Rexroth IndraDrive C HCS03.1
5.2
Weight
Mounting Position
Temperatures Above the Top of the Device
DOK-INDRV*-HCS03.1****-PR02-EN-P
Device
HCS03.1E-W0070
HCS03.1E-W0100
HCS03.1E-W0150
HCS03.1E-W0210
Fig. 5-10:
Weight of the devices
Note:
The control section is not contained in the weight data.
The weight of the control section is about 0.4 kg.
Drive controllers and DC bus resistor unit should be mounted in such a
way that their longitudinal axis corresponds to the natural direction of
convection (motor and power connections facing downwards).
In this way, natural convection supports the forced cooling air flow. This
avoids the generation of pockets of heat in the drive controller.
The drive controllers have a high efficiency. Outlet temperatures higher
than the ambient temperature are nevertheless produced at the top of the
devices, among other things due to the converted energies. High outlet
temperatures are particularly produced in the case of insufficient cooling
or when the cooling air current (blower failure) fails.
Risk of damage caused by too high outlet
temperatures!
⇒ When mounting and installing other components,
make sure the distance to the top of the drive
CAUTION
controllers is sufficient.
⇒ You have to take into account that higher outlet
temperatures can occur when the cooling air current
fails.
Outlet Temperatures
Designation
Symbol
temperature rise
with distance of
10 mm from top of
device
Fig. 5-11:
Outlet temperatures
Weight in kg
13
20
20
38
Unit
∆T
K
5-7
Mechanical Data
HCS03.1
30
