- Page 1 User Manual AC1200 WiFi USB Adapter USB2.0, Dual Band Model A6150 NETGEAR, Inc. January 2019 350 E. Plumeria Drive 202-11951-01 San Jose, CA 95134, USA...
- Page 2 Do not use this device outdoors. If you connect cables or devices that are outdoors to this device, see http://kb.netgear.com/000057103 for safety and warranty information. Trademarks © NETGEAR, Inc., NETGEAR, and the NETGEAR Logo are trademarks of NETGEAR, Inc. Any non-NETGEAR trademarks are used for reference purposes only.
-
Page 3: Table Of Contents
Contents Chapter 1 Install Your Adapter and Connect to a WiFi Network Package contents..................5 Status LED....................5 Use the adapter with a Windows-based computer......6 Set up your adapter with a Windows-based computer....6 Join a WiFi network using the built-in Windows tool....7 Use the adapter with a Mac..............8 Set up your adapter with a Mac............8 Join a WiFi network on a Mac............9... -
Page 4: Chapter 1 Install Your Adapter And Connect To A Wifi Network
Install Your Adapter and Connect to a WiFi Network The NETGEAR AC1200 WiFi USB Adapter Model A6150, in this manual referred to as the adapter, is a USB2.0, dual band WiFi adapter that provides a combined throughput of 1200 Mbps (300 Mbps at 2.4 GHz and , 866 Mbps at 5 GHz). The adapter supports multiuser MIMO (MU-MIMO) and beamforming and integrates and internal antenna in a nano size format. -
Page 5: Package Contents
AC1200 WiFi USB Adapter Model A6150 User Manual Package contents The package contains the adapter and the resource CD. Figure 1. Package contents Status LED The adapter contains a small status LED that lights when you insert the adapter into the USB port of your computer. -
Page 6: Use The Adapter With A Windows-Based Computer
The NETGEAR Resource CD window opens. Note: If the NETGEAR Resource CD window does not open, browse the files on the CD and double-click the autostart.exe file. 2. Click the Install Windows Driver button. -
Page 7: Join A Wifi Network Using The Built-In Windows Tool
AC1200 WiFi USB Adapter Model A6150 User Manual Join a WiFi network using the built-in Windows tool After you install the adapter (see Set up your adapter with a Windows-based computer on page 6), you can use the built-in Windows configuration tool (the Connect to a network tool) to connect the adapter to a WiFi network. -
Page 8: Use The Adapter With A Mac
The NETGEAR Resource CD window opens. Note: If the NETGEAR Resource CD window does not open, browse the files on the CD and double-click the file ending in .dmg or .pkg. The following are examples of adapter software file names: A6150_MAC_V1.0.0.1.dmg or... -
Page 9: Join A Wifi Network On A Mac
Use WPS to join a WiFi network on a Mac After you install the adapter (see Set up your adapter with a Mac on page 8), you can use the NETGEAR adapter software to connect the adapter to a WiFi network using Wi-Fi Protected Setup (WPS). -
Page 10: Use Wps With The Pbc Method To Join A Wifi Network On A Mac
The WPS pop-up window opens. 3. Click the PBC button. For 2 minutes, the NETGEAR adapter software scans for the WiFi router or access point. 4. Within 2 minutes, either press the physical WPS button on the WiFi router or access point or log in to your WiFi router or access point and click the software WPS button on the WPS configuration page of the WiFi router or access point. -
Page 11: View Information About Or Change A Wifi Network On A Mac
View information about or change a WiFi network on a Mac After you install the adapter (see Set up your adapter with a Mac on page 8), you can use the NETGEAR adapter software to view information about a WiFi network or change the security of a WiFi network. -
Page 12: Join A Hidden Wifi Network On A Mac
A hidden network is a network that does not broadcast its SSID (WiFi network name). If the network name is not displayed in the menu of the NETGEAR adapter software, the network that you are trying to join is either not functioning or is hidden. To let the Mac join a hidden network, you can use WPS (see Use WPS to join a WiFi network on a Mac on page 9) or enter the hidden network’s information manually. - Page 13 AC1200 WiFi USB Adapter Model A6150 User Manual • WPA Enterprise AES. Select an option from the 802.1x EAP menu, enter the network user name in the User Name field, and either enter the WiFi network password in the Password field or select certificate information from the CA Certificate and Client Certificate menus.
-
Page 14: Chapter 2 Troubleshooting And Frequently Asked Questions
Troubleshooting and Frequently Asked Questions This chapter describes how you can troubleshoot the adapter and network environment, and addresses frequently asked questions (FAQ). The chapter includes the following sections: • The adapter LED does not light • The adapter does not connect to a WiFi network •... -
Page 15: The Adapter Led Does Not Light
AC1200 WiFi USB Adapter Model A6150 User Manual The adapter LED does not light If the LED does not light when you insert the adapter into a USB port on your computer, try these troubleshooting tips: • Remove and reinsert the adapter. -
Page 16: When I Connect The Adapter To A Wifi Network, I Cannot Access A Shared Resource
AC1200 WiFi USB Adapter Model A6150 User Manual When I connect the adapter to a WiFi network, I cannot access a shared resource If you cannot access a shared resource such as a printer, try these troubleshooting tips: • Make sure that the WiFi router or access point is physically connected to the LAN Ethernet network. -
Page 17: How Do I View The Speed Of The Wifi Connection On A Windows-Based Computer
AC1200 WiFi USB Adapter Model A6150 User Manual How do I view the speed of the WiFi connection on a Windows-based computer? While your computer is connected to a WiFi network using the adapter, you can view the speed of the WiFi connection. -
Page 18: Where Can I Find More Information About The Built-In Windows Tool
Where can I find more information about the built-in Windows tool? Other than driver software, the adapter does not come with NETGEAR adapter software for Windows. That is, it does not come with an adapter-specific graphical user interface for Windows. Instead, the adapter uses software that is already built into your Windows-based computer. -
Page 19: Appendix A Factory Default Settings And Technical Specifications
Factory Default Settings and Technical Specifications This appendix includes the following sections: • Factory default settings • Technical specifications Note: For more information, see the data sheet that you can download by visiting netgear.com/support/download/. -
Page 20: Factory Default Settings
AC1200 WiFi USB Adapter Model A6150 User Manual Factory default settings The following table lists the default settings of your adapter. Table 2. Factory default settings Feature Default Setting WiFi Enabled (non-configurable) communication Country or region United States, but varies by country or region of purchase Operating mode 802.11ac, 802.11a, 802.11n, 802.11g, or 802.11b... - Page 21 AC1200 WiFi USB Adapter Model A6150 User Manual Table 3. Technical specifications (Continued) Feature Description Encryption WPA2-PSK [AES] WPA-PSK [TKIP] 64-bit/128-bit WEP data encryption Power 5V bus powered Bus interface USB 2.0, compatible with USB 1.1 Provided drivers Microsoft Windows 10 Microsoft Windows 8.1...
