INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
Certified to Canadian and American National Standards: CSA 2.22 and ANSI Z21.50 for Vented Decorative Gas Appliances.
FOR INDOOR USE ONLY
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI/CSA METHODS.
SAFETY INFORMATION
WARNING
!
If the information in these instructions are
not followed exactly, a fi re or explosion
may result causing property damage,
personal injury or loss of life.
- Do not store or use gasoline or other fl ammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use
any phone in your building.
•
Immediately call your gas supplier from a
neighbour's phone. Follow the gas supplier's
instructions.
•
If you cannot reach your gas supplier, call the
fi re department.
- Installation and service must be performed by a
qualifi ed installer, service agency, or the supplier.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless
a certifi ed kit is used.
Decorative Product: Not for use as a heating appliance.
Phone 1 (866) 820-8686 • www.napoleonfi replaces.com • hearth@napoleonproducts.com
$10.00
OPERATING INSTRUCTIONS
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
INSTALLATION AND
B35NTL
Natural Gas
B35PTL
HDX35
Log Burner
Assembly
DANGER
!
A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this appliance
and shall be installed for the protection of children
and other at-risk individuals.
AVERTISSEMENT
!
Propane
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
LA VITRE CHAUDE CAUSERA
DES BRÛLURES.
NE PAS TOUCHER LA VITRE
AVANT QU'ELLE AIT REFROIDI.
1.22E
W415-2193 / B / 12.01.17
NE JAMAIS LAISSER LES
ENFANTS TOUCHER LA VITRE.
EN
FR
PG
13
Advertisement
Chapters
Table of Contents
Related Manuals for Napoleon B35PTL
Summary of Contents for Napoleon B35PTL
- Page 1 AVERTISSEMENT LA VITRE CHAUDE CAUSERA Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada / DES BRÛLURES. 103 Miller Drive, Crittenden, Kentucky, USA, 41030 NE PAS TOUCHER LA VITRE Phone 1 (866) 820-8686 •...
-
Page 2: Table Of Contents
VENTURI ADJUSTMENT REPLACEMENTS B35NTL LOG BURNER ASSEMBLY (NG) B35PTL LOG BURNER ASSEMBLY (P) NOTE: Changes, other than editorial, are denoted by a line in the margin. 1.0 general information This burner and log assembly are approved for use in the HDX35 gas fireplace only. They are not approved for use as a stand alone appliance or in conjunction with any other appliance. -
Page 3: Access Panel
BULKHEADS BULKHEADS bulkheads NOTE: Bulkhead covers need to be removed. NOTE: Bulkhead covers need to be removed. NOTE: Bulkhead covers must be removed. Connect the main burner gas fl ex line Connect the main burner gas fl ex line Connect the main burner gas flex line and the pilot line to the gas fi... -
Page 4: Hearth Panel Installation
hearth panel installation NOTE: It is recommended to remove the grate assembly prior to panel installation. The hearth panel is shipped separately from the appliance and is included with the mandatory brick panel kits. Due to the brittle material of the panel, care must be taken not to bend or force the panel into place. When shipped, the hearth panel range in varying shades of Sandstone / New Port. -
Page 5: Log Placement
LOG PLACEMENT LOG PLACEMENT LOG PLACEMENT LOG PLACEMENT LOG PLACEMENT LOG PLACEMENT Before placing the log set, ensure to cover the wiring on the right side of the burner with charcoal lumps. Before placing the log set, ensure to cover the wiring on the right side of the burner with charcoal lumps. Before placing the log set, ensure to cover the wiring on the right side of the burner with charcoal lumps. - Page 6 Align the 2 holes located in the bottom Align the 2 holes located in the bottom Align the 2 holes in the bottom of the Align the 2 holes in the bottom of the Align the 2 holes located on the bottom Align the 2 holes on the bottom of of the front left crossover log with the of the front left crossover log with the...
-
Page 7: Charcoal Lumps
charcoal lumps WARNING CHARCOAL EMBERS, VERMICULITE AND CHARCOAL LUMPS ARE NOT TO BE PLACED ON THE BURNER. Place the lumps in front of the logs in a realistic manner taking care not to block any of the burner ports. 34.1 charcoal embers Randomly place the charcoal embers along the front and sides of the log support tray in a realistic manner. -
Page 8: Adjustment
3.0 adjustment flame characteristics It’s important to periodically perform a visual check of the pilot and burner fl ames. Compare them to the illustration provided. If any fl ames appear abnormal call a service person. PILOT ELECTRODE BURNER 3/8” - 1/2” (9.5mm - 12.7mm) FLAME SENSOR... -
Page 9: Replacements
4.0 replacements WARNING FAILURE TO POSITION THE PARTS IN ACCORDANCE WITH THIS MANUAL OR FAILURE TO USE ONLY PARTS SPECIFICALLY APPROVED WITH THIS APPLIANCE MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. Contact your dealer for questions concerning prices and policies on replacement parts. Normally, all parts ** THIS IS A FAST ACTING THERMOCOUPLE. - Page 10 W415-2193 / B / 12.01.17...
- Page 11 W415-2193 / B / 12.01.17...
- Page 12 NAPOLEON CELEBRATING OVER 40 YEARS OF HOME COMFORT PRODUCTS 7200, Route Transcanadienne, Montréal, Québec H4T 1A3 24 Napoleon Road, Barrie, Ontario, Canada L4M 0G8 214 Bayview Drive, Barrie, Ontario, Canada L4N 4Y8 103 Miller Drive, Crittenden, Kentucky, USA 41030 Phone: 1-866-820-8686...
- Page 13 R&D BCL’s BARRIER d’autres personnes à risque. ÉCRAN DE PROTECTION Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada / 103 Miller Drive, Crittenden, Kentucky, USA, 41030 Téléphone 1 (866) 820-8686 • www.napoleonfoyers.com • hearth@napoleonproducts.com 1.22E 10,00 $...
- Page 14 RÉGLAGE DU VENTURI RECHANGES BRÛLEUR DE BÛCHES DU B35NTL (GN) BRÛLEUR DE BÛCHES DU B35PTL (P) NOTE : Les modifications, autres qu’éditoriales, sont indiquées par une ligne verticale dans la marge. 1.0 INFORMATION GÉNÉRALE Ce brûleur et cet assemblage de bûches sont approuvés pour utilisation dans l’appareil au gaz HDX35 seulement.
- Page 15 RACCORDS RACCORDS RACCORDS NOTE: Les couvercles des raccords doivent NOTE: Les couvercles des raccords doivent être retirés. NOTE: Les couvercles des raccords doivent être retirés. Branchez les conduites de gaz flexibles et la être retirés. Branchez les conduites de gaz flexibles et la conduite de la veilleuse aux raccords de gaz Branchez les conduites de gaz flexibles et la conduite de la veilleuse aux raccords de gaz...
-
Page 16: Installation Des Panneaux De Plancher
INSTALLATION DES PANNEAUX DE PLANCHER NOTE: Nous vous suggérons de enlever l’ensemble de la grillage avant l’installation du panneau. Les panneaux de plancher sont expédiés séparément de l’appareil et ils sont inclus avec l’assemblage du brûleur et les bûches. En raison de la fragilité des panneaux, prenez grand soin de ne pas courber ou forcer les panneaux pour les mettre en place. -
Page 17: Disposition Des Bûches
LOG PLACEMENT LOG PLACEMENT LOG PLACEMENT LOG PLACEMENT LOG PLACEMENT LOG PLACEMENT Before placing the log set, ensure to cover the wiring on the right side of the burner with charcoal lumps. Before placing the log set, ensure to cover the wiring on the right side of the burner with charcoal lumps. Before placing the log set, ensure to cover the wiring on the right side of the burner with charcoal lumps. - Page 18 Alignez les 2 trous du dessous de la bûche Alignez les 2 trous du dessous de la bûche Align the 2 holes located in the bottom Align the 2 holes in the bottom of the Align the 2 holes located in the bottom Align the 2 holes in the bottom of the Align the 2 holes located in the bottom Align the 2 holes located in the bottom...
-
Page 19: Morceaux De Charbon
MORCEAUX DE CHARBON AVERTISSEMENT LES BRAISES DE CHARBON DE BOIS, LA VERMICULITE ET LES MORCEAUX DE CHARBON NE DOIVENT PAS ÊTRE PLACÉS SUR LE BRÛLEUR. Placez les morceaux de charbon devant les bûches de façon réaliste. Prenez garde de ne pas bloquer les orifi ces du brûleur. -
Page 20: Réglages
PILOT ELECTRODE BURNER 3/8” - 1/2” (9.5mm - 12.7mm) FLAME SENSOR 3.0 RÉGLAGES CARACTÉRISTIQUES DE LA FLAMME FLAME MUST ENVELOP UPPER 3/8” (9.5mm) TO 1/2” (12.7mm) OF FLAME SENSOR Il est important d’effectuer périodiquement une inspection visuelle de la fl amme de la veilleuse et du brûleur. Comparez-les à... -
Page 21: Rechanges
4.0 RECHANGES AVERTISSEMENT OMETTRE DE POSITIONNER LES PIÈCES CONFORMÉMENT À CE MANUEL OU D’UTILISER UNIQUEMENT DES PIÈCES SPÉCIFIQUEMENT APPROUVÉES POUR CET APPAREIL PEUT CAUSER DES DOMMAGES MATÉRIELS OU DES BLESSURES CORPORELLES. Contactez votre détaillant pour les questions concernant les prix et la disponibilité des pièces de ** CECI EST UN THERMOCOUPLE À... - Page 22 W415-2193 / B / 12.01.17...
- Page 23 W415-2193 / B / 12.01.17...
- Page 24 NAPOLÉON CÉLÈBRE PLUS DE 40 ANS D’EXISTENCE CONSACRÉS À LA CONCEPTION DE PRODUITS DE CONFORT 7200, Route Transcanadienne, Montréal, Québec H4T 1A3 24 Napoleon Road, Barrie, Ontario, Canada L4M 0G8 214 Bayview Drive, Barrie, Ontario, Canada L4N 4Y8 103 Miller Drive, Crittenden, Kentucky, USA 41030 Téléphone: 1-866-820-8686...
