Regulatory Compliance and Safety Information
Base Unit
United States Class B Notice - FCC Compliance
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to the Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canada Class B Notice
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Australia/New Zealand and European Class B Notice
N12558
EMI/EN 55 022 statement
This certifies that the Aastra IP Phone is shielded against the generation of radio interference in
accordance with the application of Council Directive 89/336/EEC. Conformity is declared by the
application of EN 55 022:1998 and EN 55 024:1998.
CE Declaration of Conformity
This product conforms to the provisions of Council Directive's EMC Directive (89/336/EEC),
Low Voltage Directive (73/23/EEC), and R+TTE Directive (1999/5/EC).
Publish Date: 01/02/2007
Document: 41-001198-01 Rev 02
For 57i CT IP Phone
