Philips ProScreen PXG10 Specification Sheet

features:
ProScreen PXG10
Super High Bright XGA performance
• 2200 ANSI Lumen
• True XGA resolution
ProScreen
High Advanced compatibility
Motorised Zoom and Focus Lens system
Low Acoustical Fan Noise (35 dBA)
Easy Plug & Play
• Long-lasting - up to 2000 hours – 150 Watt
UHP TM (Ultra High Performance) lamp for uni-
form images, rich colours and brightness over
time, without hot spots
• High Advanced Full- and Semi- Automatic scaling
technology, guarantees compatibility with all
video and PC/Mac data sources up to UXGA
• High degree on compatibility via multiple Inputs
for Computer, Standard and High Definition
(HD) Video applications
• HDTV Compatible – 480i / 480p / 720p / 1080i
(4:3 & 16:9 aspect ratios)
• Component Video Input
• Superior Video Quality: 3D Y/C circuitry, Digital
comb filter, 3D Noise reduction, Interlaced (I) or
Progressive (P) scan, Digital motion correction
• Motorised Lens functions (1 : 1.3x), by Power
Zoom / Focus also operating in combination
with the optional available snap-off Wide & Tele
Lenses;
• Multiple projection application; Ceiling and Desk
operation in front- as well in rear projection.
• Digital picture enhance technologies; Digital
Zoom, Digital Freeze, Digital Keystones
• Auto voltage for safe usage around the globe
• Audience size up to over 300 people (board-
room, lecture hall or auditorium)
• Portable weight (7,2 kg), compact design with
integrated carrying handle, which makes the
product also suitable for portable use
• Slot for optional Kensington lock
• Free remote control included
• Full wired remote control possible via RS-232C
port for fixed installation operation
• Free support:
• First Choice* support
• Free toll-free support*
Standard mode (4:3)
Image diagonal size Projection distance
Tele zoom
[inch] [meters] [inch] [meters]
Minimum 40 1,02
55 1,4
1,52
60 87 2,2
72 1,83 102 2,6
2,13 122
84 3,1
100 2,54 3,7
146
3,81
150 220 5,6
200 5,08
291 7,4
Maximum 300 7,62
433 11,0
For wide mode (16:9) different projection distances are applicable.
main target specifications
LCD
Brightness
Contrast
Lamp
Lens
Input signals
Video
Data 1 and 2
Power in
Input connections
Video
Data 1
Data 2
RS232C
Mains
Output connections
Data out
Audio
Specialities
Dimensions
Net weight
Package
Executions
Optional acc.
Wide zoom
[meters]
[inch]
1,9
75
114 2,9
134 3,4
157 4,0
193 4,9
7,2
283
More information
9,8
386
563 14,3
Big picture Eye for detail
3x 1.3" HT Poly Silicon Active Matrix with u-lenses
2,359,296 pixels, RGB stripe (1024x768)
2200 ANSI lumens with 90% uniformity (CCR)
200:1
UHP 150; End user replaceable
2000 hours
F1.7 - 2.3; f= 49.1 – 63.8 mm
1.3x Motor Zoom / Focus
Proj. Dist. 1.4 – 1.9 (40"), 3,7 – 4,9m (100"), 11 – 14,3m (300")
Diagonal 40 -- 300"
NTSC 3.85, 4.43 /PAL-CCIR, Secam
DTV/HDTV(1080i, 720p,480p with 4:3 and 16:9 aspect ratios)
and DVD compatible.
PC and Mac compatible, Multi scan VGA, S-VGA, XGA, SXGA
UXGA via LIMESCO kind full screen true XGA display; Auto
Identification; Plug & Play VESA, DDC 1/2b
Hor. scan rate: 15 – 125 kHz;Vert. Refresh rate 43 – 200 Hz;
12 – 230 Dot clock
120 - 120 V / 220 - 240 V; 50/60 Hz; 265 W
S-Video (Y/C DIN)/Video (RCA)/ Stereo Audio (2x RCA)
Mini D-sub data (15 pin)/PC, RGBHV, PbPrY Csync (via BNC)
Stereo Audio (M3)
Mini D-sub data (15 pin)/PC Stereo Audio (M3)
9-pin mini DIN
Mains input socket (3 pin)
Mini D-sub data (15pin)
Stereo Audio (M3)
Multi Input projector for Data as well for Video applications (3D Y/C separation,
3 line Digital comb filter, 3D Noise reduction, Colour transient and Y delay)
Long life and almost constant light output over entire lamp life projection lamp
Automatic perfect Multi Scan data input handling,VGA up to UXGA resolutions.
Low Acoustical Noise (35dBA)
Intuitive Graphic User Interface for Ease of Use
Auto Source and Interlaced/Progressive (I/P)scan conversion
Power save modes (4)
Auto Image; Phase, Clock, Position H/V
Optional lenses:Tele and Wide lenses which can be fit in combination with the
existing zoom lens
261 x 129 x 356 mm (WxHxD); 12 dm 3
7,2 kg; <16 lbs
ProScreen PXG10 + lenscap
2x Power cord; USA version plus Continental Europe version
Remote Control + 3x AA batteries + USB Mouse receiver
VGA cable
RCA cable (Video/Audio stereo) + RCA - BNC adapters (3x)
S-Video cable
Scart – RCA adapter
DIN-D sub RS232C cable
User Guide (CD-ROM) plus Quick Reference, Registration card
Extra Air filter
LC 1041/00 Global version
UHP 150 Projection lamp
soft carrying bag
Exchangeable lenses;Tele and Wide lenses
Ceiling mount brackets (High, Low ceilings)
Mac adapter
www.pcstuff.philips.com/projectors
