Installation and Setup Guide
S
e
r
i
e
s
C
o
m
S
e
r
i
e
s
C
o
m
n
e
t
a
n
d
C
e
l
l
u
l
a
r
n
e
t
a
n
d
C
e
l
l
u
l
a
r
m
u
n
i
c
a
t
o
r
m
u
n
i
c
a
t
o
r
L
T
E
-
I
V
L
T
E
-
I
V
L
T
E
-
I
A
L
T
E
-
I
A
L
T
E
-
I
C
L
T
E
-
I
C
C
o
m
m
u
n
i
c
a
t
o
r
C
o
m
m
u
n
i
c
a
t
o
r

Advertisement

Table of Contents
loading

Related Manuals for Honeywell IntelliPath Series

Summary of Contents for Honeywell IntelliPath Series

  • Page 1 Installation and Setup Guide 800-24453 9/18 Rev A...

  • Page 3: Table Of Contents

    Table of Contents                                                  SECTION 1: General Information ..............................
  • Page 4 LTE-I Installation and Setup Guide SECTION 4: Registration ................................. 35 Registering the Communicator ........................35 Registering through the AlarmNet 360 Website .................. 35 Register using the Tamper Switch ....................... 36 Register using the Programming Tool ....................36 Replacing an existing communicator ....................37 Register by Phone ..........................

  • Page 5: Section 1: General Information

    Communication Path choice is set to IP & Cell, the communicator transmits signals via the cellular network to complete these transmissions. These transmissions are sent to the Honeywell NOC and then forwarded to your Central Station exactly the same way as if they were received via the Internet.

  • Page 6: System Features

    The communicator uses 256 bit AES (Rijndael) encryption (which is required for certain government installations). The AlarmNet-i AES Encryption Software Module Version 1.0 contained in the Honeywell products has NIST approval. Listings for this approval can be found at http://csrc.nist.gov/groups/STM/cavp/documents/aes/aesval.html and search for “Certificate number 979.”...

  • Page 7: Modes Of Operation

    Triggers modes are approved for ULC Commercial Burglary Installations. ECP Mode  This mode is for Honeywell control panels that support ECP communication  The communicator connects to the control panel’s keypad terminals and provides 2-way communication with the control panel using ECP messaging ...

  • Page 8: Supervision Features

    LTE-I Installation and Setup Guide Supervision Features The communicator provides the following types of supervision and fault detection:  Network communication failure: In the event the AlarmNet network does not hear a supervisory message from the communicator within a specified time, AlarmNet notifies the central station of a communication failure.

  • Page 9: Specifications

    16.5VAC, 40VA transformer, or for ULC installations 12VDC from the control panel. (Honeywell transformer # 1361-GT included with LTE-I.) (Honeywell transformer # 1361CN-GT not included with the LTE-I.) Current Drain: 90mA (rms) standby, 125mA (rms) active 6V, 3.1AH, (Honeywell # K14139 included with LTE-I only.) Backup Battery: Expected Battery Life: 5 Years (approx.)

  • Page 10: Compatibility

    For UL installations and ULC Commercial Burglary Installations, any compatible UL or ULC (respectively) Listed Control Panel may be used. Note, that any control panel that does not communicate via Honeywell's ECP data bus is compatible using zone Trigger Mode. For ULC Commercial Fire Installations, only ULC Listed Subscriber's Unit Panels which use Honeywell's ECP data bus are compatible.

  • Page 11: Section 2: Mounting And Wiring

    S E C T I O N Mounting and Wiring                                                  Determine the Signal Strength and Select a Location (Communication path is set to Cell or IP &...

  • Page 12: Mounting The Communicator

    LTE-I Installation and Setup Guide Mounting the Communicator The communicator can be mounted in two ways depending on the installation requirements. ULC NOTES: For Commercial Fire installations, the communicator must be mounted to a single or double gang box. 1. Locate the Drilling Template (provided) and align with case back. Drill at the appropriate locations for either single or double gang box.

  • Page 13: Mounting Procedure, Lte-I (With Rear Tamper Switch)

    Section 2: Mounting and Wiring Mounting Procedure, LTE-I (with rear tamper switch) For Canadian installations where the rear tamper switch is used, this procedure requires the removal of the printed circuit boards and installation of the tamper screw. 1. Remove the two mounting screws, and standoff from the daughter card, as shown in Step A below.

  • Page 14: Wiring The Communicator

    Check the Installation and Setup Guide for the control panel you are using to see if it supports ECP communication. Connect the communicator to a compatible Honeywell VISTA control panel's ECP terminals, in parallel with keypads and other peripheral devices such as RF receiver, VIP module, etc. Wire length/gauge limitations are the same for the communicator as they are for keypads and other peripheral devices.

  • Page 15: Wiring For Zone Trigger Mode

    Section 2: Mounting and Wiring Wiring for Zone Trigger Mode To trip a zone using a positive trigger, the voltage level must be: 6V or greater = positive trigger. (Levels above +14V may cause damage to the unit.) 4V or less = restore. To trip a zone using a negative trigger, the voltage level must be: 4V or less = negative trigger.

  • Page 16: Wiring The Fault Relay

    LTE-I Installation and Setup Guide AC INPUT 1 NO CONNECTION AC INPUT 2 NO CONNECTION +12 V AUX ECP (+) VOLTAGE INPUT ULC Installation (Zone mode) ZONE INPUT Z1/Z2 TRIGGER CONTROL PANEL NO CONNECTION NOTE: DO NOT CONNECT THE COMMUNICATION MODULE BACKUP BATTERY OR TRANSFORMER COMMUNICATION MODULE FOR COMMERCIAL BURGLARY INSTALLATIONS.

  • Page 17: Power Connections And Options

    Shared Transformer Installation – In this installation the supplied AC plug-in transformer may be used to power both the communicator and the control panel under the following conditions:  You must use the Honeywell 1361-GT Transformer.  This configuration ONLY applies to the VISTA-15P, VISTA-20P control panels when used with the LTE-I Communicator.
  • Page 18 "Zone Trigger Setup" COMMUNICATIONS CONTROL PANEL MODULE Shared Transformer Installation HONEYWELL 1361 OR 1361-GT TRANSFORMER TO 110 VAC UNSWITCHED 30 FT. MAX TO MODULE OUTLET 18 AWG. WIRE (MIN) NOTE: Shared Transformer Installation has not been evaluated by UL/ULC.

  • Page 19: Backup Battery Connection

    Section 2: Mounting and Wiring Backup Battery Connection The included battery (K14139) is used for backup in the event of power loss to the communicator. It does not provide power to the control panel. In ULC installations this battery is not connected, and all backup power is supplied by the control panel.
  • Page 20 LTE-I Installation and Setup Guide...

  • Page 21: Section 3: Programming The Communicator

    S E C T I O N Programming the Communicator                                                  General Information The communicator delivers alarms via the Internet to an AlarmNet central station or via the network, using cell technology when the Internet is not available.

  • Page 22: Using The Control Panel Programming Mode

    LTE-I Installation and Setup Guide 7720P PROGRAM CONNECTOR Xmit Shift 7720 PROGRAMMING TOOL BS / ESC N / Y Shift Space Enter 7720P Programmer Tool Connection Each key of the 7720P has two possible functions: a normal function and a Shift function. To perform a normal key function, simply press the desired key.

  • Page 23: Programming Conventions

    Section 3: Programming the Communicator Programming Conventions Programming is accomplished by answering a series of prompts (questions). Most prompts require only a [Y]es or [N]o response, while others require a numerical response (ID numbers, etc.). The current value is displayed on the second line in parentheses ( ). A "?" indicates an invalid entry.
  • Page 24 LTE-I Installation and Setup Guide PROMPTS OPTIONS DESCRIPTION [0-9, A-F, N, S, Re-enter the password as confirmation. Verify Password T, X, Y] If the password doesn't match the first entry, the following is displayed followed by the "Exit Prog. Mode?" prompt: Verify Not OK PSWD not created Otherwise, the "Exit Prog.
  • Page 25 Section 3: Programming the Communicator PROMPTS OPTIONS DESCRIPTION Important Information Regarding Primary and Secondary Accounts (Questions 12-18) Account information is provided by the central station administrator. If the control panel supports secondary account reporting, you will need secondary account information. The City ID, CS ID or Subscriber ID of the secondary account must differ from that of the primary account.
  • Page 26 LTE-I Installation and Setup Guide PROMPTS OPTIONS DESCRIPTION IP & Cell or Cell The AlarmNet network must hear at least one supervisory message Supervision Only: from the communicator during this supervision period; otherwise, (24 Hours)_  None AlarmNet notifies the central station that a communication failure has ...
  • Page 27 Section 3: Programming the Communicator PROMPTS OPTIONS DESCRIPTION This prompt appears only if comm. path is set to IP & Cell. Notify Panel Of_ [Neither fault] (Neither Fault) If "Both IP and Cell Fault" is selected, the device will only notify the [Both IP and Cell control panel if both communication paths fail, but will always send Faults]...
  • Page 28 LTE-I Installation and Setup Guide PROMPTS OPTIONS DESCRIPTION [Y], [N] Invert Zn6 Y/N Inverts the alarm and normal states of the zone 6 trigger; otherwise (N)_ uses normal input signal. Restore Zn6 Y/N Enables restore reporting for zone 6. [Y], [N] (Y)_ [01-15] Defines the reporting delay in seconds for zone 6.

  • Page 29: Ecp Status Codes

    Section 3: Programming the Communicator PROMPTS OPTIONS DESCRIPTION This prompt appears only if comm. path is set to IP & Cell. IP Connection  Present (Present) Press the [space] key to toggle between the options. Press [ENTER] to  Auto Detect select the configuration.

  • Page 30: Zone Trigger Mode

    LTE-I Installation and Setup Guide Zone Trigger Mode UL / ULC The LYNX controls have not been evaluated with this communicator. There are six input zones available on the communicator. Each zone is selectable for +V, -V, or EOLR trigger. The first zone input can detect both pulsed and steady signals if connected to a bell output.
  • Page 31 Cover tamper will send email event 8. All communication device system events (such as power loss, low battery, Telco, etc.) are still sent to AlarmNet. Events used to send email messages are defined on the Honeywell Total Connect web site, and must correspond to events triggering the hardwired zones.
  • Page 32 LTE-I Installation and Setup Guide PROMPTS OPTIONS DESCRIPTION This address must be programmed if using either the Remote Keypad Address [01-30] Access feature or Direct Wire downloading. Enter the appropriate (28)_ device address. NOTES: 1. This address must also be programmed as an alpha keypad in the control panel or an AUI (Advanced User Interface) type device, if a full enhanced graphic interface to the system is desired and the control panel supports it.
  • Page 33 Section 3: Programming the Communicator PROMPTS OPTIONS DESCRIPTION [00-99] This prompt appears only if comm. path includes IP. IP Flt Time (60 mins)_ In the event there is a loss of contact with the network over the Ethernet connection, enter the time delay (in minutes) before the communicator notifies the central station.
  • Page 34 LTE-I Installation and Setup Guide PROMPTS OPTIONS DESCRIPTION [Y], [N] Applies only if used with a Lynx, LynxR or Lynx Panic Y/N LynxR-EN controls where the communicator (or LRR) trigger is (N)_ connected to the communicator’s zone terminal. Reports a Panic alarm on zone 3 when the communicator detects a single pulse on zone 1.
  • Page 35 Section 3: Programming the Communicator PROMPTS OPTIONS DESCRIPTION See Important Information Regarding Zone Input Options on Telco Zone Zone Trig: [3-7] previous page. (0)_ [0] = not used Enter the zone number to be used for Telco line fault reports. This zone assignment must be unique from the open/close zone selected in Prompt 33.
  • Page 36 LTE-I Installation and Setup Guide PROMPTS OPTIONS DESCRIPTION [Y], [N] Reports alarms on zone 3 ONLY if the conditional zone (zone 7 in Rpt Zn3 ONLY if zone trigger mode) is triggered (armed). Armed (N)_ If [N], always reports alarms on zone 3. Selects the triggering method for this zone input.
  • Page 37 Section 3: Programming the Communicator PROMPTS OPTIONS DESCRIPTION Selects the triggering method for this zone input. Zn7 Trigger Type  (V+) Press the [space] key to scroll through choices. (V+)_  (V–) UL/ULC: V+ must be set as inverted and V– as ...

  • Page 38: Exiting Programming Mode

    LTE-I Installation and Setup Guide PROMPTS OPTIONS DESCRIPTION This prompt appears only if comm. path is set to IP & Cell. IP Connection  Present (Present) Press the [space] key to toggle between the options. Press [ENTER] to  Auto Detect select the configuration.

  • Page 39: Section 4: Registration

    S E C T I O N Registration                                                  Registering the Communicator Once you have programmed the communicator, it must be registered to enable the AlarmNet account.

  • Page 40: Register Using The Tamper Switch

    LTE-I Installation and Setup Guide Register using the Tamper Switch Initiate the registration sequence by clicking the Tamper Switch three times. You can monitor the registration process by viewing the Status Display. The Message (yellow) LED and the Status (green) LED will blink slowly in unison while registration is in progress. Once the registration has been completed successfully, the communicator enters normal operating mode;...

  • Page 41: Replacing An Existing Communicator

    Section 4: Registration This prompt is displayed if this is a repair/replacement, or an error was Registration BAD made in programming the Secondary account information of the ID – Need PIN communicator for an existing account. This prompt appears for 2 seconds.
  • Page 42 LTE-I Installation and Setup Guide...

  • Page 43: Section 5: Programmer Keyboard Commands

    S E C T I O N Programmer Keyboard Commands                                                  Programmer keyboard commands can be used to quickly view your connectivity settings and options.

  • Page 44: Cellular Status Displays (Appear Only If The Communication Path Includes Cell)

    LTE-I Installation and Setup Guide NOTE: The following displays except Encryption Test are displayed only if the communication path includes IP. Network Diagnostics Display Physical Link Indicates whether the device has detected a physical connection Good/Bad to the internet. Press the [Space] key to go to the next field. IP Information Display NIC IP Address Displays the IP address assigned to this device.
  • Page 45 Section 5: Programmer Keyboard Commands Signal Display for LTE RAT RSRP RSRQ RAT – Radio Access Technology. xxxx xxxx RSRP – Reference Signal Received Power RSRQ – Reference Signal Received Quality Press the [space] key to get to the next screen. Press the [backspace] key to go to the previous field.
  • Page 46 LTE-I Installation and Setup Guide Operating with 3G service (Applies to LTE-IA ONLY) Signal Display for 3G RAT RSCP EC/No RAT – Radio Access Technology. -xxx -xxxxxx RSCP –Received Signal Code Power Ec/N0 – Carrier Noise Ratio (CNR) Press the [space] key to get to the next screen. Press the [backspace] key to go to the previous field.

  • Page 47: System Status Displays

    5555555 5 ++ OK The status display includes: Zone input status (1234567) - the numbers 1-7 represent  the 7 mappings of the zone input, and follow Honeywell's ADEMCO high-speed format codes: 1 = New Event 5 = Normal X = Not Enabled Tm –...
  • Page 48 LTE-I Installation and Setup Guide Battery Charger Battery Charger Indicates the battery charger circuit status ( either OK or NOT OK). Press the [Space] key to go to the next field. Press the backspace [BS] key to go to the previous field. Line Voltage Display Line Voltage [this value is the peak voltage from the power...

  • Page 49: Section 6: Network Diagnostics

    S E C T I O N Network Diagnostics                                                  Running Network Diagnostics (available only if the communication path includes IP) The network diagnostic process tests the integrity of the links between the communicator and the...

  • Page 50: Possible Errors Running Network Diagnostics

    LTE-I Installation and Setup Guide Possible Errors Running Network Diagnostics Errors may occur either while tracing the connection to a given Redir or while testing the service at a given Redir. The following list highlights the most common errors. Please contact the AlarmNet Technical Assistance Center (TAC) for help regarding any errors NOT listed below: Possible Errors While tracing the connection to Redir x, the trace fails before ever...

  • Page 51: Appendices

    Appendices Appendices                                                  Appendix A: Summary of LED Operation LTE-I-005-V0...
  • Page 52 LTE-I Installation and Setup Guide...

  • Page 53: Appendix B: Central Station Messages

    Appendices Appendix B: Central Station Messages ECP Mode Zone Mode Alarm Condition Alarm Code Restore Code Alarm Code Restore Code Power On / Reset E339 C08xx* 5551 5555 6 Tamper E341 C08xx* R341 C08xx* 5555 5551 7 5555 5553 7 (Compromise Indication) Power Loss E337 C08xx*...
  • Page 54 LTE-I Installation and Setup Guide...

  • Page 55: Appendix C: Glossary

    (e.g., www.yahoo.com) into numerical IP addresses (e.g., 204.17.25.1.). Digital Subscriber Line. Enhanced Console Protocol, which is a proprietary bus used in Honeywell control panels to communicate with keypads and peripheral devices. It uses four wires; power, ground, data in, data out.
  • Page 57 NOTES...
  • Page 58 NOTES...
  • Page 59 NOTES...
  • Page 60 Responsible Party / Issuer of Supplier’s Partie responsable / Émetteur de la déclaration Declaration of Conformity: Honeywell de conformité du fournisseur : Honeywell International, 2 Corporate Center Drive., International, 2 Corporate Center Drive., Melville, NY 11747, Ph: 516-577-2000...
  • Page 61 CAN/ULC-S536, Standard for the Inspection and Testing of Fire Alarm Systems. SUPPORT, WARRANTY, & PATENT INFORMATION For the latest documentation and online support information, please go to: https://mywebtech.honeywellhome.com/ For the latest warranty information, please go to: www.honeywell.com/security/hsc/resources/wa. Patents MyWebTech Warranty For patent information, see www.honeywell.com/patents...
  • Page 63 Summary of Connections INTERNAL ANTENNA STATUS LED MESSAGE LED FACTORY USE ONLY FAULT LED CELLULAR STATUS LED 7720P PROGRAMMER PORT INTERNAL TB 1 ANTENNA AC 1 SIGNAL QUALITY / AC 2 MODE AND 12V DC IN STATUS LEDs ECP INPUT ECP OUTPUT BLACK MOUNTING HOLE...
  • Page 64 2 Corporate Center Drive, Suite 100 P.O. Box 9040, Melville, NY 11747 Ê800-244536Š  2018 Honeywell International Inc. www. honeywell.com/security 800-24453 9/18 Rev A...
