DIVAR 2000 / DIVAR 3000 / DIVAR 5000 Network/Hybrid Video Recorder Operation Manual Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
Page 2
Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
DIVAR 2000 / DIVAR 3000 / DIVAR Table of Contents | en 5000 Table of contents Safety Important safety instructions FCC and UL Short information System overview Installation Unpacking 4.1.1 Package contents Make connections 4.2.1 Back panel connectors DIVAR network 2000/3000 (no PoE) 4.2.2...
Page 4
DIVAR 2000 / DIVAR 3000 / DIVAR en | Table of Contents 5000 6.3.1 Detection 6.3.2 Configuration 6.3.3 Recording Alarm 6.4.1 Motion detect 6.4.2 Video loss 6.4.3 Input alarm 6.4.4 System alarm 6.4.5 Alarm Out Schedule 6.5.1 Weekdays and Holidays Storage 6.6.1...
DIVAR 2000 / DIVAR 3000 / DIVAR Table of Contents | en 5000 Configuration Web Client Software Getting started How to log on Web client live window 9.3.1 Playback mode 9.3.2 Event search 9.3.3 Export 9.3.4 Setting 9.3.5 Info 9.3.6...
Important safety instructions Video loss - Video loss is inherent to digital video recording; therefore, Bosch Security Systems cannot be held liable for any damage that results from missing video information. To minimize the risk of losing information, we recommend multiple, redundant recording systems, and a procedure to back up all analog and digital information.
Page 7
17. Attachments, changes or modifications - Only use attachments/accessories specified by the manufacturer. Any change or modification of the equipment, not expressly approved by Bosch, could void the warranty or, in the case of an authorization agreement, authority to operate the equipment.
DIVAR 2000 / DIVAR 3000 / DIVAR en | Safety 5000 FCC and UL FCC & ICES Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly. More information For more information please contact the nearest Bosch Security Systems location or visit www.boschsecurity.com http://www.boschsecurity.com/catalog_overview.htm Bosch Security Systems Operation Manual 2016.09 | v1.0 | AM18-Q0717...
DIVAR 2000 / DIVAR 3000 / DIVAR en | System overview 5000 System overview The recorder can be connected to cameras that use the latest H264 high-resolution video technology and state-of-the-art compression techniques. These advanced technologies, coupled with efficient network data transmission, deliver the high security and reliability required for modern surveillance systems.
This equipment should be unpacked and handled with care. If an item appears to have been damaged in shipment, notify the shipper immediately. Verify that all parts are included. If any items are missing, notify your Bosch Security Systems Sales or Customer Service Representative.
9. Connect extra video out cables to the ports if loop through is required to other devices (only for DIVAR 5000 hybrid). 10. Connect a Bosch Intuikey keyboard cable to the connector using the supplied adaptor (only for DIVAR 5000) – see description in Hardware setup.
5000 4.2.1 Back panel connectors DIVAR network 2000/3000 (no PoE) RJ45 video input for max. 32 IP cameras (max. 16 IP cameras for DIVAR 2000) connected via external switch (optional with DHCP configuration) RJ45 Ethernet connection (10/100/1000Base-T according to IEEE802.3)
DIVAR 2000 / DIVAR 3000 / DIVAR en | Installation 5000 4.2.2 Back panel connectors DIVAR network 2000 (8 PoE) Max. 8 RJ45 PoE ports (115 W; 25.5 W max. per port) connected with DHCP configuration (maximum 16 IP channels possible) RJ45 Ethernet connection (10/100/1000Base-T according to IEEE802.3)
Back panel connectors DIVAR network 2000/3000 (16 PoE) Max. 16 PoE ports (130 W; 25.5 W max. per port) connected with DHCP configuration (max. 16 IP cameras for DIVAR 2000; max 32 IP cameras for DIVAR 3000) RJ45 Ethernet connection (10/100/1000Base-T according to IEEE802.3)
DIVAR 2000 / DIVAR 3000 / DIVAR en | Installation 5000 4.2.4 Back panel connectors DIVAR network 5000 (no PoE) RJ45 video input for max. 32 IP cameras connected via external switch (optional with DHCP configuration) RJ45 Ethernet connection (10/100/1000Base-T according to IEEE802.3)
DIVAR 2000 / DIVAR 3000 / DIVAR Installation | en 5000 4.2.5 Back panel connectors DIVAR network 5000 (16 PoE) 16 RJ45 ports (200 W; max. 25.5 W per port) for connecting max. 16 PoE cameras connected with DHCP configuration (max.
DIVAR 2000 / DIVAR 3000 / DIVAR en | Installation 5000 4.2.6 Back panel connectors DIVAR hybrid 3000 16 BNC for connecting max. 16 analog cameras Max. 16 IP cameras connected via external switch (if no analog cameras are connected, an extra 16 IP cameras can...
DIVAR 2000 / DIVAR 3000 / DIVAR Installation | en 5000 4.2.7 Back panel connectors DIVAR hybrid 5000 16 BNC for connecting max. 16 analog cameras Max. 16 IP cameras connected with external switch (if no analog cameras are connected, an extra 16 IP cameras can...
DIVAR 2000 / DIVAR 3000 / DIVAR 20 en | Installation 5000 Powering up For units with an external power adapter 1. Switch on all equipment connected to unit. 2. Connect the DC power cord of the power adaptor to the 12 VDC connector on the unit.
DIVAR 2000 / DIVAR 3000 / DIVAR Installation | en 5000 Login Log in to your recorder by entering your user name and password, then click <OK>. Use the supplied USB mouse, front panel, remote control or keyboard to input data and commands.
All the input/output ports are Safety Extra Low Voltage (SELV) circuits. SELV circuits should only be connected to other SELV circuits. Keyboard connection (only DIVAR 5000 models) Use the keyboard connection on the back of the unit to connect a Bosch Intuikey keyboard using one of the following methods: –...
DIVAR 2000 / DIVAR 3000 / DIVAR Hardware setup | en 5000 power to keyboard keyboard control RS-485 KEYBOARD 5.1.2 Connect wires directly 1. Cut off one of the connectors at the end of the cable. 2. Strip cable wires 1, 3, 4 and 6.
RS-485 KEYBOARD RS485 port connection (only hybrid models) Use the RS485 connector to connect Bosch, Pelco-P or Pelco-D controllable cameras to the unit for pan, tilt, and zoom control. RS485 is a single-direction protocol; the PTZ device can’t return any data to the unit.
DIVAR 2000 / DIVAR 3000 / DIVAR Hardware setup | en 5000 Figure 5.1: RS485 connector Signal name Pin number Description TX + Data transmission TX - Data transmission Shield Max. signal voltage is -8 to +12 V. The recommended cable cross section is AWG 28-16 (0.08-1.5 mm2).
Page 26
DIVAR 2000 / DIVAR 3000 / DIVAR en | Hardware setup 5000 DIVAR 2000/3000 1, 2, 3, 4 Alarm inputs: max. 4. The alarm becomes active at low voltage. Max. input voltage 15 VDC. NO1 C1, Two groups of normal open activation outputs (on/off button).
DIVAR 2000 / DIVAR 3000 / DIVAR Settings | en 5000 Settings System Here you can choose from the following tabs General, Playback, Display, Serial port, Account and Service. 6.1.1 General General Language: Select here your desired language for the user interface (you will need to restart the system to display the user interface in the chosen language).
DIVAR 2000 / DIVAR 3000 / DIVAR 28 en | Settings 5000 1. Insert a USB stick (containing a company logo file) into the USB slot on the front of the DVR. 2. Choose the USB stick from the ‘Device name’ drop-down menu (a list normally appears on the bottom half of the screen showing the current folders and files available on the memory device;...
Use the Serial port menu to configure the connections for a Console connected to the RS232 port, and an optional Bosch keyboard (Intuikey series) connected to the extra RS485 port (on DIVAR 5000 models). Configure the settings for Console or Bosch keyboard as described below.
Page 30
DIVAR 2000 / DIVAR 3000 / DIVAR 30 en | Settings 5000 Administrator Advanced User User View (all channels) View (all channels) View (all channels) Pan/Tilt/Zoom Control Pan/Tilt/Zoom Control Pan/Tilt/Zoom Control Color Setting Color Setting Search/Play (all channels) Search/Play (all channels)
Enter the New password again in the Confirm field. 5. Click <Save> to save the new password setting. Notice! Bosch strongly recommends to enforce a strict password policy by using strong unique passwords with at least 8 characters including combinations of numbers and special characters.
Page 32
DIVAR 2000 / DIVAR 3000 / DIVAR 32 en | Settings 5000 Default Notice! User settings and recordings will be lost The system menu display, language, time display mode, video format, IP address and recordings will all lose their user defined setup after the factory defaults are restored.
– The maximum number of connections is 64, however more than 4 remote connections can cause performance limitations. Bosch strongly advises not using more than 4 simultaneous connections. Preferred DNS: if required, enter here the preferred DNS server IP address.
Use the following steps to configure DDNS: 1. Select the ‘DDNS enable’ box. 2. Select a DDNS provider from the drop-down menu. The providers supported are: Bosch free DDNS, NO-IP DDNS and Dyndns DDNS. All DDNS types can be valid at the same time;...
DIVAR 2000 / DIVAR 3000 / DIVAR Settings | en 5000 The SNMP files can be retrieved/received on devices using common tools such as MG-SOFT MIB Browser. The Management Information Base (MIB) can be downloaded via the Web. Use the following steps to configure SNMP: 1. Select the ‘SNMP enable’...
DIVAR 2000 / DIVAR 3000 / DIVAR en | Settings 5000 Select the File format, type and location. Then assign a schedule (weekday, start time, last number of days, time period and channel) to activate the storage. See also –...
DIVAR 2000 / DIVAR 3000 / DIVAR Settings | en 5000 Camera 6.3.1 Detection This screen shows a list of cameras connected to the DIVAR, IP and/or analog (see Device list). If required, cameras can also be added automatically with <Device search> or manually with <Manual add>.
DIVAR 2000 / DIVAR 3000 / DIVAR en | Settings 5000 6.3.3 Recording Enter here the relevant settings for each connected channel. In most cases you can encode 2 streams for each connected channel. If required, use the Default button to reset all encode fields to the factory default.
DIVAR 2000 / DIVAR 3000 / DIVAR Settings | en 5000 Alarm Use the Alarm menu to specify the desired behavior for a Motion detect, Video loss, Input alarm, System alarm, or Alarm out; also define how alarms are acknowledged.
DIVAR 2000 / DIVAR 3000 / DIVAR 40 en | Settings 5000 – Select here the days you want to assign as free days or work days and click <Save> – Now assign the active time periods for the work day or free day – these same time periods will be copied to all the assigned work days or free days 5. When ready, click <OK>...
DIVAR 2000 / DIVAR 3000 / DIVAR Settings | en 5000 6.4.3 Input alarm See Alarm > Motion detect for a description of applicable fields. 6.4.4 System alarm Use tabs in this menu to setup how the system reacts to different system alarms (HDD, Network, Temperature, Other).
DIVAR 2000 / DIVAR 3000 / DIVAR 42 en | Settings 5000 Schedule Here you can plan and set up schedules for efficient use of the channels while effectively covering most recording needs. You can also assign holiday intervals. 6.5.1...
DIVAR 2000 / DIVAR 3000 / DIVAR Settings | en 5000 Storage 6.6.1 HDD manage Here you can view and manage the HDD(s) installed in your DVR: – SATA: shows the current selected hard disk where the system will continuously record, overwriting the oldest unprotected video on the hard disk with newer video.
DIVAR 2000 / DIVAR 3000 / DIVAR 44 en | Operation 5000 Operation User controls and menus The following user controls are available: – Mouse – (the preferred input device when setting up the system and entering field values) –...
When entering characters in a field, click to switch between numeral, text capitalized and text non-capitalized When selecting camera channels (on the DIVAR 2000/3000), press first the Shift button and then the required channel number – see the keys below with number functions...
Page 46
In PTZ mode, use to control the tilt functions of the selected camera In text mode or when choosing a camera channel, input number 3 or 9 (only on the DIVAR 2000/3000) Left Right In menu mode, move around through menu items or values...
DIVAR 2000 / DIVAR 3000 / DIVAR Operation | en 5000 Play Next In playback mode, playback the next video In menu setup, scroll down the dropdown list In text mode or when choosing a camera channel, input number 8 (only on DIVAR 2000/3000)
Page 48
DIVAR 2000 / DIVAR 3000 / DIVAR en | Operation 5000 Figure 7.3: Remote control See the following table for detailed information on each of the remote control buttons. Button ID Name Function Power button Start up or shut down the device (may be password...
Page 49
DIVAR 2000 / DIVAR 3000 / DIVAR Operation | en 5000 Esc (Cancel) Go back to previous menu or cancel current operation (close upper interface or control) Mult Switch between multiple-windows and single-window In menu mode, move up and down through menu items...
DIVAR 2000 / DIVAR 3000 / DIVAR 50 en | Operation 5000 7.1.4 Quick menu When in live viewing mode, right-click the mouse for the Quick menu. Options here are: View 1, 4, 8, 9, 16, 32 – choose here the number of view windows shown on Monitor A (one- window, four-windows, nine-windows, 16-windows or 32-windows).
DIVAR 2000 / DIVAR 3000 / DIVAR Operation | en 5000 7.2.1 Live mode Once the Startup Wizard is completed, your monitor will show the live viewing mode with 1 to 32 real-time images on the display (from a maximum 32 connected cameras). The system date and time is displayed in the top right corner of the screen, and the channel ID is shown in the bottom left of each channel display.
DIVAR 2000 / DIVAR 3000 / DIVAR 52 en | Operation 5000 Snapshot Make a snapshot of the current channel display. The system will ask to export the snapshot to an email address, a USB memory device, and/or a DVD: Note: A disclaimer screen may initially appear when you first select Snapshot (click <Accept>...
DIVAR 2000 / DIVAR 3000 / DIVAR Operation | en 5000 Check that a sequence of camera pictures appears, To stop sequencing, right-click the mouse to access the Quick menu, and choose Sequence off 7.2.4 Monitor A Monitor A shows live pictures of connected cameras in full-screen or multiscreen, plus status messages and alarm events (e.g.
DIVAR 2000 / DIVAR 3000 / DIVAR en | Operation 5000 Playback Click Search/Play in the Quick menu (or Playback in the Main Menu) for the following screen. Note: A disclaimer screen may initially appear (click <Accept> to continue). Figure 7.4: Search/Play screen See the following table for an overview of the features on this screen.
Page 55
DIVAR 2000 / DIVAR 3000 / DIVAR Operation | en 5000 Playback Choose between 1/4/9/16 window or full screen (toggle the buttons during mode playback to switch between views): and – 1-window – select which channel to display from the drop-down menu channel (select ‘..’...
Page 56
DIVAR 2000 / DIVAR 3000 / DIVAR en | Operation 5000 File list Double click to view a list of recorded files for the selected day. The list displays the first channel of the recorded file (click the numbers above to select another channel). A maximum 128 files are shown at one time.
Page 57
DIVAR 2000 / DIVAR 3000 / DIVAR Operation | en 5000 When ready, return to the original calendar and channel setup interface by clicking Play or Pause (the ‘pause’ button is displayed if the DVR is already playing and you wish to pause the play)
Page 58
DIVAR 2000 / DIVAR 3000 / DIVAR 58 en | Operation 5000 Smart This function is only active when the system is playing a recording in 1- search window mode. Click to activate smart search. See following figure. Use your mouse to drag and select zone(s) in the window to detect motion.
Page 59
DIVAR 2000 / DIVAR 3000 / DIVAR Operation | en 5000 Time bar Displays a maximum 16 channel time bars for the current search date (use the scroll bars on the right to scroll up and down through the available channels).
Page 60
DIVAR 2000 / DIVAR 3000 / DIVAR 60 en | Operation 5000 Restrict/ Use this function to restrict playback of a recording and/or to protect that Protect recording from being deleted. The restrict/protect permission can be individually set for each user account.
DIVAR 2000 / DIVAR 3000 / DIVAR Operation | en 5000 7.3.1 Export Access the Export menu from the main menu or Search/Play screen (or by pressing the Export key on the Front Panel or on the remote control). Use this menu to write segments of recorded video to a USB storage device or recordable DVD.
Wait until the update is complete and the system is restarted. Notice! Bosch strongly recommends upgrading to the latest firmware for the best possible functionality, compatibility, performance and security. Check http://downloadstore.boschsecurity.com/ regularly to see if there is a new firmware version available.
DIVAR 2000 / DIVAR 3000 / DIVAR Operation | en 5000 Earliest recording: shows the date and time of the oldest recording still available on HDD. Latest recording: shows the date and time of the latest recording on HDD. Recording status: shows if HDD can record or not.
DIVAR 2000 / DIVAR 3000 / DIVAR 64 en | Operation 5000 – Event – record – Account – Clear – Playback – Connection The system can display a maximum 100 logs per page and a maximum 115 pages of log files (displayed in order of newest to oldest).
Page 65
DIVAR 2000 / DIVAR 3000 / DIVAR Operation | en 5000 Press <Search> to start the event search (all the events found will be listed in the table below). If required, use <Go to> to access a particular page in the list of events.
NOTICE! The Archive Player will not be downloaded from the DVR when archiving is performed via Web Client. Use the Archive Player available on the Bosch website, the product CD, or download it by performing a local archive. When copying the archive file to other media afterwards, make sure to also copy the Archive playernode:106123408751015 file.
Page 67
DIVAR 2000 / DIVAR 3000 / DIVAR Archive Player operation | en 5000 Name Function Menu bar Here you have the following options: Play Window (default window) activates a window where you can play pre-recorded files. Export File activates a window where you can choose files to export to a pre-defined directory –...
Page 68
DIVAR 2000 / DIVAR 3000 / DIVAR en | Archive Player operation 5000 Play screen Here you can have a maximum 16 player screens to simultaneously play a maximum 16 channels (cameras). Click — to minimize player screen Click [_] to maximize player screen...
DIVAR 2000 / DIVAR 3000 / DIVAR Archive Player operation | en 5000 Open an archive file After starting the player, check the relevant directory to locate your archive files (identified by file extensions .mpg, .mp4, .dav, .264, .dev, .asf).
DIVAR 2000 / DIVAR 3000 / DIVAR 70 en | Archive Player operation 5000 2. If required, preview the file on the left screen by selecting the check box for the chosen file (if the file has multiple channels, select the check box for the required channel). Use the play, pause, and fast forward/reverse buttons as required.
DIVAR 2000 / DIVAR 3000 / DIVAR Web Client Software | en 5000 Web Client Software Getting started How to log on 1. Open your web browser and enter the IP address for the DIVAR in the address column. For example, if your DVR IP is 10.10.3.16, then enter http:// 10.10.3.16 2. If Web Client is already installed, the following Login screen is shown (if Web Client is not...
DIVAR 2000 / DIVAR 3000 / DIVAR 72 en | Web Client Software 5000 The progress of the export is shown on the status bar. 9.3.3 Export Assign here a schedule for an automatic export (backup) of a recording to a directory.
Program upgrade is incorrect – Check the program upgrade file is the correct version – Try upgrading the program again – If the upgrade still does not succeed, contact Bosch service HDD malfunction – Check the HDD cabling – Format the HDD DVR automatically shuts down or stops running –...
Page 74
DIVAR 2000 / DIVAR 3000 / DIVAR 74 en | Troubleshooting 5000 – DVR and monitor resistance is not compatible. – Video transmission is too long or degrading is too large. – DVR color or brightness setup is incorrect. Cannot search local records –...
Page 75
DIVAR 2000 / DIVAR 3000 / DIVAR Troubleshooting | en 5000 – For some versions, there is hardware limit. Cannot log in client-end or web – For Windows 98 or Windows ME users, please update your system to Windows 2000 SP4 (or install client-end software for previous versions).
Page 76
– No DivX503Bundle.exe or ffdshow-2004 1012.exe in Windows XP OS. Forgotten local menu operation password or network password Please contact your local service engineer or Bosch sales group for help. 2016.09 | v1.0 | AM18-Q0717 Operation Manual Bosch Security Systems Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
DIVAR 2000 / DIVAR 3000 / DIVAR Maintenance | en 5000 Maintenance 11.1 Insert DIVAR 5000 in rack 1. Remove the four cross head screws (two on each side) located near the front panel on the right and left side of the unit.
DIVAR 2000 / DIVAR 3000 / DIVAR en | Maintenance 5000 11.4 Install DVD See separate Quick Install Guide. Refer to the Appendix for recommended DVD types. 2016.09 | v1.0 | AM18-Q0717 Operation Manual Bosch Security Systems Available from A1 Security Cameras...
The unit should only be passed on together with this installation guide. 12.2 Disposal Disposal - Your Bosch product was developed and manufactured with high-quality material and components that can be recycled and reused. This symbol means that electronic and electrical appliances, which have reached the end of their working life, must be collected and disposed of separately from household waste material.
DIVAR 2000 / DIVAR 3000 / DIVAR en | Technical data 5000 Technical data Environmental Operating temperature (incl. +0°C to +40°C (+32°F to +104°F) HDD(s) and DVD) Storage temperature -40°C to +70°C (-40°F to +158°F) Operating humidity <93% non-condensing Storage humidity <95% non-condensing...
Page 81
DIVAR 2000 / DIVAR 3000 / DIVAR Technical data | en 5000 Weight with PoE switch 6.37 kg (14.0 lb) approx. (excluding HDDs and DVD) Power AC input (without PoE) 100–240 VAC; 50-60 Hz; 1.9 A, 75 W AC input (with PoE) 100–240 VAC;...
14.1.1 Bosch software All Bosch software is licensed under the terms of the End User License Agreement (EULA) of Bosch Security Systems B.V. or Bosch Security Systems Inc, as available together with the physical carrier (CD or DVD). Any use is subject to agreement and compliance with such EULA, as applicable.
No representation or warranty, express or implied, is or will be made in relation to, and no responsibility or liability is or will be accepted by Bosch or its subsidiaries as to the accuracy or completeness of the given Information included here or any other written or oral information made available to any.
Page 85
