Connections

Caution!
Wiring
!
Pinching of the wires is possible due to incorrectly hinged components.
–
–
–
Permitted cable types
For all MAP components and for all connections, only shielded cables are permitted.
4
Caution!
Wrong cable type
!
Using a wrong cable type can lead to malfunction of the system.
–
3.1

Connecting the data bus

To assist with cable connections, the terminal blocks on each system module are color-coded.
Terminal block color codes
Color
White
Black
Blue
Orange
Yellow
Brown
Green
Connecting the data bus
1.
2.
3.
2016.06 | 17 | F.01U.168.332
Ensure that there is sufficient slack in the service wire loop to allow proper movement of
the hinged mounting plates.
Ensure that the wiring to and from components on the hinged bracket is properly secured
to the hinged mounting plates.
Ensure strain relief by means of the T cutouts.
Ensure to connect the shield to the grounding studs.
Use shielded cables only.
Description
Auxiliary power
AC / battery
Inputs / tamper
Outputs
DR2020 printer (ICP-MAP0007 only)
LSN data (ICP-MAP0010 only)
Data bus
Connect the system modules via the data bus.
Always use the main panel as the first device on the data bus. The 120 ohm end
terminator is already installed on every data bus.
Connect a 120 ohm end terminator to the last device on each data bus.
