- Page 1 Philips multimedia projector bCool SV1 User guide English...
-
Page 2: Table Of Contents
Computer input 13 USB connection (Universal Serial Bus) 13 Video input 13 Connecting to a computer 14 Connecting to video equipment 15-16 CVBS (Video) 15 S-VHS (S-Video) 15 Scart connection 15 Component/HDTV (YPbPr/ YCbCr) 16 > English User guide bCool SV1... - Page 3 34-36 End of life directives Philips is paying a lot of attention to producing environmentally-friendly in green focal areas. Your new product contains materials which can be recycled and reused. At the end of its life specialised companies can dismantle the discarded product to concentrate the reusable materials and to minimise the amount of materials to be disposed of.
-
Page 4: Introduction
For your own protection and prolonged operation of your projector, please read the enclosed Safety Sheet. Make sure the following statement is on the Safety Sheet: Please confirm that the following items are packed in the projector box.They are provided to help you use or set up your projector. -
Page 5: Optional Accessories
The following accessories are available from our Service Organization: • Laser pointer remote Control - 3139 228 62631 • Compact remote control - 3139 228 62641 • User Guide (Cd- rom) - 3122 435 96321 8670 931 26009 8670 953 11009 English User guide bCool SV1 <... -
Page 6: Functional Overview
Fast blinks red (1 sec On, 1 sec Off) in case of fan error. To select the current projection source (Computer,YPbPr,YCbCr, RGBS, S-Video or Video).The button toggles between the six signals. To adjust the size of the image. To adjust the focus of the image. Controls English User guide bCool SV1 >... -
Page 7: Functional Overview
To connect the projector to the mains. To release the elevator foot. To adjust the vertical angle of the projector. To adjust a possible oblique displayed picture. To correct picture distortion of the vertical keystone type by internal scaling. Controls English User guide bCool SV1 <... -
Page 8: Remote Control
The Cursor Control can only function as a mouse cursor when projector and computer are connected via the USB connectors. Windows 98 ® , Windows ME ® , Windows 2000 ® or Windows XP ® should be installed on the computer when you make the USB connection. -
Page 9: Connections
When USB connection is used, the mouse cursor on the connected computer can be controlled through the projector remote control. Make sure Windows 98 ® , Windows ME ® , Windows 2000 ® or Windows XP ® is installed on the computer. -
Page 10: Turning On The Projector
The projector will now go into Standby mode. To switch off the mains supply completely, disconnect the mains lead. – Save energy! Please put the projector in the Standby position if you are not going to use the projector for more than 15 minutes. –... -
Page 11: Adjusting The Focus And Size Of The Image
– The Standby indicator light is red. Wait until the cooling fan has stopped (about 2 minutes after the projector has been put in Standby) and disconnect the mains lead and all other cables. Put the lens cap back in place to prevent damage to the front of the lens when moving/transporting the projector. -
Page 12: Inserting The Batteries In The Remote Control
Install Install two AAA Alkaline batteries as indicated inside the battery compartment. Replace the lid and snap it into place. The maximum range of the remote control is approximately 7 m (± 25 feet). < English User guide bCool SV1... -
Page 13: Installation
Video input The projector accepts the input signal of all major video formats, including NTSC 3.58, 4.43, PAL B, G, D, H, I, N, M, SECAM and HDTV (480i/P, 576P, 720P, 1080i) signals.The projector will recognize these standards and adapt to them automatically.With the ‘Picture format’ feature, you can select one of five picture format options: 4:3, 16:9, letter box, pan &... -
Page 14: Connecting To A Computer
Data in S-Video Data out Connect the Data (out) socket of the computer to the Data in socket of the projector and secure the plugs by tightening the thumb screws. For this, use the VGA cable supplied (1). Connect the USB (upstream) socket of the projector to the USB downstream port of the computer. -
Page 15: Connecting To Video Equipment
For this, use the Composite video cable (1) supplied. Connect the S-Video (out) socket of a S-VHS video recorder, Laser Disc player, video camera or TV to the S-Video (in) socket of the projector. For this, use the S-video cable (2) supplied. -
Page 16: Installation
Connect the plugs at the other end of the cable to the appropriate output sockets of your Component- or HDTV-video equipment (Pr,Y, Pb / Cr,Y, Cb). < Component/HDTV Equipment DVD player, Settop Box, HDTV receiver, etc. English User guide bCool SV1... -
Page 17: Operation
These messages will only be displayed when the menu option ‘Feedback’ is set to ‘On’ in the ‘Setup’ menu. All messages will be removed automatically after 4 seconds. Video selected as source S-Video selected as source no input signal A/V muted Computer selected as source Preparation < YPbPr selected as source English User guide bCool SV1... -
Page 18: On Screen Display Menu
All video and data adjustments and settings (except A/V Mute) are done through On Screen Displays with the help of Menu, OK and Cursor Control on the projector or the remote control. The projector is set to standard settings at the factory. However, you can adjust these settings to suit your own preferences. - Page 19 Smart Dimmer SecurityMax On Screen Display Menu Sub menu Setting Eng. Deu. Esp. Fra. Ita. Ned. Por. Chi. - 50 Auto Computer YPbPr YCbCr RGBS S-Video Video 16:9 Letter box Pan & Scan Compact Description English User guide bCool SV1 >...
-
Page 20: General Explanation
Adjust the selected item, using the Cursor left or right. Select the next item to be adjusted in the sub menu and adjust as described above. Press Menu to close the On Screen Display. On Screen Display Menu English User guide bCool SV1 >... -
Page 21: Computer Adjustments
If you experience a vertical flickering bar, use this function to make an adjustment. – Phase minimizes picture imperfections. When connecting the projector to your PC for the first time, be sure to adjust the phase control for optimal readability of the projected text. -
Page 22: General Adjustments
– Child lock de-activates the control keypad of the projector. – Sleep timer turns Sleep timer mode off or selects the delay time after which the projector automatically switches to Standby. On Screen Display Menu > English User guide bCool SV1... -
Page 23: Setup Adjustments
– Keystone corrects picture distortion of the vertical keystone type by internal scaling. – Mirror mirrors the picture for use of the projector in various positions with respect to the user(s) and the projection screen. -- Source selects the current projection source (Computer,YPbPr,YCbCr, RGBS, S-Video or Video). If you select ‘Auto’, the projector will always automatically search for available input signals. -
Page 24: Theft Deterrence - Securitymax
However, the cost of resetting the security code is not covered under the manufacturer's warranty. In the unfortunate event that your projector is stolen, Philips cannot be held responsible, nor take any action. We advise you to report the theft immediately at the nearest police station. -
Page 25: Setting Up Securitymax
Philips Multimedia Projector 5. Operation Setting up SecurityMax Make sure the projector is properly connected (see the user manual on the manual CD-ROM). Turn on the projector. – The projector Startup screen will be projected. Press Menu and select ‘Setup’ in the menu bar. Select the SecurityMax item. -
Page 26: Changing Your Security Code
Leave the projector turned on during this time and then unlock as described under ‘Unlocking the projector after shutdown’. If you turn off the projector before the full 30 minutes have past, it will be locked again for the remaining time before turning on again. -
Page 27: Entering Your Personal Start-Up Text
3 Click the OK button. 4. Click the Menu button to close this window. – Your own Personal start-up screen will now be projected each time the projector is turned on.The screen will be projected for about 30 seconds and cannot be suppressed. -
Page 28: Unlocking The Projector After Shutdown
– When shutdown time has expired, operating the projector is no longer possible. – The Locked warning screen will be projected with the SecurityMax symbol flashing. • To continue the use of the projector, you will have to unlock it as described in the next chapter. -
Page 29: Update The Shutdown Timer
5. Operation On Screen Display Menu > Update the shutdown timer 1 Make sure the projector is properly connected (see the user manual on the manual CD-ROM). 2 Turn on the projector. – The Locked warning screen will be projected. -
Page 30: Removing Securitymax Protection
3 Select Yes/No by using the Cursor Control left/right. 4 Click the OK button. 5 Click the Menu button to close this window. Exit SecurityMax 1 Exit SecurityMax by pressing the Menu button. English User guide bCool SV1 Philips Multimedia Projector... -
Page 31: Maintenance
Press the Standby button twice to turn off the projector. – The Standby indicator light turns red. Wait until the cooling fan has stopped (about 1 minute after the projector has been put in Standby) and disconnect the mains lead and all other cables. Cleaning the cabinet •... -
Page 32: Lamp
Use Cursor Control to move the cursor to ‘Setup’. Use Cursor Control to select ‘Lamp counter’. Turn off the projector and wait until the lamp has cooled down before disconnecting the projector. Remove the mains lead from both projector and wall socket.Turn the projector over. -
Page 33: Maintenance
Use Cursor Control to select ‘Setup’ in the menu bar. Use Cursor Control to select ‘Lamp counter’ in the sub menu. Press OK to reset the lamp counter. If required, select another item you wish to adjust or press Menu to exit. > English User guide bCool SV1... -
Page 34: Troubleshooting
Philips Multimedia Projector 7.Troubleshooting If a fault occurs, first check the points listed below before taking the projector for repair. If you are unable to correct a problem by following these hints, consult your dealer or service center. Under no circumstances should you try to repair the projector yourself as this could void your warranty. - Page 35 Lamp indicator – Red blinking (0.5sec. On, 0.5sec. Off): lamp start has failed. • Disconnect projector from the mains. Reconnect and restart. If this does not solve the problem, replace the lamp. See ’Maintenance. ’ – Red blinking (1sec. On, 1sec. Off): the fans are locked.
-
Page 36: Troubleshooting
• Check proper installation of the batteries in the remote control and/or replace the batteries. • Check the projector to make sure it is receiving signal from the remote control. • Check that the USB cable has been properly connected.
