6-16
Electrical Data
Optional Control Voltage
Tightening Torque
DC Bus
Tightening Torque
DC Bus Wiring
Description of the connections:
Connection
Control voltage
DC bus
Module bus (X1)
Mains connection (X3)
Motor connection (X5)
Motor temperature monitoring and motor holding brake (X6) 6-21
Braking resistor (X9)
Shield connection (XS1)
Control voltage is supplied by an external 24V power supply unit.
Note:
Technical data of control voltage: See page 6-10
The control voltage supply is connected via contact bars and screws (M6)
Design
at the front of the drive controller (cross section of a contact bar:
6 x 12 mm). Depending on the width of the drive controllers, there are
contact bars of different lengths.
6 Nm
By means of the DC bus connection, the following components are linked:
• the converter to other inverters
external additional capacitors are not allowed
The DC bus is connected via contact bars and screws (M6) at the front of
Design
the drive controller (cross section of a contact bar: 6 x 12 mm).
Depending on the width of the drive controllers, there are contact bars of
different lengths.
6 Nm
If in special cases it is not possible to use the DC bus rails for connection,
connection must be established using the shortest possible twisted wires.
Length of twisted wire
Wire cross section
Wire protection
Dielectric strength of single strand against
ground
Rexroth IndraDrive C HCS03.1
Page
6-16
6-16
6-17
6-18
6-19
6-24
6-25
max. 4 m
2
minimum 10 mm
(AWG 8)
but not less than supply feeder
cross section
by means of fuses in the mains
supply
> 750 V DC
(e.g.: strand type – H07)
DOK-INDRV*-HCS03.1****-PR02-EN-P
