5.6 GROUPED ELEMENTS
a) MAIN MENU

PATH: SETTINGS GROUPED ELEMENTS
 NEGATIVE SEQUENCE
 CURRENT
The D60 relay provides two (2) negative-sequence time overcurrent elements, two (2) negative-sequence instantaneous
overcurrent elements, and two (2) negative-sequence directional overcurrent elements. For additional information on the
negative sequence time overcurrent curves, refer to the Inverse Time Overcurrent Curves section earlier.
5
5-210

SETTING GROUP 1(6)
 NEG SEQ TOC1

 NEG SEQ TOC2
MESSAGE

 NEG SEQ IOC1
MESSAGE

 NEG SEQ IOC2
MESSAGE

 NEG SEQ DIR OC1
MESSAGE

 NEG SEQ DIR OC2
MESSAGE

D60 Line Distance Protection System

5.6.11 NEGATIVE SEQUENCE CURRENT


NEGATIVE SEQUENCE CURRENT
See page 5–211.
See page 5–211.
See page 5–212.
See page 5–212.
See page 5–213.
See page 5–213.
