- Page 1 Transceiver KX-TR320B/320F/320S Model No. KX-TR325B/325S Operating Instructions PLEASE READ BEFORE USE AND SAVE. Contents by Section 1 Getting Started 2 Before You Talk 3 To Communicate 4 Call Tones 5 Channel Scan 6 Special Features 7 Using the Options 8 Things You Should Know –1–...
-
Page 2: Getting Started
¤ Getting Started 1-A Location of Controls 1-B Display MIC (Microphone)/SP (Speaker) Jack (7-A, 7-C) The flip is open (3-C). The unit is in the vibratory call Sub Speaker (3-C) mode (KX-TR325 only) (4-B). Display (1-B) The scrambling function is ON Antenna (1-E) (LOCK) Button (6-B) (KX-TR325 only) (6-A). - Page 3 ¤ Getting Started 1-C Battery Installation 1-D Belt Clip The unit requires 3 AA (R6, UM-3) size alkaline batteries (not You can hang the unit on your belt or pocket using the belt clip. supplied). The batteries will last about 30 hours with normal use. 1-E Adjusting the Antenna 1 Remove the cover.
- Page 4 Getting Started Section 1 1-G Programming Summary You can program the following functions. See the section number below for details. Each time you press (MENU), the display changes as follows. The display shows the current channel and group code. To select the operating channel, see 2-A. To select the group code, see 2-B.
- Page 5 Before You Talk Section 2 1 Press (MENU) The unit has 14 operating frequency channels and 38 group codes. twice. ≥“ To talk to others, all users in your group must be using the same ” and the current group code will channel and group code.
- Page 6 ¤ To Communicate 3-A Monitor 3-B Sending/Receiving Messages 1 Check the current channel activity (3-A). The monitor function unmutes the speaker in any situation. Use this ≥Do not talk if someone is already on the channel. function when received signals are too weak to recognize. You can use the monitor function to check activity on the current 2 Press and hold (TALK)
- Page 7 To Communicate Section 3 3-C Private Talk Mode If you want to talk privately during transmission, open the flip. To select the private talk mode volume You can transmit without using (TALK) by holding the unit near your 1 Open the flip and press (›) (‹) ear.
-
Page 8: Call Tones
Call Tones Section 4 4-A Call Tones 4-B Vibratory Call (KX-TR325 only) The unit has five unique call tones to identify each user and alert KX-TR325 allows you to receive a vibratory call. This is useful in others that you intend to transmit. When you press (CALL), all users noisy locations, or when quiet is required. -
Page 9: Channel Scan
Channel Scan Section 5 5-A Finding a Busy Channel ≥ If you want to scan privately, open the flip before pressing (SCAN) . Channel scan allows you to monitor 14 channels and a selected group code. When the unit detects channel activity on your selected When finished, close the flip. -
Page 10: Special Features
KX-TR325 also allows you to scramble your calls so that 6-C Auto Power OFF others will not understand your conversation. This is only possible between Panasonic transceivers. The factory preset is OFF. The unit can be programmed to turn itself off after a certain period of 1 Press (MENU) six times. -
Page 11: Using The Options
Using the Options To order, call the accessaries Section 7 telephone number in section 1-A. 7-A To Enjoy Hands-Free Operation 7-C To Operate with a Speaker Mic The unit has built-in Voice Activated Transmission (VOX) capability. Connecting a Speaker Mic (optional) to the MIC/SP jack of the unit, Connecting a Headset Mic (optional) or Earbud Mic (optional) to the you can operate the unit remotely. -
Page 12: Things You Should Know
¤ Things You should Know Channel frequency chart (unit: MHz) 8-A Talk Range Freq. Freq. Freq. The unit is designed to maximize performance and improve 462.5625 462.6875 467.6375 transmission range in the field. However, the talk range depends on 462.5875 462.7125 467.6625 your surrounding environment. - Page 13 ¤ Things You should Know 8-B Before Requesting Help Problem Remedy Problem Remedy You press (POWER) to ≥Reposition or replace batteries (1-C). ≥Steel/concrete structures, heavy Limited Talk Range power the unit ON, but foliage and use in buildings or the unit does not work. vehicles will decrease range.
- Page 14 ¤ Things You should Know 8-C Safety Instructions Splash-Resistant 4. Exercise care in handling battery(ies) in order not to short the battery(ies) to conductive materials such as rings, bracelets, and The unit is designed to be splash resistant. You can use the unit with keys.
- Page 15 ≥Routine care—wipe the unit with a soft cloth. Do not use benzine, this device. thinner, or any abrasive powder. ≥If there is any trouble—consult the authorized Panasonic Factory Note: Service Centers. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 16 Symptom ≥Send the unit to an authorized servicenter, prepaid and adequately insured. ≥Do not send your unit to the Panasonic Consumer Electronics Company listed below or to executive or regional sales offices. These locations do not repair consumer products. Panasonic Consumer Electronics Company,...
