Setting Up Cisco Cius
This chapter comprises the following topics, which help you install Cisco Cius on an IP telephony network.
Before you install Cisco Cius, you must decide how to configure Cisco Cius in your network. Then you
Note
can install Cisco Cius and verify its functionality. For more information, see
Cius on Your
This chapter comprises the following topics:
•
•
•
•
•
•
Before You Begin
Before installing Cisco Cius, review the requirements in these sections:
•
•
Network Requirements
For Cisco Cius to operate successfully as an endpoint in your network, your network must meet the following
requirements:
• Working Voice over IP (VoIP) Network:
OL-27284-01
Network.
Before You Begin, page 1
Understanding Cisco Cius Components, page 2
Installing Cisco Cius, page 11
Verifying Cisco Cius Startup Process, page 12
Configuring Startup Network Settings, page 12
Configuring Security on Cisco Cius, page 12
Network Requirements, on page 1
Cisco Unified Communications Manager Configuration, on page 2
◦ VoIP configured on your Cisco routers and gateways
Preparing to Install Cisco
Cisco Cius Administration Guide, Release 9.2(4)
1
Advertisement
Table of Contents
Related Manuals for Cisco Cius
Summary of Contents for Cisco Cius
-
Page 1: Before You Begin
Setting Up Cisco Cius This chapter comprises the following topics, which help you install Cisco Cius on an IP telephony network. Before you install Cisco Cius, you must decide how to configure Cisco Cius in your network. Then you Note can install Cisco Cius and verify its functionality. -
Page 2: Cisco Unified Communications Manager Configuration
In Cisco Unified Communications Manager Administration, you can add users to the database and associate them with specific Cisco Cius devices. In this way, users gain access to their Unified CM User Option page to configure options for their Cisco Cius. See the Configuring Reset Options/Load Upgrades for details. - Page 3 USB ports, two in the back of the unit and one on the right side. Cisco Cius supports a maximum of 15 devices total connected to the USB ports. Each device that is connected to Cisco Cius is included in the maximum device count. Supported accessories include USB serial cable, USB mouse, USB keyboard, USB-powered hub, and USB memory stick.
- Page 4 The following table describes the features on the front of the media station. Table 2: Media Station with Handset - Front View Item Item Handset Speaker button Speaker Volume button USB Port Mute button Docking ports Cisco Cius Administration Guide, Release 9.2(4) OL-27284-01...
- Page 5 The USB Serial Console allows a USB port on the media station to be used as a console, eliminating the need for a serial port. The following table shows the settings for the USB console: Table 4: USB Console Settings Parameter Setting Baud rate 115200 Data 8 bit Cisco Cius Administration Guide, Release 9.2(4) OL-27284-01...
- Page 6 The USB console cable has a USB interface on one end and a serial interface on the other. The USB interface may be plugged in to any of the three USB ports on Cisco Cius. The serial interface connects to the serial port on the PC.
-
Page 7: Wired Headsets
(cell) phones and two-way radios, some noise or echo may still occur. A hum or buzz may be heard either by the remote party or by both the remote party and Cisco Cius user. - Page 8 If Cisco Cius cannot connect, it displays an error alert to let the user know the reason for the failure. A timeout of 10 seconds occurs for the Cisco Cius device to try to connect the accessory.
-
Page 9: Hands-Free Profile
• User guide provided with your headset Advanced Audio Distribution (A2DP) Profile Cisco Cius supports A2DP streaming audio from a music player to a Bluetooth headset that supports A2DP. A2DP can be disabled by the user. From the Bluetooth devices submenu, select the connected headset and choose Options >... -
Page 10: Using External Devices
Connect a monitor to the device by inserting one end of an HDMI cable into the micro-HDMI port and the other end into a monitor HDMI port. The Cisco Cius media station connects to an external monitor through a DisplayPort connection. - Page 11 Installing Cisco Cius You must connect Cisco Cius to the network and to a power source before using it. Cisco Cius can be powered directly through the AC Adapter on Cisco Cius or through Power over Ethernet (PoE+ 802.3at) through the media station.
-
Page 12: Configuring Startup Network Settings
Verifying Cisco Cius Startup Process After Cisco Cius is charged, press the Power button at the top of the unit to start the device. Cisco Cius begins its startup diagnostic process as the device checks its hardware. The home screen cycles through two screens, the first displays Cisco Cius and the second a flashing blue Cisco logo. - Page 13 Enter the authentication string if required by administrator and tap Submit. Cisco Cius begins to install, update, or remove the LSC, depending on how the CAPF was configured. During the procedure, a series of messages appears in the LSC option field in the Security Configuration menu, so you can monitor progress.
- Page 14 Setting Up Cisco Cius Configuring Security on Cisco Cius Cisco Cius restarts after LSC is installed, upgraded, or Note deleted. Cisco Cius Administration Guide, Release 9.2(4) OL-27284-01...
