What's in the box
Wireless Modem Router
Wireless
Quick start
USB adapter
Installation CDROM
Ethernet cable
Line cord
What else will you need
A desktop or a laptop
A web browser
with free USB port
Install your wireless
1
modem router
Insert installation CD
A
CKA7740N
1
Connect
2
Install
Enjoy
Power adapter
guide
Filter
Choose your language
B
An Internet connection
C
Insert the installation CD into the
PC's CD ROM (or DVDROM)
drive
> The installation program will start
automatically
Follow instructions on the screen
If for some reason the installation
does not start automatically:
D
Click on Windows START and
then RUN
Type explorer and navigate to the
CD ROM (or DVDROM) drive
Double-click on Setup.exe
E
By default, the language of your
operating system will be choosen,
but you have 10 seconds if you
want to select another one.
Click on the required language
> The next screen will be displayed
automatically
Select your product
DO NOT PLUG IN YOUR
CCU7740N WIRELESS USB
ADAPTER BEFORE BEING
INSTRUCTED !
Click on the picture of the
CGA7740N Wireless Modem Router
> The next screen will be displayed
automatically
Follow instructions on the screen
for the connection of your gateway
Enter Internet Service Provider settings
Select your country and Internet
Service Provider (ISP) using
the information provided by your
ISP
If your ISP is not in the default list,
please select "Other".
Click on Continue
> A progress bar screen will be displayed,
your settings will be saved and you will
be connected to Internet
> The next screen will be displayed
Connected to Internet
Once the installation completed,
the following screen will be
displayed.
Click on Menu in order to install
the wireless USB adapter
