- Page 1 Multimedia Projector Philips bClever SV1 User guide English...
-
Page 2: Table Of Contents
Connecting to video equipment 17-20 Video (CVBS) 17 S-Video 17 Scart connection 17 Component/HDTV 18 PR/R, PB/B,Y/G, S 18 When YPbPr connection has been made 18 Scart connection 19 RGBS 19 When RGBsog connection has been made 19 > English User guide bClever SV1... -
Page 3: Index
Picture Format 29 Personal Start-up text 30 31-33 Cleaning 31 Cleaning the cabinet 31 Cleaning the lens 31 Cleaning the dust filter 31 Lamp 32 Lamp replacement 32 Resetting the lamplife time 33 34-36 < English User guide bClever SV1... -
Page 4: Introduction
STAND BY PICTURE SIZE BRIGHTNESS CONTRAST FREEZE PICTURE FORMAT COLOUR TRACKING ZOOM DATA S-VIDEO VIDEO AV MUTE KEY LOCK INFO MENU KEYSTONE MUTE Scart/RCA Audio Video adapter (not for USA version) Audio/Video RCA Cable English User guide bClever SV1 >... -
Page 5: Optional Accessories
Optional accessories Service accessories Philips Multimedia Projector 1. Introduction The following accessories are available via the dealer from which you purchased your Philips projector: • LCA 3122/00 - 150 W replacement lamp - 8670 931 22009 • LCA 2214/00 - Ceiling mount - 8670 922 14009 •... -
Page 6: Functional Overview
To reduce/enlarge the size of the projected picture. When the menu is active the Cursor Control controls the menu cursor to navigate through the OSD menu.The cursor control works with up/down and left/right button operation. Controls English User guide bClever SV1 >... -
Page 7: Controls
VIDEO STANDBY STANDBY SOURCE SOURCE AV MUTE AV MUTE To receive the signals from the remote control. To adjust the vertical angle of the projector. To adjust the focus of the projected image. Controls < English User guide bClever SV1... -
Page 8: Remote Control
To confirm actions in the menu when the menu is on screen. To mute the sound of the projector and to mute the picture. To show information on the projector status: Source, Input Signal, Mute, A/V Mute, and Picture Format Remote control > English User guide bClever SV1... - Page 9 ‘Vivid’ is automatically set when computer input is used; ‘Natural’ is automatically set when video input is used. To capture a (moving) picture.The button toggles between the Freeze mode and the display situation. Remote control < English User guide bClever SV1...
-
Page 10: Connections
Input sockets to connect to the Audio out sockets of a video recorder, laser disc player, video camera or TV with A/V output socket. General Dust filter To connect the projector to the mains. To insert an optional locking device (Kensington lock). To adjust a possible oblique displayed picture. Connections English User guide bClever SV1 <... -
Page 11: Set Up
15 minutes. – Before disconnecting the mains lead, make sure that the cooling fan has stopped (about 3 minutes after the projector has been switched to Power/Standby). SCREEN Ceiling front projection SCREEN Ceiling rear projection English User guide bClever SV1 >... -
Page 12: Adjusting The Focus Of The Image
– The keystone slider appears on the screen. • This correction function also is accessible through the ‘Keystone’ option in the ‘Set up’ menu of the On Screen Display (OSD) menu. > English User guide bClever SV1... -
Page 13: Moving/Transporting The Projector
Push and slide the lid in the direction of the arrow. Install two ‘AA’ batteries as indicated inside the battery compartment. Replace the lid and snap it into place. The maximum range of the remote control is approximately 15 m (± 50 feet). < English User guide bClever SV1... -
Page 14: Installation
With the ‘Picture Format’ feature you can select one of five picture format options: 16:9, 16:9 enlarged, 16:9 in 4:3, 4:3, 4:3 to 16:9. To reduce the risk of fire or electric shock always switch off projector and external equipment before making any connections. General information < English User guide bClever SV1... -
Page 15: Connecting To A Computer
Switch on your Computer and projector. Press the Data button on the remote control. Press Menu. – The menu bar appears on the screen. The ‘Picture’ item is highlighted. Connecting to a computer > S-VIDEO VIDEO AUDIO-L AUDIO-R Mac/PC English User guide bClever SV1... -
Page 16: Connecting To An External Monitor
The image projected is simultaneously shown on the monitor. In case of interference problems when connecting to an external monitor, applying long VGA cables or interference with certain monitor type's, the use of an active splitter is recommended. Connecting to a computer < English User guide bClever SV1... -
Page 17: Connecting To Video Equipment
Audio (in) L/R sockets of the projector. S-Video Plug an optional S-Video connection cable into the VCR and the S-Video socket of the projector. AUDIO-L AUDIO-R L Audio R Video only CVBS CVBS (Video) only English User guide bClever SV1... -
Page 18: Component/Hdtv
The menu bar appears on the screen. The ‘Picture’ item is highlighted. Use Cursor Control left to select ‘Set up’. Use Cursor Control down to select ‘Auto Component Selection’. Use Cursor Control right to select ‘YPbPr’. S-Video AUDIO-L AUDIO-R Audio English User guide bClever SV1 >... -
Page 19: Scart Connection
The ‘Picture’ item is highlighted. Use Cursor Control left to select ‘Set up’. Use Cursor Control down to select ‘Auto Component Selection’. Use Cursor Control right to select ‘RGBsog’. VIDEO AUDIO-L AUDIO-R Component/HDTV equipment Audio English User guide bClever SV1 >... -
Page 20: Operation
– keystone correction; – brightness; – contrast; – colour tracking. Dialogs are used when setting e.g.: – keystone correction; – child lock. Lists are used when setting e.g.: – picture format; – source. Preparation > English User guide bClever SV1... -
Page 21: Feedback Messages
Data source cannot be shown. Warning messages Warning messages are displayed in the centre of the screen.They are displayed when: – lamplife time has almost expired; – lamplife time has expired. Preparation > English User guide bClever SV1... -
Page 22: On Screen Display Menu
0 (min) -100 (max) 16:9 16:9 enlarged 16:9 in 4:3 4:3 to 16:9 vivid warm normal cool 0 (soft) - 5 (sharp) 16 x Philips Personal None Auto Data RGB sync YPbPr RGBsog S-Video Video English User guide bClever SV1 < natural... -
Page 23: Menu Tree
16:9 in 4:3 4:3 to 16:9 vivid warm normal cool 0 (soft) - 5 (sharp) 0 (min) - 100 (max) 16 x Philips Personal None Auto Data RGB sync YPbPr RGBsog S-Video Video English User guide bClever SV1 > natural... - Page 24 On Screen Display Menu Sub menu Setting Deutsch English Français Español Italiano Nederlands Português ∑ 0.50 x - 1.00 x YPbPr 5 minute - 60 minutes Lamp used for: 0 OK (3 sec.) English User guide bClever SV1 > RGBsog...
-
Page 25: General Explanation
Cursor Control up/down. Confirm the setting by pressing OK. Select the next item to be adjusted in the sub menu and adjust as described above. Press Menu to close the On Screen Menu Display. On Screen Display Menu English User guide bClever SV1 >... -
Page 26: Data Adjustments
Key lock can also be disabled by pressing OK on the remote control or on the projector for 10 seconds. – Start-up screen to display (Philips) or suppresses (Off) the default Philips start-up screen or your personal startup text (Personal) upon the projector’s start up; – Source to select the current projection source: Auto, Data, RGBsync,YPbPr, RGBsog, S-Video, Video. -
Page 27: Video/S-Video Adjustments
Key lock can also be disabled by pressing OK on the projector for 10 seconds. – Start-up screen to display (Philips) or suppresses (None) the default Philips start-up screen or your personal startup text (Personal) upon the projector’s start up;... -
Page 28: General Adjustments/Settings
System Information sub menu contains an overview of the most relevant projector information, including information on the hardware and software configuration; – Factory settings to reset all user settings to the default factory settings; On Screen Display Menu > English User guide bClever SV1... -
Page 29: Examples
With Cursor Control you can adjust the position of the projected image upwards or downwards. On Screen Display Menu > English User guide bClever SV1... -
Page 30: Personal Start-Up Text
You can now enter your personal Start-up text with a maximum of 14 characters. Use Cursor Control Up/Down to select characters. Use Cursor Control Left/Right to move to a previous/next position. Confirm with OK. Press OK again to return to the main menu.. On Screen Display Menu > English User guide bClever SV1... -
Page 31: Maintenance
When the filter is damaged replace it with a filter of the same type (12 nc: 3122 434 02190). Don’t switch on the projector again unless the filter holder is installed correctly. > English User guide bClever SV1... -
Page 32: Lamp
When the lamp door is removed the mains inlet socket will be partly closed. The lamp door therefore cannot be removed if the mains lead is not disconnected from the projector. Read the caution and warning labels on the lamp holder. > English User guide bClever SV1... -
Page 33: Resetting The Lamplife Time
Use Cursor Control to select ‘Lamp counter’ in the ‘Set up’ menu. Press OK for 10 seconds to reset the lamp counter. If required, select another item you wish to adjust or press Menu to exit. < English User guide bClever SV1... -
Page 34: Troubleshooting
Decrease keystoning until the image is correctly displayed. For this use the • buttons on the remote control or the ‘Keystone’ option in the ‘Set up’ menu. Keystone buttons on the remote control or the Keystone English User guide bClever SV1 >... - Page 35 Cancel (A/V-)Mute. • – Distance is too great. Reduce distance. • – Batteries are exhausted. Replace batteries (see ‘Inserting the batteries in the remote control’). • – IR sensor is obstructed. Remove obstacle. • > English User guide bClever SV1...
- Page 36 Enable the ’Monitor out’ option. Press Menu and use cursor control to go to ‘Set up’ in the menu bar. Select ’Monitor out’ and select ‘On’. The Philips bClever SV1 projector uses three LCD (Liquid Crystal Display) panels.These panels contain a total of 1,200,000 pixels. As with any equipment, certain tolerances apply to the performance specification of the product.
