Philips DCP850/07B Quick Start Manual

Docking Entertainment System
DVD Portable with dock for iPod
Quick start guide
Charge your battery
1
This portable DVD player is designed with
a built-in lithium battery to supply power
to the player when you are on travel.
1 Slide the POWER switch to the OFF
position (charging of the DVD player only
possible in the power-off mode).
2 Connect the supplied power adaptor cord
(or the car adaptor) to the player and AC
mains (or the car cigarette lighter outlet)
to start charging.
➜ The CHG indicator turns green.
➜ When the battery is fully charged, the
indicator turns off.
3 Disconnect the power adaptor cord (or
the car adaptor) when the CHG indicator
turns off.
2,3
OR
1
Notes:
– You can also connect the supplied power
adaptor cord (or the car adaptor) to the player
and AC mains (or the car cigarette lighter outlet)
directly wherever possible.
– Before using the DVD player for the first time,
make sure to charge the battery for 8 hours at
least.
Prepare your remote
2
control
1 Lift up the handle marked /
EJECT to take out the
remote control.
2 Remove the protective plastic
tab (first time users only).
➜ Your remote control is
now ready for use.
3
Enjoy (iPod with video)
Connecting and
using your iPod
player
1 Pull out the iPod
connector.
2 Dock your iPod player
with the top
entering first as
shown.
3 Push in the iPod
connector.
4 Switch on your iPod player to set "TV
OUT" to "ON" and select the "PAL"
mode. (See your iPod user's manual for
detailed operation.)
3 OPEN HERE
5 Press the SOURCE key
repeatedly (or iPod on the
remote) for dock input.
6 Play files in your iPod player.
● To recharge your iPod player, you
must connect your DVD player to AC mains (or
the car cigarette lighter outlet) and ensure:
Your DVD player is in the power-off mode.
OR
The DVD player is in the power-on mode and
the current source is "iPod".
REMOVE
To remove the iPod player
1 Pull out the iPod connector.
2 Lift up the handle marked 2 / EJECT to
release.
1
2
Notes:
– This DVD player only supports 30G, 60G and
3
80G iPod player with video.
– Please take out the tab marked "for 30G iPod" in
the dock if you want to dock a 60G or 80G iPod
player.
– You need to press 2; on your iPod player in
order to start photo playback through this DVD
player.
DCP750/850
5
SOURCE
2
1
