Set Up Video Calls Between Two IECs with VECs
Figure I-1
2.
3.
Set Up Video Calls Between Two IECs with VECs
To set up calls between two IECs with VECs, you will need the following:
•
Note
•
•
•
•
Connect the Hardware
Follow the steps below to connect the hardware.
Make sure that both IECs are installed, registered, configured, and up and running. Confirm that the
Step 1
startup URL is displaying.
For each IEC, connect a HD video camera using a USB cable to a USB port on the IEC.
Step 2
For each IEC, connect a microphone to either a USB port or the MIC-in port (shown on the figure below
Step 3
as the pink port with the microphone icon).
Cisco Interactive Experience Client 4600 Series User Guide
I-2
Video Encoder in Status Tab
The IEC splash screen indicates if a VEC is built-in.
IECs with VECs have a sticker on the bottom of the device indicating that an encoder card is built-in.
IEC4610 or IEC4632 with embedded VECs (found in Release 2.1 and later)
Calls between two IECs cannot be accomplished with older versions of the IEC hardware such
as 2.0 or 1.0.3.
IEC Firmware 2.1.1 or later
High-definition video cameras such as the Cisco PrecisionHD or the Logitech C110 with USB
cables
Microphones
CUCM 9.1.1.10000-5
Appendix I HD Video Conferencing Between Two IECs Using the Video Encoder Card
