Basic Operating Instructions
Memory Card Portable Recorder
Model No.
AG-UMR20P
AG-UMR20E
DVQX1262ZA
ENGLISH
Advertisement
Table of Contents
Related Manuals for Panasonic AG-UMR20P
Summary of Contents for Panasonic AG-UMR20P
- Page 1 Basic Operating Instructions Memory Card Portable Recorder AG-UMR20P Model No. AG-UMR20E Before using this product, be sure to read “Information for Your Safety” (pages 3 to 8). More detailed operating instructions are available in “Operating Instructions (PDF format)”. ENGLISH To read it, download it from the website.
- Page 2 Hrvatski Suomi Magyar Português http://pro-av.panasonic.net/en/manual/index.html DVQX1262...
-
Page 3: Information For Your Safety
Information for Your Safety WARNING: To reduce the risk of fire, electric shock or product damage, ≥ Do not expose this unit to rain, moisture, dripping or splashing. ≥ Do not place objects filled with liquids, such as vases, on this unit. ≥... - Page 4 Warning Risk of fire, explosion and burns. Do not disassemble, heat above 60 oC (140 oF) or incinerate. ≥ We recommend using Panasonic batteries (VW-VBD58/AG-VBR59/AG-VBR89/AG-VBR118). ≥ If you use other batteries, we cannot guarantee the quality of this product. ≥ Do not heat or expose to flame.
- Page 5 Battery pack (Lithium ion battery pack) ≥ Use the specified unit to recharge the battery pack. ≥ Do not use the battery pack with equipment other than the specified unit. ≥ Do not get dirt, sand, liquids, or other foreign matter on the terminals. ≥...
- Page 6 Declaration of Conformity Model Number: AG-UMR20P Trade Name: Panasonic Responsible Party: Panasonic Corporation of North America Two Riverfront Plaza Newark NJ07102 Support contact: 1-800-524-1448 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 7 Disposal may be regulated in your community due to For your safety, please read the following text carefully. environmental considerations. For disposal or recycling information, please visit Panasonic website: http:// This appliance is supplied with a moulded three pin www.panasonic.com/environmental or call 1-888-769- mains plug for your safety and convenience.
- Page 8 <For India only> AEEE Yönetmeliğine Uygundur. AC adaptor information AEEE Complies with Directive of Turkey. Note regarding the Power Management IS 616/IEC 60065 function specified under COMMISSION REGULATION (EC) No 1275/2008 implementing Directive 2009/125/EC of the European Parliament and of the Council. This device is designed and manufactured for use at a broadcasting station and/or in a similar environment.
-
Page 9: Sicherheitshinweise
DEUTSCH Sicherheitshinweise WARNUNG: Um die Gefahr eines Brandes, eines Stromschlages oder einer Beschädigung des Produktes zu reduzieren, ≥ Setzen Sie dieses Gerät weder Regen, noch Feuchtigkeit, Tropfen oder Spritzern aus. ≥ Stellen Sie keine mit Flüssigkeiten gefüllten Gefäße, wie Vasen, auf dieses Gerät. ≥... - Page 10 Warnung Brand-, Explosions- und Verbrennungsgefahr. Nicht zerlegen, auf über 60 oC erhitzen oder verbrennen. ≥ Wir empfehlen, Panasonic-Akkus zu benutzen (VW-VBD58/AG-VBR59/AG-VBR89/AG-VBR118). ≥ Bei Einsatz anderer Akkus übernehmen wir keine Gewähr für die Qualität dieses Produkts. ≥ Setzen Sie den Akku weder Hitze noch offenem Feuer aus.
- Page 11 ∫ Entsorgung von Altgeräten und Entfernen des Akkus und der Knopfzelle Batterien Hauptspannungsversorgungsakku (Lithium-Ionen- Nur für die Europäische Union und Batterie) Entfernen Sie den Akku, während Sie auf den Akku- Länder mit Recyclingsystemen Freigabehebel drücken. Dieses Symbol, auf den Produkten, der Verpackung und/ oder den Begleitdokumenten, bedeutet, dass gebrauchte elektrische und elektronische...
- Page 12 ≥ Verwenden Sie ein handelsübliches Kabel nach USB 2.0-Standard. Schließen Sie einen miniB-Anschluss an dieses Gerät an. Beim Anschließen des speziellen Kamerakopfs (AG-UCK20G) ≥ Verwenden Sie für den Kamerakopf stets ein Originalkabel von Panasonic (AG-C20003G (3 m), AG-C20020G (20 m): Sonderzubehör). Beim Verbinden mit einem Netzwerk ≥...
-
Page 13: Précautions À Prendre
FRANÇAIS Précautions à prendre AVERTISSEMENT: Afin de réduire les risques d’incendie, de chocs électriques ou d’endommagement du produit, ≥ N’exposez pas cet appareil à la pluie, l’humidité, l’égouttement ou les éclaboussures. ≥ Ne placez pas d’objets remplis d’eau, comme des vases, sur cet appareil. ≥... - Page 14 Il existe des risques d’incendie, d’explosion et de brûlure. Ne pas démonter, chauffer au-delà de 60 oC (140 oF) ou incinérer. ≥ Nous vous conseillons d’utiliser des batteries Panasonic (VW-VBD58/AG-VBR59/AG-VBR89/AG-VBR118). ≥ Si vous utilisez d’autres batteries, nous ne pouvons pas garantir la qualité de ce produit.
- Page 15 Batterie (batterie au lithium-ion) ≥ Utilisez l’appareil spécifié pour recharger la batterie. ≥ N’utilisez la batterie avec aucun autre appareil que l’appareil spécifié. ≥ Évitez que de la saleté, du sable, des liquides ou d’autres corps étrangers n’entrent en contact avec les bornes. ≥...
- Page 16 <Pour l'Europe uniquement> Pour enlever la batterie ∫ L’élimination des équipements et des Batterie alimentation principale (Batterie au lithium- batteries usagés ion) Applicable uniquement dans les pays Tout en appuyant sur la touche de déverrouillage de la membres de l’Union européenne et batterie, retirez la batterie.
- Page 17 à cet appareil. Pour raccorder la tête de caméra dédiée (AG-UCK20G) ≥ Utilisez toujours un véritable câble de tête de caméra en option Panasonic (AG-C20003G (3 m (118-1/8 q)), AG-C20020G (20 m (787-3/8 q)) : en option). Pour se raccorder au réseau ≥...
-
Page 18: Informazioni Riguardanti La Vostra Sicurezza
ITALIANO Informazioni riguardanti la vostra sicurezza AVVISO: Per ridurre il rischio di incendi, scosse elettriche o danni al prodotto, ≥ Non esporre questa unità a pioggia, umidità, infiltrazioni o schizzi. ≥ Non collocare su questa unità oggetti riempiti di liquidi (ad esempio vasi). ≥... - Page 19 Rischio di incendio, esplosione e ustioni. Non disassemblare, riscaldare al di sopra dei 60 oC o incenerire. ≥ Si consiglia di utilizzare batterie Panasonic (VW-VBD58/AG-VBR59/AG-VBR89/AG-VBR118). ≥ Se si utilizzano batterie di tipo diverso, non è possibile garantire la qualità di questo prodotto.
- Page 20 ∫ Smaltimento di vecchie Per rimuovere la batteria apparecchiature e batterie usate Batteria di alimentazione principale (Litio Ioni Solo per Unione Europea e Nazioni batteria) con sistemi di raccolta e smaltimento Rimuovere la batteria tenendo premuto il pulsante di rilascio batteria. Questi simboli sui prodotti, sull’imballaggio e/o sulle documentazioni o manuali...
- Page 21 ≥ Usare un cavo disponibile in commercio compatibile con lo standard USB 2.0. Collegare un terminale miniB a questa unità. Collegamento alla Testa Camera dedicata (AG-UCK20G) ≥ Usare sempre un cavo testa camera opzionale originale Panasonic (AG-C20003G (3 m), AG-C20020G (20 m): opzionale). Collegamento ad una rete ≥...
-
Page 22: Información Para Su Seguridad
ESPAÑOL Información para su seguridad ADVERTENCIA: Para reducir el riesgo de incendio, de descarga eléctrica, o de daño del producto, ≥ No exponga esta unidad a la lluvia, humedad, goteo o salpicaduras. ≥ No ubique los objetos llenos con líquido, como floreros, sobre esta unidad. ≥... - Page 23 Riesgo de fuego, explosión y quemaduras. No desmonte, caliente a más de 60 oC (140 oF) ni incinere. ≥ Le recomendamos utilizar baterías Panasonic (VW-VBD58/AG-VBR59/AG-VBR89/AG-VBR118). ≥ No podemos garantizar la calidad de este producto si se utilizan baterías de otras marcas.
- Page 24 ∫ INSTRUCCIONES DE SEGURIDAD IMPORTANTES Lea atentamente estas instrucciones de funcionamiento antes de usar la unidad. Siga las instrucciones de seguridad en la unidad y las instrucciones de seguridad aplicables que se mencionan abajo. Guarde a mano estas instrucciones de funcionamiento para consultarlas en el futuro. Lea estas instrucciones.
- Page 25 <Solamente para Europa> Extracción de la batería ∫ Eliminación de Aparatos Viejos y de Batería de alimentación principal (Batería de litio Pilas y Baterías iones) Solamente para la Unión Europea y Mientras presiona el botón para expulsar la batería, países con sistemas de reciclado retire la batería.
- Page 26 ≥ Utilice un cable disponible comercialmente compatible con el estándar USB 2.0. Conecte un terminal miniB a esta unidad. Al conectar al cabezal de cámara específico (AG-UCK20G) ≥ Utilice siempre un cable opcional para cabezal de cámara Panasonic (AG-C20003G (3 m (118-1/8 q)), AG-C20020G (20 m (787-3/8 q)): opcional). Al conectar a una red ≥...
- Page 27 ≥ When storing the unit, it is recommended that you (AG-UCK20G) place a desiccant (silica gel) in with it. ≥ Always use a genuine Panasonic Camera head option About terminal protection cable (AG-C20003G (3 m (118-1/8 q)), AG-C20020G ≥ When not using the connecting terminal, please attach (20 m (787-3/8 q)): optional).
- Page 28 About the battery (optional) About the AC adaptor (supplied)/ battery charger (optional) The battery used in this unit is a rechargeable lithium-ion battery. It is susceptible to humidity and temperature and ≥ If the temperature of the battery is extremely high or the effect increases the more the temperature rises or extremely low, charging may take time or the battery falls.
- Page 29 About the SD card (optional) About operation from the Web screen When disposing of or giving away the SD card, note It is possible to distribute the streaming image of the unit that: (IP image transmission) or change the setup of the unit ≥...
- Page 30 ∫ Disclaimer of warranty ∫ Network security IN NO EVENT SHALL Panasonic Corporation BE As you will use the unit connected to a network, your LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT attention is called to the following security risks.
- Page 31 Be careful about the possibility of theft or loss of the unit, and be careful not to leave the unit unattended. Please the LCD monitor of this unit becomes note that Panasonic does not accept any responsibility cloudy) for the compromise, manipulation, and loss of Condensation occurs when there is a change in information caused by these events.
-
Page 32: Table Of Contents
Contents Information for Your Safety ........ 3 Recording Sicherheitshinweise ..........9 Précautions à prendre ........13 Informazioni riguardanti la vostra sicurezza ..18 Selecting a media to record ......51 Información para su seguridad ......22 Formatting media .......... 51 Accessories ............ -
Page 33: Accessories
Accessories Check the accessories before using this unit. Keep the accessories out of reach of children to prevent swallowing. AC adaptor AC cable (AG-UMR20P) (AG-UMR20E) For U.K. and Saudi Arabia (AG-UMR20E) For Continental Europe, etc. Caution for AC Mains Lead... -
Page 34: Preparation
Preparation What you can do with this unit Recording to the SD card It is possible to record motion pictures and still pictures to the SD card using a variety of recording functions. ≥ This unit supports relay recording using double card slots. Connecting to the Camera Head (optional) to record (CAM Mode) It is possible to connect to the Camera Head and record onto an SD card. -
Page 35: Linking To External Devices
Linking to external devices Connection to a PC (USB connection) Transfer data (files) to perform nonlinear editing on another device (PC, etc.). ≥ This unit supports USB 2.0. A SD card B USB 2.0 cable (A-miniB type) C PC SD cards are optional and not supplied with this unit. -
Page 36: Network Connection
Network connection Connection with remote camera controller This unit supports the remote camera controllers AW-RP50/AW-RP120 and the remote operation panel AK-HRP200. (Connection example) SIGNAL GND POWER TO PAN/TILT HEAD 12V IN TALLY/GPI BOOT ... - Page 37 Connection to PC/mobile terminal This unit can display an IP image on a PC connected to the network via wired LAN or a mobile terminal connected via a wireless access point. (Connection example) ...
-
Page 38: Names And Functions Of Main Parts
Preparation Names and Functions of Main Parts 11 12 13 14 15 16 17 18 19 20 25 26 24 21 22 23 ≥ When using screws, do not apply excessive force. LCD monitor (Touch screen) Also, if you use a M3 (3 mm (0.1 q) diameter) type Power button [ ] (l 44) screw longer than 8 mm (0.3 q) in length, this unit may... - Page 39 35 36 30 Inlet (cooling fan) (l 50) 31 Battery release button [PUSH] 32 Battery holder 33 SD Card slot cover (l 42) 34 Access lamp (card 1) (l 42) 35 Card slot 1 (l 42) 36 Card slot 2 (l 42) 37 Access lamp (card 2) (l 42) 38 Setting legs DVQX1262...
-
Page 40: Power Supply
To ensure that safe products are used we would recommend that a genuine Panasonic battery pack is used. ≥ For information on how to charge the battery, refer to the Operating Instructions for the battery charger. -
Page 41: Preparation Of Sd Cards
Preparation of SD cards The unit can record motion pictures or still pictures to an SD card. ≥ We recommend that you use a Panasonic Memory Card. Cards that you can use with this unit ∫ About the Speed Class ratings for recording motion pictures ≥... -
Page 42: Inserting/Removing An Sd Card
Inserting/removing an SD card When using an SD card for the first time, it is necessary to format the SD card. (l 51) When the SD card is formatted, all of the recorded data is deleted. Once the data is deleted, it cannot be restored. Caution: Check that the access lamp has gone off. -
Page 43: Connecting This Unit To The Camera Head (Cam Mode)
Preparation Connecting this unit to the Camera Head (CAM Mode) ∫ Attaching the Camera head option cable (optional) Be sure to turn off the unit before attaching the Camera head option cable. A Camera head option cable Insert Camera head option cable D into this unit’s CAMERA terminal and the Camera Head connecting terminal. -
Page 44: Turning The Unit On/Off
Preparation Turning the unit on/off ≥ The method for turning on the unit depends on the setting of [POWER UP OPTION]. Press power button B for 2 seconds or more to turn on the unit. To turn off the unit ... -
Page 45: Selecting A Mode
Preparation Selecting a mode Switching between the CAM Mode and the SDI Mode Always turn off this unit and turn it on again when switching between the SDI Mode and the CAM Mode. ≥ Connect this unit and the Camera Head when switching to the CAM Mode. (l 43) ≥... -
Page 46: Switching Between Recording Mode And Playback Mode
Switching between Recording Mode and Playback Mode When [PRIORITY MODE] is set to [REC/PB] or [REC/PB(4K)], press the MODE button to switch between Recording Mode and Playback Mode. ≥ If set to [IP], [IP(4K)], even if the MODE button is pressed, this unit will not enter Playback Mode. Press the MODE button A to switch between Recording Mode and Playback Mode. -
Page 47: Using The Menu Screen
Preparation Using the menu screen Menu setting by button operation Press the MENU button Press the buttons to move the cursor to the menu, and press the SET button to select. Place the cursor on [EXIT] and press the SET button to finish the menu setting. ∫... -
Page 48: Menu Setting By Touch Screen Operation
Menu setting by touch screen operation Press the MENU button Touch the top menu A. Touch the submenu B. ≥ Next (Previous) page can be displayed by touching Touch the desired item to enter the setting. Touch [EXIT] to exit the menu setting. How to use the touch screen You can operate by directly touching the LCD monitor (touch screen) with your finger. -
Page 49: Setting Date And Time
Preparation Setting date and time When this unit is turned on, the message [SET TIME ZONE AND DATE/TIME] may appear. To make these settings, select [YES], and follow the instructions from Step 2-3 of the time zone setting procedure. Time zone Time difference from the Greenwich Mean Time can be set. -
Page 50: Before Recording
Preparation Before recording ≥ When recording, make sure your footing is stable and there is no danger of colliding with another person or object. ≥ When you are outdoors, record pictures with the sunlight behind you. If the subject is backlit, it will become dark in the recording. -
Page 51: Recording
Recording Selecting a media to record You can specify the card slot to which motion pictures are to be recorded. Select the menu. : [RECORD SETUP] # [MEDIA SELECT] # [SD CARD 1]/[SD CARD 2] ≥ You can also change the card slot used for motion picture recording by pressing the USER button to which <SLOT SEL>... -
Page 52: Record On Sd Card
Recording Record on SD card Set [PRIORITY MODE] to [REC/PB] or [REC/ PB(4K)] to switch to Recording Mode. (l 45, 46) Press REC/PAUSE button A to start recording. ≥ When recording starts, REC (red) appears on the screen and the tally lamp lights up. - Page 53 ∫ About Auto Mode In Auto Mode, the following menu items are set automatically. Their settings cannot be changed. Menu item Setting [SCENE FILE] → [DETAIL LEVEL] [SCENE FILE] → [V DETAIL LEVEL] [SCENE FILE] → [DETAIL CORING] [SCENE FILE] → [SKIN TONE DTL] [SCENE FILE] →...
-
Page 54: Using The Zoom
Recording Using the zoom The unit can deliver a maximum optical zoom of 20k. ≥ You can check the zoom magnification on-screen, displayed as a value between Z00 and Z99. The value gets larger as you zoom in, and smaller as you zoom out. Press the buttons to zoom. -
Page 55: Playback
Playback Clip/Still picture playback Set this unit to playback mode. (l 46) Touch the play mode select icon A. Card display The selected card slot is displayed in yellow. Select the card slot C you wish to play back. ... - Page 56 Touch the clip or the still picture to be played back. ≥ Next (Previous) page can be displayed by touching ≥ You can change the playback media by pressing the USER button to which <SLOT SEL> is registered. Select the playback operation by touching the operation icon. G Operation icon TC 00:02:30.00 TC 00:02:30.00...
-
Page 57: Others
At least three (3) years from delivery of this product, these instructions are usually the registered Panasonic will give to any third party who contacts us at trademarks or trademarks of the manufacturers who the contact information provided below, for a charge no developed the system or product concerned. -
Page 58: Specification
Others Specification Memory Card Portable Recorder Appearance (Unit: mm [inch]) 46.1 [1-13/16] 22 [7/8] 19.5 [25/32] 41.6 [1-5/8] 38.15 [1-1/2] 19 [3/4] 41.6 [1-5/8] 34.6 [1-3/8] 78.4 [3-3/32] 78.4 [3-3/32] 32.1 [1-1/4] 32.1 [1-1/4] 11.4 11.4 [7/16] [7/16] [1/8] 100 [3-15/16] 26 [1-1/32] 101 [3-31/32] 68 [2-11/16]... - Page 59 General AC adaptor Power source: Power: 100 V to 240 V, DC 7.28 V (When using battery) 50 Hz/60 Hz, 1.2 A DC 12 V (When using AC adaptor) Power output: Current consumption: 12 V, 3.0 A When only SDI recording is used; 1.1 A (When using battery) indicates safety information 0.7 A (When using AC adaptor)
- Page 60 частин на мільйон; 6.полібромдефенілові ефіри (PBDE) – не перевищує 0,1 % ваги речовини або в концентрації до 1000 частин на мільйон. Manufactured by: Panasonic Corporation, Osaka, Japan Importer’s name and address of pursuant to EU rules: Panasonic Marketing Europe GmbH...
