottle nozzle ..........1 (5) Water feed connector ..........1 (6) Nozzle cleaner pin ............1 (7) Cord holder ..............1 (8) Gun holder ..............1 (9) Handle (with 2 attachment screws) ......1...

  • Page 8: Optional Accessories (Sold Separately)

    OPTIONAL ACCESSORIES (sold separately) Items shown in are sold separately. Contact Hitachi authorized service centers for replacements if the standard accessories become damaged or broken. Trigger gun Variable nozzle [Standard accessory] [Standard accessory] Turbo nozzle High-pressure extension hose (10 m) Extends the length of the high- pressure hose supplied.

  • Page 9: Prior To Operation

    3. Check the power socket APPLICATIONS If the power socket is loose or the plug is easily dislodged, it needs to be repaired. ○ Cleans screen doors, window glass, fl oors, walls, etc. It is dangerous to use it in this condition. Consult with ○...
  • Page 10 • Jet washer ○ Place your fi nger in the center of the trigger during A water jet is discharged in a direct line to remove operations (Fig. 13) stubborn mud and other dirt from agricultural machinery, Failure to observe this may result in injury from pinched etc.

  • Page 11: Safety Mechanisms

    6. Replacing supply cord If the replacement of the supply cord is necessary, it has SAFETY MECHANISMS to be done by a Hitachi Authorized Service Center to The washer is equipped with the following safety mechanisms avoid a safety hazard.

  • Page 12: Troubleshooting

    TROUBLESHOOTING Use the inspections in the table below if the tool does not operate normally. If this does not remedy the problem, consult your dealer or the Hitachi Authorized Service Center. Symptom Possible cause Remedy The motor won’t operate The power plug is not plugged into the power Plug the power cord into the power socket.
  • Page 13 In case of complaint, please send the Power Tool, undismantled, with the GUARANTEE CERTIFICATE found at the end of this Handling instruction, to a Hitachi Authorized Service Center. NOTE Due to HITACHI’s continuing program of research and...
  • Page 15 English GUARANTEE CERTIFICATE 1 Model No. 2 Serial No. 3 Date of Purchase 4 Customer Name and Address 5 Dealer Name and Address (Please stamp dealer name and address)
