Summary of Server Features

8 Internal USB 3.0 port on motherboard
9 RTC battery, vertical socket
Summary of Server Features
The following table lists a summary of server features.
Feature
Chassis
Central Processor
Memory
Multi-bit error protection
Baseboard management
Network and management I/O
Modular LOM
Cisco Secure Network Server 3600 Series Appliance Hardware Installation Guide
12
Cisco Secure Network Server 3600 Series Appliance Overview
17 Micro-SD card socket on PCIe riser 1
-
Description
One rack-unit (1RU) chassis
• Intel Xeon 2.1 GHz 4110
• Intel Xeon 2.1 GHz 4116
24 DDR4 DIMM sockets on the motherboard (12 each CPU)
Multi-bit error protection is supported
Board management controller (BMC), running Cisco Integrated
Management Controller (Cisco IMC) firmware.
Depending on your Cisco IMC settings, Cisco IMC can be
accessed through the 1-Gb dedicated management port, the
1-Gb/10-Gb Ethernet LAN ports, or a Cisco virtual interface card.
Rear panel:
• One 1-Gb Ethernet dedicated management port (RJ-45
connector)
• Two 1-Gb/10-Gb BASE-T Ethernet LAN ports (RJ-45
connectors)
The dual LAN ports can support 1 Gbps or 10 Gbps
depending on the link partner capability.
• One RS-232 serial port (RJ-45 connector)
• One Video Graphics Array (VGA) connector port (DB-15
connector)
• Two USB 3.0 ports
Front panel:
• One front-panel keyboard/video/mouse (KVM) connector
that is used with the KVM cable, which provides two USB
2.0, one VGA, and one DB-9 serial connector.
One dedicated socket (x16 PCIe lane) that can be used to add an
mLOM card for additional rear-panel connectivity.
