VC10
Wireless Presentation Gateway
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://
www.viewsonic.com in English, or in specific languages using the Regional selection
box in the upper right corner of our website. "Antes de operar su equipo lea cu
idadosamente las instrucciones en este manual"
Model No. VS17129
Advertisement
Table of Contents
Related Manuals for ViewSonic VC10
Summary of Contents for ViewSonic VC10
-
Page 1: User Guide
Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http:// www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website. - Page 2 Thank you for choosing ViewSonic As a world leading provider of visual solutions, ViewSonic is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic product you have chosen will serve you well.
-
Page 3: Compliance Information
Compliance Information Please read before proceeding • Use only the batteries and power adapter provided by the manufacturer. The use of unauthorized accessories may void your warranty. • Do not store your device in temperatures higher than 50°C (122°F). • The operating temperature for this device is from 0°C (32°F) to 35°C (95°F). FCC Compliance Statement The following statement applies to all products that have received FCC approval. -
Page 4: Ce Conformity For European Countries
FCC SAR Information This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. -
Page 5: Ic Warning Statement
IC Warning Statement This device complies with Industry Canada license- exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. -
Page 6: Declaration Of Rohs2 Compliance
Declaration of RoHS2 Compliance This product has been designed and manufactured in compliance with Directive 2011/65/EU of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS2 Directive), and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Proposed Maximum Substance... -
Page 7: Table Of Contents
Contents Compliance Information FCC Compliance Statement ...................i CE Conformity for European Countries ..............ii IC Warning Statement ..................iii Declaration of RoHS2 Compliance ...............iv Copyright Information Product Registration .................... vii For Your Records ....................vii General Hardware Installation .....................1 App (iOS/Android) ....................2 iOS System requirements ......................2 Android OS System requirements .....................2 Start up ............................2... - Page 8 Installation (Mac) ....................35 Download and Install .......................36 Next ............................36 Mirror ............................44 Extension ..........................44 Split screen ..........................45 Update .............................45 Setting .............................48 Connection ..........................53 Connection ..........................53 Other Information Customer Support ....................54 Limited Warranty ....................55 Mexico Limited Warranty ..................57...
-
Page 9: Copyright Information
® NERGY Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 10: General
General “EZCast Pro” is a new product based on successfulwireless app EZCast, and adds some new features for commercial/educational application. It supports Multi-users Display under our new Host Control System and Content Broadcasting function. There are still more new features to be added soon, please download and enjoy our EZCast Pro features with hardware! Hardware Installation LED Indicator... -
Page 11: App (Ios/Android)
App Installation • IOS and Android users: Please search “EZCast Pro” in Apple’s App Store or Google Play and install it. • Or Use the QR scanner app to scan the QR code on EZCast LAN’s main • page. *Supports iOS9 and Android 4.2 above • Windows and Mac OS users: Please download it from our official website: www.iezcast.com or •... -
Page 12: App Starts(Below Photos Are Based On Ios Version)
App starts(below photos are based on iOS version) When you execute the app, if you are not linking to EZCast Pro, youcan only • use several functions in offline mode. Click “EZCastPro” icon, the device will be listed, you can select thedevice you •... - Page 13 Important: WiFi Link mode explanations EZCast Pro devices allow variousconnection methods, here are the • descriptions: SoftAP mode: It’s direct linking from PC/MobilePhone/Tablet to a Pro device, • you can link to EZCast Pro’s SSID directly to discover it, and you can also setup Pro devices’WiFi to link with your router to keep internet surfing.
- Page 14 • There is 2 special modes for WiFi connections in our advanced setting, one is “Direct link only” and the other is“Via Router only”. • In “Direct Link Only” mode, you will not be able to discover EZCast Pro through your home router.
-
Page 15: Main Features
App Tips Link Mode Indication Direct link (peer to peer) Link through router Main Features • You can cast your multimedia data wirelessly now, however, please be noted some features like cloud video or web will require internet connection. • Please be noted EZMirror(Miracast) mode will disconnect current WiFi and you will need to connect to internet by your phone (3G or WiFi) if you want to keep internet surfing. -
Page 16: App Features
App Features(*based on iOS app for your reference) • Photo • You will have to allow EZCast Pro to share your camera roll andenable the location service before using Photo function. • In Photo viewer, you can select photo and it will be displayed onyour TV/Projector. You can also use gesture control to zoom in/out orchange photos. - Page 17 • Video • There are 2 sources to video streaming. One is to sync the videoyou like through iTunes (iTunes File Syncing), or you can selectvideo from your recorded video (Camera Roll) • Please be noted iOS will compress the recorded video beforestreaming to save the bandwidth, you can decide if you want tosave it in EZCast Pro app for future use.
- Page 18 • Live Camera • Live camera is a real object camera which allows you to streamthe image from mobile device’s camera, and take a snap shot toedit. • You can adjust image quality, switch from Front/Rear camera. You can enable Sketch and save the current image to album.
- Page 19 • Web • EZCast Pro comes with a built-in browser, and we also categorizeseveral popular websites for you. • The web page will dynamically change with different countrysetting in your device. • Sketch function is also supported. • Cloud Storage •...
-
Page 20: Split Screen
• Comment • We treasure your feedback either good or bad, so we created aninnovative way to communicate with you. You can send somecomments, suggestions or even bugs to us directly, and all the inputs will make our product better. • Split Screen and Host Control... - Page 21 • When you are the first user link to EZCast Pro and open the app,you will become the “Host”. • Host has the authority to control the display, that means Host rolecan use all features without limitation. The next or later coming users will be treated as “Guest”, somefunctions will be disabled under Guest mode, and you will need toget Host’s permission to display.
-
Page 22: Preferred Device
• Preference • Except Preferred device setting, you can also enable/disable theinquiry from guests, or automatically allow all display requestsfrom guests without showing pop-up message. • AirView • You can enable AirView function to see the current display contenton EZCast Pro hardware, this is a great tool for display sharing. - Page 23 • EZBoard • EZBoard is an innovativefunction to achieve real collaboration, which will allow all users share/collaborate in the same board. It can support sketch, insert photos or texts, all users can see the real-time result either on Pro or their own devices. Furthermore, we also integrate a quick tool for quiz purpose.
- Page 24 • EZChannel • Once you enter EZChannel, you can enjoy default featured channel, public channel or your friend’s channel. Please be noted some features will require logging in. • You can subscribe your channel here, review your playlists(collections) or install Chrome plug-in in the setting.
- Page 25 • EZMirror(Miracast, this is only available for Windows and Android) • EZMirror is fully compatible with Miracast, you can click theEZMirror button in EZCast app, and the receiver will be switchedto Miracast mode. • Once you turn it on, there will be a 60seconds countdown for yourmobile phone to connect with the receiver.
-
Page 26: Host Control
• AirSetup • In setting function, you can setup EZCastPro device’sconfigurations including output resolution, change SSID password,setup router connection for internet surfing, languages, EZAir modes, and turn on/off Airview/Castcode/Miracode…etc. • Miracode: this is a special code for IP translation for better IP protection •... -
Page 27: Link Status
• Advanced Example: Non-admin mode (Guest/Host) Example: Administrator mode • The Advanced functioncontains all advanced setting/control including Conference Control, Device Management, Network setup, Admin Setup, Host Authority control, Add CA and Access Control or Reboot and Upgrade FW…etc. The defaultpassword is “000000”, and you will have to change it while 1st time log-in admin. - Page 28 • Conference Control(Default for Host/Admin only) • This is an advanced control for all connected devices, you can select the position and place it. • You can disconnect all at one time, too. • Please be noted some special mode like Miracast will not be controlled by it.
- Page 29 • Device Management (Default for Host/Admin only) • You can modify device setting here, includinglanguage, device’s host name(not SSID), change resolution, change EZAir mode while playing video (only mirror or stream video), turn on/off AirDisk auto play, HDMI CEC, AirView on/off, Castcode on/ off/fixed digit, Miracode on/off, as well as the max.
- Page 30 Network Setup (Default for Admin, but can be enabled for Host by Administrator) • You can adjustnetwork related setting here. Please be noted some settings will require reboot.
- Page 31 Admin Setup (Only for Admin) • You can adjust more detailed functions here, and you can also release some authorities for Host to control the device, and here are some major features descriptions. • Password • Admin password change, the defaultpassword is “000000”, you will have to change it in the 1st time log-in as admin.
-
Page 32: Access Control
• Host Authority • The admin can release some functions to Host so that the host can get some control, too. If some functions are released to host, then the host can use some functions withoutlogging in as administrator. • Access Control •... -
Page 33: Reset To Default
• Add CA for WiFi enterprise (802.1x), this is for WiFi Enterprise connection, consult with your MIS for the CA if needed. • Reboot Control (Default for Admin only, but can be released to Host) • You can reboot the device if you need. • Reset to Default •... -
Page 34: Other Information
Latin America C= http://www.viewsonic.com/ www.viewsonic.com/la/ soporte@viewsonic.com (Mexico) la/soporte/servicio-tecnico Nexus Hightech Solutions, Cincinnati #40 Desp. 1 Col. De los Deportes Mexico D.F. Tel: 55) 6547-6454 55)6547-6484 Other places please refer to http://www.viewsonic.com/la/soporte/servicio-tecnico#mexico Latin America C= http://www.viewsonic.com/ www.viewsonic.com/la/ soporte@viewsonic.com (Peru) la/soporte/servicio-tecnico Macau www.hk.viewsonic.com T= 853 2870 0303 service@hk.viewsonic.com... -
Page 35: Limited Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components. - Page 36 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of profits, loss of business opportunity, loss of goodwill, interference with business relationships, or other commercial loss, even if advised of the possibility of such damages.
-
Page 37: Mexico Limited Warranty
Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of profits, loss of business opportunity, loss of goodwill, interference with business relationships, or other commercial loss, even if advised of the possibility of such damages. - Page 38 Tel: (52) 999-925-1916 Tel: 01(52)95-15-15-22-22 E-Mail: rrrb@sureste.com Fax: 01(52)95-15-13-67-00 E-Mail. gpotai2001@hotmail.com Tijuana: FOR USA SUPPORT: ViewSonic Corporation Av Ferrocarril Sonora #3780 L-C 14035 Pipeline Ave. Chino, CA 91710, USA Col 20 de Noviembre Tel: 800-688-6688 (English); 866-323-8056 (Spanish); Tijuana, Mexico E-Mail: http://www.viewsonic.com...
