Summary of Contents for Draytek VigorIPPBX 3510

  • Page 2 VigorIPPBX 3510 Series User’s Guide Version: 2.0 Firmware Version: V3.5.5 Date: 19/11/2010 VigorIPPBX 3510 Series User’s Guide...
  • Page 3 Web registration is preferred. You can register your Vigor router via Owner http://www.draytek.com. Firmware & Tools Due to the continuous evolution of DrayTek technology, all routers will be regularly Updates upgraded. Please consult the DrayTek web site for more information on newest firmware, tools and documents.

  • Page 4: Regulatory Information

    Product: VigorIPPBX 3510 DrayTek Corp. declares that VigorIPPBX 3510 of routers are in compliance with the following essential requirements and other relevant provisions of R&TTE Directive 1999/5/EEC. The product conforms to the requirements of Electro-Magnetic Compatibility (EMC) Directive 2004/108/EC by complying with the requirements set forth in EN55022/Class A and EN55024/Class A.

  • Page 5: Table Of Contents

    4.2 Create a Remote Dial-in User Connection Between the Teleworker and Headquarter 48 4.3 QoS Setting Example......................52 4.4 LAN – Created by Using NAT ..................... 56 4.5 Upgrade Firmware for VigorIPPBX 3510................58 4.6 Backup and Restore Settings for VigorIPPBX 3510 ............60 VigorIPPBX 3510 Series User’s Guide...
  • Page 6 5.5.5 Keyword Object ......................134 5.5.6 Keyword Group......................135 5.5.7 File Extension Object....................136 5.6 CSM ............................ 137 5.6.1 APP Enforcement Profile ..................139 5.6.2 URL Content Filter Profile..................143 5.6.3 Web Content Filter Profile..................147 VigorIPPBX 3510 Series User’s Guide...
  • Page 7 5.12.3 File Explorer......................226 5.12.4 USB Disk Status ..................... 227 5.12.5 Syslog Explorer....................... 227 5.13 System Maintenance....................... 229 5.13.1 System Status......................229 5.13.2 TR-069 ........................231 5.13.3 Administrator Password..................232 5.13.4 Configuration Backup ..................... 232 VigorIPPBX 3510 Series User’s Guide...
  • Page 8 6.3 Pinging the Router from Your Computer................ 252 6.4 Checking If the ISP Settings are OK or Not..............253 6.5 Backing to Factory Default Setting If Necessary............255 6.6 Contacting Your Dealer..................... 255 Appendix: Hardware Specifications................257 VigorIPPBX 3510 Series User’s Guide viii...

  • Page 9: Chapter 1: Preface

    By the way, DoS/DDoS prevention and URL/Web content filter strengthen the security outside and control inside. VigorIPPBX 3510 can provide up to 100 extensions setup to let all registered IP phones in LAN or remote sites around the world to have unlimited free calls through Internet.

  • Page 10: Led Indicators And Connectors

    The port is connected with 10Mbps. Left LED The port is connected. WAN 1 (Green) The port is disconnected. Blinking The data is transmitting. Right LED The port is connected with 100Mbps. (Green) The port is connected with 10Mbps. VigorIPPBX 3510 Series User’s Guide...
  • Page 11 Connecter for FXS interface of PABX. LAN (1-4) Connecters for local networked devices. WAN 2/1 Connecter for remote networked devices. Connecter for a USB device (for 3G USB Modem or printer). Connecter for a power adapter. Power Switch. ON/OFF VigorIPPBX 3510 Series User’s Guide...

  • Page 12: Hardware Installation

    Power on the device by pressing down the power switch on the rear panel. The system starts to initiate. After completing the system test, the PWR and ACT LEDs will light up and start blinking. (For the detailed information of LED status, please refer to section 1.2.) VigorIPPBX 3510 Series User’s Guide...

  • Page 13: Introduction For Fxs/Fxo/Isdn Te/Isdn Nt Module

    FXO equipment. As for VigorIPPBX 3510, it is more special because it has both FXS and FXO devices at the same time. It can connect to the phone line to act as FXO equipment; and it can connect to telephones to act as FXS equipment.
  • Page 14 Based on the characteristics described above that the ISDN NT equipment and the ISDN TE equipment must connect with each other, please pay special attention when you use ISDN NT card and ISDN TE card. VigorIPPBX 3510 Series User’s Guide...

  • Page 15: Printer Installation

    You can install a printer onto the router for sharing printing. All the PCs connected this router can print documents via the router. The example provided here is made based on Windows XP/2000. For Windows 98/SE, please visit www.draytek.com. Before using it, please follow the steps below to configure settings for connected computers.
  • Page 16 Open File->Add a New Computer. A welcome dialog will appear. Please click Next. Click Local printer attached to this computer and click Next. In this dialog, choose Create a new port Type of port and use the drop down list to select Standard TCP/IP Port. Click Next. VigorIPPBX 3510 Series User’s Guide...
  • Page 17 In the following dialog, type 192.168.1.1 (router’s LAN IP) in the field of Printer Name or IP Address and type IP_192.168.1.1 as the port name. Then, click Next. Click Standard and choose Generic Network Card. Then, in the following dialog, click Finish. VigorIPPBX 3510 Series User’s Guide...
  • Page 18 11. Select “LPR” on Protocol, type p1 (number 1) as Queue Name. Then click OK. Next please refer to the red rectangle for choosing the correct protocol and LPR name. The printer can be used for printing now. Most of the printers with different manufacturers are compatible with vigor router. VigorIPPBX 3510 Series User’s Guide...
  • Page 19 Note 1: Some printers with the fax/scanning or other additional functions are not supported. If you do not know whether your printer is supported or not, please visit www.draytek.com to find out the printer list. Open Support >FAQ; find out the link of Printer Server and click it;...
  • Page 20 This page is left blank. VigorIPPBX 3510 Series User’s Guide...

  • Page 21: Chapter 2: Configuring Basic Settings

    Open a web browser on your PC and type http://192.168.1.1. A pop-up window will open to ask for username and password. Please type “admin” as the username and leave blank for the password on the window. Next click OK for next screen. VigorIPPBX 3510 Series User’s Guide...
  • Page 22 Enter the login password (the default is blank) on the field of Old Password. Type New Password and Confirm Password. Then click OK to continue. Now, the password has been changed. Next time, use the new password to access the Web Configurator for this router. VigorIPPBX 3510 Series User’s Guide...

  • Page 23: Quick Start Wizard

    Type the name for this router. Physical Mode If you choose WAN2, you can specify Ethernet or 3G USB Modem as the physical mode. Physical Type Choose the physical type you desired. The default setting is Auto negotiation. VigorIPPBX 3510 Series User’s Guide...

  • Page 24: Pppoe

    Ethernet can share a common connection. PPPoE is used for most of modem users. All local users can share one PPPoE connection for accessing the Internet. Your service provider will provide you information about user name, password, and authentication mode. VigorIPPBX 3510 Series User’s Guide...
  • Page 25 Confirm Password Retype the password. Click Next for viewing summary of such connection. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system status of this protocol will be shown. VigorIPPBX 3510 Series User’s Guide...

  • Page 26: Pptp/L2Tp

    Click PPTP/L2TP as the protocol. Type in all the information that your ISP provides for this protocol. PPTP Setting --- L2TP Setting --- User Name Assign a specific valid user name provided by the ISP. Password Assign a valid password provided by the ISP. Confirm Password Retype the password. VigorIPPBX 3510 Series User’s Guide...
  • Page 27 PPTP/L2TP Server – Type the IP address of the PPTP/L2TP Server. Click Next for viewing summary of such connection. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system status of this protocol will be shown. VigorIPPBX 3510 Series User’s Guide...

  • Page 28: Static Ip

    Type in the primary IP address for the router if you want to use Static IP mode. If necessary, type in secondary IP address for necessity in the future. After finishing the settings in this page, click Next to see the following page. VigorIPPBX 3510 Series User’s Guide...

  • Page 29: Dhcp

    In such cases you need to click the Specify a MAC Address and enter the MAC address in the MAC Address field. After finishing the settings in this page, click Next to see the following page. VigorIPPBX 3510 Series User’s Guide...

  • Page 30: Ippbx Wizard

    All the settings, also, can be configured by using IP PBX menu. However, the wizard is the most convenient and easy method for users. & & Click IPPBX Wizard. You can get the first screen as shown below. VigorIPPBX 3510 Series User’s Guide...
  • Page 31 You can set 10 groups for using in different conditions. Then click Next to access into next web page. Below shows an example for your reference: After finishing the extension & group setup, please click Next. VigorIPPBX 3510 Series User’s Guide...

  • Page 32: Sip Trunk Setup

    Trunk Number. When you finish the settings of profile name, domain/realm, proxy, account number/name, password and trunk number fields, please click OK to save them. The new added profile will be displayed on the screen. VigorIPPBX 3510 Series User’s Guide...

  • Page 33: Office Hours Setup

    Is this schedule available at If such schedule will be available in the weekend, simply the weekend click Yes, otherwise, click No. When you finish the settings, click Finish to save the settings and exit the wizard. VigorIPPBX 3510 Series User’s Guide...

  • Page 34: Service Activation Wizard

    Service Activation Wizard is a tool which allows you to use trial version or update the license of WCF directly without accessing into the server (MyVigor) located on http://myvigor.draytek.com. For using Web Content Filter Profile, please refer to section 5.6.3 Web Content Filter Profile for detailed information.
  • Page 35 Free trial edition: it offers a period of trial for you to get acquainted with WCF function. Formal edition with license key: you can extend the license valid time manually. Note: If you activate Formal edition with license key first, the free trial edition will be invalid. VigorIPPBX 3510 Series User’s Guide...
  • Page 36 Wait for a moment till the following page appears. When such page appears, you can enable or disable these services for your necessity. Then, click Finish. Note: The service will be activated and applied as the default rule configured in Firewall>>General Setup. VigorIPPBX 3510 Series User’s Guide...
  • Page 37 Later, if you need to extend the license valid time, you can also use the Service Activation Wizard again to reach your goal by clicking the radio button of Formal edition with license key and clicking Next. VigorIPPBX 3510 Series User’s Guide...

  • Page 38: Online Status

    Display the speed of transmitted octets at the WAN interface. RX Packets Display the total number of received packets at the WAN interface. RX Rate Display the speed of received octets at the WAN interface. VigorIPPBX 3510 Series User’s Guide...

  • Page 39: Saving Configuration

    Settings Saved means your settings are saved once you click Finish or OK button. When you click the menu item under Support Area, you will be guided to visit www.draytek.com and open the corresponding pages directly. VigorIPPBX 3510 Series User’s Guide...
  • Page 40 This page is left blank. VigorIPPBX 3510 Series User’s Guide...

  • Page 41: Chapter 3: Applications

    PSTN number 87654321. The mobile No. +49-176999661 made a call to IP Phone with ext. No.201: Press 12345678. After getting through you will hear the auto reply from the PBX, then VigorIPPBX 3510 Series User’s Guide...
  • Page 42 The analog phone with ext. No. 602 made a call to IP phone with extension No. 301: Press extension No. 605. After getting through you will hear the dial tone, then press the ext. No. 301. VigorIPPBX 3510 Series User’s Guide...

  • Page 43: Conventional Analog Phones) & Poe-Switch For Ip-Based Phones

    FXO 5 port: with extension No. 609 [Phone No. 88839] FXO 6 port: with extension No. 610 [Phone No. 88840] FXO 7 port: with extension No. 611 [Phone No. 88841] FXO 8 port: with extension No. 612 [Phone No. 88842] VigorIPPBX 3510 Series User’s Guide...
  • Page 44 888835 Port 2 (FXO) 888836 Port 3 (FXO) 888837 Port 4 (FXO) 888838 Port 5 (FXO) 888839 Port 6 (FXO) 888840 Port 7 (FXO) 888841 Port 8 (FXO) 888842 Vigor3300V 61.31.167.135 Port 1 (FXS) 888829 VigorIPPBX 3510 Series User’s Guide...

  • Page 45: Isdn Application Via Isdn Trunk

    The analog phone with VoIP number 302 in Shanghai made a call to the remote ISDN Phone (Ex:801): Dial to SIP trunk number 307; then dial ISDN trunk number 0 to connect to ISDN PBX. After getting through you can hear the dial tone, press ext. No. 801. VigorIPPBX 3510 Series User’s Guide...

  • Page 46: Isdn Application With All Isdn Te Ports

    The IP phone with ext. 301 on Internet made a call to the remote ISDN Phone (Ex: 801): Dial to SIP trunk number 307; then dial ISDN trunk number 0 to connect to ISDN PBX. After getting through you can hear the dial tone, press ext. No. 801. VigorIPPBX 3510 Series User’s Guide...

  • Page 47: Isdn Application With 4 Isdn Te And 2 Isdn Te/ 2 Isdn Nt Ports

    ISDN Phone: with extension No. 803 ISDN Phone: with extension No. 804 The ISDN phone with ext. 905 (with MSN No. 21) on VigorIPPBX 3510 made a call to the remote ISDN Phone (Ex:801): Dial ISDN trunk number 0 to connect to ISDN PBX.
  • Page 48 This page is left blank. VigorIPPBX 3510 Series User’s Guide...

  • Page 49: Chapter 4: Other Applications

    Then, For using PPP based services, such as PPTP, L2TP, you have to set general settings in PPP General Setup. For using IPSec-based service, such as IPSec or L2TP with IPSec Policy, you have to VigorIPPBX 3510 Series User’s Guide...
  • Page 50 Go to LAN-to-LAN. Click on one index number to edit a profile. Set Common Settings as shown below. You should enable both of VPN connections because any one of the parties may start the VPN connection. VigorIPPBX 3510 Series User’s Guide...
  • Page 51 If a PPP-based service is selected, you should further specify the remote peer IP Address, Username, Password, PPP Authentication and VJ Compression for this Dial-Out connection. Set Dial-In settings to as shown below to allow Router B dial-in to build VPN connection. VigorIPPBX 3510 Series User’s Guide...
  • Page 52 Address, Username, Password, and VJ Compression for this Dial-In connection. At last, set the remote network IP/subnet in TCP/IP Network Settings so that Router A can direct the packets destined to the remote network to Router B via the VPN connection. VigorIPPBX 3510 Series User’s Guide...
  • Page 53 Go to LAN-to-LAN. Click on one index number to edit a profile. Set Common Settings as shown below. You should enable both of VPN connections because any one of the parties may start the VPN connection. VigorIPPBX 3510 Series User’s Guide...
  • Page 54 If an IPSec-based service is selected, you may further specify the remote peer IP Address, IKE Authentication Method and IPSec Security Method for this Dial-In connection. Otherwise, it will apply the settings defined in IPSec General Setup above. VigorIPPBX 3510 Series User’s Guide...
  • Page 55 Address, Username, Password, and VJ Compression for this Dial-In connection. At last, set the remote network IP/subnet in TCP/IP Network Settings so that Router B can direct the packets destined to the remote network to Router A via the VPN connection. VigorIPPBX 3510 Series User’s Guide...

  • Page 56: Create A Remote Dial-In User Connection Between The Teleworker And Headquarter

    PPP General Setup. For using IPSec-based service, such as IPSec or L2TP with IPSec Policy, you have to set general settings in IKE/IPSec General Setup, such as the pre-shared key that both parties have known. VigorIPPBX 3510 Series User’s Guide...
  • Page 57 Otherwise, it will apply the settings defined in IPSec General Setup above. If a PPP-based service is selected, you should further specify the remote peer IP Address, Username, Password, and VJ Compression for this Dial-In connection. VigorIPPBX 3510 Series User’s Guide...
  • Page 58 For Win2000/XP, please use "Network and Dial-up connections" or “Smart VPN Client”, complimentary software to help you create PPTP, L2TP, and L2TP over IPSec tunnel. You can find it in CD-ROM in the package or go to www.draytek.com download center. Install as instructed.
  • Page 59 VPN router. To use default gateway on remote network means that all the packets of remote host will be directed to VPN server then forwarded to Internet. This will make the remote host seem to be working in the enterprise network. VigorIPPBX 3510 Series User’s Guide...

  • Page 60: Qos Setting Example

    Vigor router at home to connect to the server in the headquarter office downtown via either HTTPS or VPN to check email and access internal database. Meanwhile, children may chat on Skype in the restroom. Go to Bandwidth Management>>Quality of Service. VigorIPPBX 3510 Series User’s Guide...
  • Page 61 Return to previous page. Enter the Name of Index Class 1 by clicking Edit link. Type the name “E-mail” for Class 1. For this index, the user will set reserved bandwidth (e.g., 25%) for E-mail using protocol POP3 and SMTP. VigorIPPBX 3510 Series User’s Guide...
  • Page 62 VoIP influent other application. Click OK. If the worker has connected to the headquarter using host to host VPN tunnel. (Please refer to Chapter 3 VPN for detail instruction), he may set up an index for it. Enter the VigorIPPBX 3510 Series User’s Guide...
  • Page 63 Click Edit to open the following window. Check the ACT box, first. 10. Then click Edit of Local Address to set a worker’s subnet address. Click Edit of Remote Address to set headquarter’s IP address. Leave other fields and click OK. VigorIPPBX 3510 Series User’s Guide...

  • Page 64: Lan - Created By Using Nat

    DHCP server is enabled so it assigns every local NATed host an IP address of 192.168.1.x starting from 192.168.1.10. You can just set the settings wrapped inside the red rectangles to fit the request of NAT usage. VigorIPPBX 3510 Series User’s Guide...
  • Page 65 To use another DHCP server in the network rather than the built-in one of Vigor Router, you have to change the settings as show below. You can just set the settings wrapped inside the red rectangles to fit the request of NAT usage. VigorIPPBX 3510 Series User’s Guide...

  • Page 66: Upgrade Firmware For Vigorippbx 3510

    Please do the following: 1. Go to www.draytek.com. 2. Access into Support >> Downloads. Please click the model name of VigorIPPBX 3510 and click on it to download the firmware execution file. 3. Locate the AutoFwUp_VXXX file that you downloaded from the website.
  • Page 67 5. In the dialog of Select Router, choose VigorIPPBX 3510 and click OK. 6. In the Confirm Password dialog, please type the password that you use to login Vigor router and click OK. If there is no password needed, click OK directly.

  • Page 68: Backup And Restore Settings For Vigorippbx 3510

    1. Go to www.draytek.com. 2. Access into Support >> Downloads. Please find out Utility menu and click it. Search the model you have (i.e., VigorIPPBX 3510) and click on it to download the newly update firmware for your router. 3. Click on the link of Firmware Upgrade Utility to download the tool. After downloading the file, please decompressed it onto your host.
  • Page 69 5. The Firmware Upgrade Utility will appear as follows: 6. Click the browse button of Router IP to search the IP address (e.g., 192.168.1.1) of VigorIPPBX 3510. Click OK. Note: Do not type the IP address in the field of Router IP directly. VigorIPPBX 3510 Series User’s Guide...
  • Page 70 Choose Backup Setting as the Operation Mode. 8. Next, click the browse button of Save Config to for specifying the place that the configuration file stored. Click OK. VigorIPPBX 3510 Series User’s Guide...
  • Page 71 9. Next, click Fetch. 10. When it is finished, the following dialog will appear. 11. Now, the configuration files (with the file name like V3510_XXXX, V35VoipMoudule_XXXX) will be stored in your host. VigorIPPBX 3510 Series User’s Guide...

  • Page 72: Restore The Configuration Settings

    1. Double click on the FrmUpg icon. 2. The Firmware Upgrade Utility will appear as follows: 3. Click the browse button of Router IP to search the IP address (e.g., 192.168.1.1) of VigorIPPBX 3510. Click OK. VigorIPPBX 3510 Series User’s Guide...
  • Page 73 4. Choose Restore as the Operation Mode. 5. Click the browse button of Select Router Config to locate the configuration file. VigorIPPBX 3510 Series User’s Guide...
  • Page 74 6. Next, click the browse button of Select VoIP Config to locate the module file for the router. Choose the file of V3K52262_XXXXXXX and click Open. 7. Next, click Import. VigorIPPBX 3510 Series User’s Guide...
  • Page 75 8. When it is finished, the following dialog will appear. 9. Now, the configuration files have been restored to your router. VigorIPPBX 3510 Series User’s Guide...

  • Page 76: Request A Certificate From A Ca Server On Windows Ca Server

    Go to Certificate Management and choose Local Certificate. VigorIPPBX 3510 Series User’s Guide...
  • Page 77 Copy and save the X509 Local Certificate Requet as a text file and save it for later use. Connect to CA server via web browser. Follow the instruction to submit the request. Below we take a Windows 2000 CA server for example. Select Request a Certificate. VigorIPPBX 3510 Series User’s Guide...
  • Page 78 IPSec (Offline request) below. Then you have done the request and the server now issues you a certificate. Select Base 64 encoded certificate and Download CA certificate. Now you should get a certificate (.cer file) and save it. VigorIPPBX 3510 Series User’s Guide...
  • Page 79 (.cer file) into Vigor router. When finished, click refresh and you will find the below window showing “------END CERTIFICATE REQUEST------” You may review the detail information of the certificate by clicking View button. VigorIPPBX 3510 Series User’s Guide...

  • Page 80: Request A Ca Certificate And Set As Trusted On Windows Ca Server

    Use web browser connecting to the CA server that you would like to retrieve its CA certificate. Click Retrive the CA certificate or certificate recoring list. VigorIPPBX 3510 Series User’s Guide...
  • Page 81 You may review the detail information of the certificate by clicking View button. Note: Before setting certificate configuration, please go to System Maintenance >> Time and Date to reset current time of the router first. VigorIPPBX 3510 Series User’s Guide...

  • Page 82: Creating An Account For Myvigor

    The website of MyVigor (a server located on http://myvigor.draytek.com) provides useful service (e.g., Web Content Filter) to filter the web pages for protecting your system. To access into MyVigor for getting more information, please create an account for MyVigor first.
  • Page 83 5. Type your personal information in this page and then click Continue. 6. Choose proper selection and click Continue. VigorIPPBX 3510 Series User’s Guide...
  • Page 84 Check to see the confirmation email with the title of Letter from myvigor.draytek.com. 9. Click the Activate my Account link to enable the account that you created. The following screen will be shown to verify the register process is finished. Please click Login. VigorIPPBX 3510 Series User’s Guide...
  • Page 85 11. Now, click Login. Your account has been activated. You can access into MyVigor server to activate the service (e.g., WCF) that you want. 1. Access into http://myvigor.draytek.com. Find the line of Not registered yet?. Then, click the link Click here! to access into next page.
  • Page 86 2. Check to confirm that you accept the Agreement and click Accept. 3. Type your personal information in this page and then click Continue. 4. Choose proper selection and click Continue. 5. Now you have created an account successfully. Click START. VigorIPPBX 3510 Series User’s Guide...
  • Page 87 8. When you see the following page, please type in the account and password (that you just created) in the fields of UserName and Password. Then type the code in the box of Auth Code according to the value displayed on the right side of it. VigorIPPBX 3510 Series User’s Guide...
  • Page 88 Now, click Login. Your account has been activated. You can access into MyVigor server to activate the service (e.g., WCF) that you want. VigorIPPBX 3510 Series User’s Guide...

  • Page 89: Chapter 5: Reference - Advanced Web Configuration

    When a router begins to connect to your ISP, a serial of discovery process will occur to ask for a connection. Then a session will be created. Your user ID and password is authenticated VigorIPPBX 3510 Series User’s Guide...

  • Page 90: Network Connection By 3G Usb Modem

    Besides, 3G USB Modem in WAN2 also can be used as backup device. Therefore, when WAN1 is not available, the router will use 3.5G for supporting automatically. The supported 3G USB Modem will be listed on Draytek web site. Please visit www.draytek.com for more detailed information.
  • Page 91 WAN2. You can choose PPP as the access mode and click Details Page for further configuration. Physical Type You can change the physical type for WAN2 or choose Auto negotiation for determined by the system. VigorIPPBX 3510 Series User’s Guide...
  • Page 92 15 seconds. WAN2 Download speed exceed XX kbps– It means the connection for WAN1 will be activated when WAN2 Download speed exceed certain value that you set in this box for 15 seconds. VigorIPPBX 3510 Series User’s Guide...

  • Page 93: Internet Access

    Access Mode Use the drop down list to choose a proper access mode. The details page of that mode will be popped up. If not, click Details Page for accessing the page to configure the settings. VigorIPPBX 3510 Series User’s Guide...
  • Page 94 PPP/MP Setup PPP Authentication – Select PAP only or PAP or CHAP for PPP. If you want to connect to Internet all the time, you can check Always On. VigorIPPBX 3510 Series User’s Guide...
  • Page 95 Cable service provider will offer a fixed public IP, while a DSL service provider will offer a public subnet. If you have a public subnet, you could assign an IP address or many IP address to the WAN interface. VigorIPPBX 3510 Series User’s Guide...
  • Page 96 Click Enable RIP for activating this function. WAN IP Network This group allows you to obtain an IP address automatically and Settings allows you type in IP address manually. VigorIPPBX 3510 Series User’s Guide...
  • Page 97 MAC Address field. DNS Server IP Type in the primary IP address for the router if you want to use Address Static IP mode. If necessary, type in secondary IP address for necessity in the future. VigorIPPBX 3510 Series User’s Guide...
  • Page 98 Click Yes to use this function and type in a fixed IP address in the box. Fixed IP Address -Type a fixed IP address. WAN IP Network Obtain an IP address automatically – Click this button to obtain VigorIPPBX 3510 Series User’s Guide...
  • Page 99 Set the PCs on LAN to work at certain time interval only. You may choose up to 4 schedules out of the 15 schedules pre-defined in Applications >> Schedule setup. The default setting of this filed is blank and the function will always work. VigorIPPBX 3510 Series User’s Guide...

  • Page 100: Load-Balance Policy

    Displays the IP address for the end of the destination IP. Dest Port Start Displays the IP address for the start of the destination port. Dest Port End Displays the IP address for the end of the destination port. VigorIPPBX 3510 Series User’s Guide...
  • Page 101 Type the destination port start for the destination IP. Dest Port End Type the destination port end for the destination IP. If this field is blank, it means that all the destination ports will be passed through the WAN interface. VigorIPPBX 3510 Series User’s Guide...

  • Page 102: Lan

    IP address. As a part of the public subnet, the Vigor router will serve for IP routing to help hosts in the public subnet to communicate with other public hosts or servers outside. Therefore, the router should be set as the gateway for public hosts. VigorIPPBX 3510 Series User’s Guide...
  • Page 103 You can group local hosts by physical ports and create up to 4 virtual LANs. To manage the communication between different groups, please set up rules in Virtual LAN (VLAN) function and the rate of each. VigorIPPBX 3510 Series User’s Guide...

  • Page 104: General Setup

    1st IP Address Type in private IP address for connecting to a local private network (Default: 192.168.1.1). 1st Subnet Mask Type in an address code that determines the size of the network. (Default: 255.255.255.0/ 24). VigorIPPBX 3510 Series User’s Guide...
  • Page 105 So those hosts in 2 subnet won’t get an IP address belonging to 1 subnet. RIP Protocol Control Disable deactivates the RIP protocol. It will lead to a stoppage of the exchange of routing information between routers. (Default) VigorIPPBX 3510 Series User’s Guide...
  • Page 106 DNS Server. If your ISP does not provide it, the router will automatically apply default secondary DNS Server IP address: 194.98.0.1 to this field. The default DNS Server IP address can be found via Online Status: VigorIPPBX 3510 Series User’s Guide...

  • Page 107: Static Route

    Here is an example of setting Static Route in Main Router so that user A and B locating in different subnet can talk to each other via the router. Assuming the Internet access has been configured and the router works properly: use the Main Router to surf the Internet. VigorIPPBX 3510 Series User’s Guide...
  • Page 108 Click the LAN - Static Route and click on the Index Number 1. Check the Enable box. Please add a static route as shown below, which regulates all packets destined to 192.168.10.0 will be forwarded to 192.168.1.2. Click OK. VigorIPPBX 3510 Series User’s Guide...

  • Page 109: Vlan

    Virtual LAN function provides you a very convenient way to manage hosts by grouping them based on the physical port. Go to LAN page and select VLAN. The following page will appear. Click Enable to invoke VLAN function. VigorIPPBX 3510 Series User’s Guide...
  • Page 110 P3 and P4. After checking the box to enable VLAN function, you will check the table according to the needs as shown below. To remove VLAN, uncheck the needed box and click OK to save the results. VigorIPPBX 3510 Series User’s Guide...

  • Page 111: Bind Ip To Mac

    It is used to refresh the ARP table. When there is one new PC added to the LAN, you can click this link to obtain the newly ARP table information. IP Bind List It displays a list for the IP bind to MAC information. VigorIPPBX 3510 Series User’s Guide...

  • Page 112: Nat

    192.168.1.0/24 subnet for the router. As stated before, the NAT facility can map one or more IP addresses and/or service ports into different specified services. In other words, the NAT function can be achieved by using port mapping methods. Below shows the menu items for NAT. VigorIPPBX 3510 Series User’s Guide...

  • Page 113: Port Redirection

    To use this function, please go to NAT page and choose Port Redirection web page. The Port Redirection Table provides 20 port-mapping entries for the internal hosts. Press any number under Index to access into next page for configuring port redirection. VigorIPPBX 3510 Series User’s Guide...
  • Page 114 For example, the built-in web configurator in the router is with default port 80, which may conflict with the web server in the local network, http://192.168.1.13:80. Therefore, you need to change the router’s http port to any one other than the default port 80 to avoid VigorIPPBX 3510 Series User’s Guide...

  • Page 115: Dmz Host

    DMZ Host allows a defined internal user to be totally exposed to the Internet, which usually helps some special applications such as Netmeeting or Internet Games etc. VigorIPPBX 3510 Series User’s Guide...
  • Page 116 Click DMZ Host to open the following page: If you previously have set up WAN Alias for PPPoE or Static or Dynamic IP mode, you will find them in Aux. WAN IP for your selection. VigorIPPBX 3510 Series User’s Guide...
  • Page 117 DMZ host. When you have selected one private IP from the above dialog, the IP address will be shown on the following screen. Click OK to save the setting. VigorIPPBX 3510 Series User’s Guide...

  • Page 118: Open Ports

    Inactive or Active state. To add or edit port settings, click one index number on the page. The index entry setup page will pop up. In each index entry, you can specify 10 port ranges for diverse services. VigorIPPBX 3510 Series User’s Guide...
  • Page 119 IP 192.168.1.10 can use 86.123.123.2 as source IP when it sends packet out to Internet. You can use address mapping function to achieve this demand. Simply type 192.168.1.10 as the Private IP; and type 86.123.123.2 as the WAN IP. VigorIPPBX 3510 Series User’s Guide...
  • Page 120 Specify the WAN interface that will be used for this entry. WAN IP Select an IP address (the selections provided here are set in IP Alias List of Network >>WAN interface). Local host can use this IP to connect to Internet. VigorIPPBX 3510 Series User’s Guide...
  • Page 121 Display the protocol for the incoming data of such trigger profile. Incoming Port Display the port for the incoming data of such trigger profile. Status Display if the rule is active or de-active. Click the index number link to open the configuration page. VigorIPPBX 3510 Series User’s Guide...
  • Page 122 When the trigger packets received, it is expected the incoming packets will use the selected protocol. Select the protocol (TCP, UDP or TCP/UDP) for the incoming data of such trigger profile. Incoming Port Type the port or port range for the incoming packets. VigorIPPBX 3510 Series User’s Guide...

  • Page 123: Firewall

    It will check packets according to the filter rules. If legal, the packet will pass the router. The following illustrations are flow charts explaining how router will treat incoming traffic and outgoing traffic respectively. VigorIPPBX 3510 Series User’s Guide...
  • Page 124 4. Port Scan attack 12. Tear drop attack 5. IP options 13. Ping of Death attack 6. Land attack 14. ICMP fragment 7. Smurf attack 15. Unknown protocol 8. Trace route Below shows the menu items for Firewall. VigorIPPBX 3510 Series User’s Guide...

  • Page 125: General Setup

    Select one of the URL Content Filter Profile settings (created in CSM>> URL Content Filter Profile) for applying with this router. Please set at least one profile for choosing in CSM>> URL Content Filter Profile web page first. For troubleshooting needs, VigorIPPBX 3510 Series User’s Guide...
  • Page 126 Syslog For troubleshooting needs you can specify the filter log and/or CSM log here by checking the box. The log will be displayed on Draytek Syslog window. Advance Setting Click Edit to open the following window. However, it is strongly recommended to use the default settings here.

  • Page 127: Filter Setup

    To edit or add a filter, click on the set number to edit the individual set. The following page will be shown. Each filter set contains up to 7 rules. Click on the rule number button to edit each rule. Check Active to enable the rule. VigorIPPBX 3510 Series User’s Guide...
  • Page 128 Do not make a loop with many filter sets. To edit Filter Rule, click the Filter Rule index button to enter the Filter Rule setup page. Check to enable the Check this box to enable the filter rule. Filter Rule VigorIPPBX 3510 Series User’s Guide...
  • Page 129 From the IP Group drop down list, choose the one that you want to apply. Or use the IP Object drop down list to choose the object that you want. Service Type Click Edit to access into the following dialog to choose a suitable service type. VigorIPPBX 3510 Series User’s Guide...
  • Page 130 Block Immediately - Packets matching the rule will be dropped immediately. Pass Immediately - Packets matching the rule will be passed immediately. Block If No Further Match - A packet matching the rule, and that does not match further rules, will be dropped. VigorIPPBX 3510 Series User’s Guide...
  • Page 131 SysLog For troubleshooting needs you can specify the filter log and/or CSM log here. Check the corresponding box to enable the log function. Then, the filter log and/or CSM log will be shown on Draytek Syslog window. Advance Setting Click Edit to open the following window. However, it is strongly recommended to use the default settings here.
  • Page 132 TCP protocol only; session timeout is configured for the data flow which matched with the firewall rule. DrayTek Banner – Please uncheck this box and the following screen will not be shown for the unreachable web page. The default setting is Enabled.
  • Page 133 Each filter set is composed by 7 filter rules, which can be further defined. After that, in General Setup you may specify one set for call filter and one set for data filter to execute first. VigorIPPBX 3510 Series User’s Guide...

  • Page 134: Dos Defense

    Check the box to activate the ICMP flood defense function. Similar defense to the UDP flood defense function, once if the Threshold of ICMP packets from Internet has exceeded the defined value, the router will discard the ICMP echo requests coming from the Internet. The VigorIPPBX 3510 Series User’s Guide...
  • Page 135 Check the box to activate the Block Ping of Death function. This attack involves the perpetrator sending overlapping packets to the target hosts so that those target hosts will hang once they re-construct the packets. The Vigor routers will block any packets realizing this attacking activity. VigorIPPBX 3510 Series User’s Guide...
  • Page 136 All the warning messages related to DoS Defense will be sent to user and user can review it through Syslog daemon. Look for the keyword DoS in the message, followed by a name to indicate what kind of attacks is detected. VigorIPPBX 3510 Series User’s Guide...

  • Page 137: Objects Settings

    You can set up to 192 sets of IP Objects with different conditions. Set to Factory Default Clear all profiles. Click the number under Index column for settings in detail. Name Type a name for this profile. Maximum 15 characters are allowed. VigorIPPBX 3510 Series User’s Guide...
  • Page 138 Type the subnet mask if the Subnet Address type is selected. Invert Selection If it is checked, all the IP addresses except the ones listed above will be applied later while it is chosen. Below is an example of IP objects settings. VigorIPPBX 3510 Series User’s Guide...

  • Page 139: Ip Group

    Available IP Objects All the available IP objects with the specified interface chosen above will be shown in this box. Selected IP Objects Click >> button to add the selected IP objects in this box. VigorIPPBX 3510 Series User’s Guide...

  • Page 140: Service Type Object

    Specify the protocol(s) which this profile will apply to. Source/Destination Port Source Port and the Destination Port column are available for TCP/UDP protocol. It can be ignored for other protocols. The filter rule will filter out any port number. VigorIPPBX 3510 Series User’s Guide...

  • Page 141: Service Type Group

    Below is an example of service type objects settings. This page allows you to bind several service types into one group. Set to Factory Default Clear all profiles. Click the number under Index column for settings in detail. VigorIPPBX 3510 Series User’s Guide...

  • Page 142: Keyword Object

    You can set 200 keyword object profiles for choosing as black /white list in CSM >>URL Web Content Filter Profile. Set to Factory Default Clear all profiles. Click the number under Index column for setting in detail. VigorIPPBX 3510 Series User’s Guide...

  • Page 143: Keyword Group

    This page allows you to bind several keyword objects into one group. The keyword groups set here will be chosen as black /white list in CSM >>URL Web Content Filter Profile. Set to Factory Default Clear all profiles. Click the number under Index column for setting in detail. VigorIPPBX 3510 Series User’s Guide...

  • Page 144: File Extension Object

    Profile 1 with name of “default” is the default profile, some files with the file extensions specified in this profile will be ignored and not be scanned by Vigor router. Set to Factory Default Clear all profiles. Click the number under Profile column for configuration in details. VigorIPPBX 3510 Series User’s Guide...

  • Page 145: Csm

    It is similar situation for corporation towards peer-to-peer applications since file-sharing can be convenient but insecure at the same time. To address these needs, we provide CSM functionality. VigorIPPBX 3510 Series User’s Guide...
  • Page 146 Please note that this action will not introduce any delay in your Web surfing because each of multiple load balanced database servers can handle millions of requests for categorization. Note: The priority of URL Content Filter is higher than Web Content Filter. VigorIPPBX 3510 Series User’s Guide...

  • Page 147: App Enforcement Profile

    Click the number under Index column for settings in detail. There are four tabs IM, P2P, Protocol and Misc displayed on this page. Each tab will bring out different items that you can choose to disallow people using. VigorIPPBX 3510 Series User’s Guide...
  • Page 148 Select All Click it to choose all of the items in this page. The profiles configured here can be applied in the Firewall>>General Setup and Firewall>>Filter Setup pages as the standard for the host(s) to follow. VigorIPPBX 3510 Series User’s Guide...
  • Page 149 Below shows the items which are categorized under P2P. The items categorized under Protocol ----- VigorIPPBX 3510 Series User’s Guide...
  • Page 150 The items categorized under Misc ----- VigorIPPBX 3510 Series User’s Guide...

  • Page 151: Url Content Filter Profile

    Click CSM and click URL Content Filter Profile to open the profile setting page. You can set eight profiles as URL content filter. Simply click the index number under Profile to open the following web page. VigorIPPBX 3510 Series User’s Guide...
  • Page 152 None – There is no log file will be recorded for this profile. Pass – Only the log about Pass will be recorded in Syslog. Block – Only the log about Block will be recorded in Syslog. VigorIPPBX 3510 Series User’s Guide...
  • Page 153 32-character long. After specifying keywords, the Vigor router will decline the connection request to the website whose URL string matched to any user-defined keyword. It should be noticed that the more simplified the blocking VigorIPPBX 3510 Series User’s Guide...
  • Page 154 File Extension Profile – Choose one of the profiles that you configured in Object Setting>> File Extension Objects previously for passing or blocking the file downloading. VigorIPPBX 3510 Series User’s Guide...

  • Page 155: Web Content Filter Profile

    Activate to satisfy your request. Be aware that service provider matching with VigorIPPBX 3510 currently offers a period of time for trial version for users to experiment. If you want to purchase a formal edition, simply contact with the channel partner or your dealer.
  • Page 156 By the way, you can click the link of Test a site to verify whether it is categorized to access into the test server selected. Find more Click it to open http://myvigor.draytek.com for searching another qualified and suitable server. Click this link to do the verification.
  • Page 157 All of the configuration made for web content filter will be deleted automatically. Therefore, please backup your data before you change the web content filter license. Profile Name Type a name for such profile. VigorIPPBX 3510 Series User’s Guide...
  • Page 158 Block - restrict accessing into the corresponding webpage with the categories listed on the box below. If the web pages do not match with the specified feature set here, it will be processed with reverse action. VigorIPPBX 3510 Series User’s Guide...

  • Page 159: Bandwidth Management

    Limitation List Displays a list of specific limitations that you set on this web page. Start IP Defines the start IP address for limit session. End IP Defines the end IP address for limit session. VigorIPPBX 3510 Series User’s Guide...

  • Page 160: Bandwidth Limit

    Click this button to activate the function of limit bandwidth. Subnet – if bandwidth limit function is enabled, Apply to 2 please check this box to apply to second subnet. Disable Click this button to close the function of limit bandwidth. VigorIPPBX 3510 Series User’s Guide...

  • Page 161: Quality Of Service

    IP header. For instance, to ensure the connection with the headquarter, a teleworker may enforce an index of QoS Control to reserve bandwidth for HTTPS connection while using lots of application at the same time. VigorIPPBX 3510 Series User’s Guide...
  • Page 162 Edit link to access into next for configuration. You can configure general setup for the WAN interface, edit the Class Rule, and edit the Service Type for the Class Rule for your request. VigorIPPBX 3510 Series User’s Guide...
  • Page 163 Enable the QoS Control The factory default for this setting is checked. Please also define which traffic the QoS Control settings will apply to. IN- apply to incoming traffic only. OUT-apply to outgoing traffic only. VigorIPPBX 3510 Series User’s Guide...
  • Page 164 Edit link of that one. After you click the Edit link, you will see the following page. Now you can define the name for that Class. In this case, “Test” is used as the name of Class Index #1. VigorIPPBX 3510 Series User’s Guide...
  • Page 165 For Subnet Address, you have to fill in Start IP address and Subnet Mask. DiffServ CodePoint All the packets of data will be divided with different levels and will be processed according to the level type by the VigorIPPBX 3510 Series User’s Guide...
  • Page 166 To add a new service type, edit or delete an existed service type, please click the Edit link under Service Type field. After you click the Edit link, you will see the following page. VigorIPPBX 3510 Series User’s Guide...
  • Page 167 Range as the type. By the way, you can set up to 40 service types. If you want to edit/delete an existed service type, please select the radio button of that one and click Edit/Delete for modification. VigorIPPBX 3510 Series User’s Guide...

  • Page 168: Applications

    Set to Factory Default Clear all profiles and recover to factory settings. Enable Dynamic DNS Setup Check this box to enable DDNS function. Auto-Update interval Set the time for the router to perform auto update for DDNS service. VigorIPPBX 3510 Series User’s Guide...
  • Page 169 Click OK button to activate the settings. You will see your setting has been saved. The Wildcard and Backup MX features are not supported for all Dynamic DNS providers. You could get more detailed information from their websites. VigorIPPBX 3510 Series User’s Guide...

  • Page 170: Schedule

    You can set up to 15 schedules. Then you can apply them to your Internet Access or VPN and Remote Access >> LAN to LAN settings. To add a schedule, please click any index, say Index No. 1. The detailed settings of the call schedule with index 1 are shown below. VigorIPPBX 3510 Series User’s Guide...
  • Page 171 Assign these two profiles to the PPPoE Internet access profile. Now, the PPPoE Internet connection will follow the schedule order to perform Force On or Force Down action according to the time plan that has been pre-defined in the schedule profiles. VigorIPPBX 3510 Series User’s Guide...

  • Page 172: Radius

    The RADIUS server and client share a secret that is used to authenticate the messages sent between them. Both sides must be configured to use the same shared secret. Confirm Shared Secret Re-type the Shared Secret for confirmation. VigorIPPBX 3510 Series User’s Guide...

  • Page 173: Upnp

    NAT router. The application will also learn the external IP address and configure port mappings on the router. Subsequently, such a facility forwards packets from the external ports of the router to the internal ports used by the application. VigorIPPBX 3510 Series User’s Guide...
  • Page 174 Non-privileged users can control some router functions, including removing and adding port mappings. The UPnP function dynamically adds port mappings on behalf of some UPnP-aware applications. When the applications terminate abnormally, these mappings may not be removed. VigorIPPBX 3510 Series User’s Guide...

  • Page 175: Igmp

    Click this link to renew the working multicast group status. If you check Enable IGMP Proxy, you will get the following page. All the multicast groups will be listed and all the LAN ports (P1 to P4) are available for use. VigorIPPBX 3510 Series User’s Guide...

  • Page 176: Wake On Lan

    MAC Address Type any one of the MAC address of the binded PCs. Wake Up Click this button to wake up the selected IP. See the following figure. The result will be shown on the box. VigorIPPBX 3510 Series User’s Guide...

  • Page 177: Vpn And Remote Access

    Enable the necessary VPN service as you need. If you intend to run a VPN server inside your LAN, you should disable the VPN service of Vigor Router to allow VPN tunnel pass through, as well as the appropriate NAT settings, such as DMZ or open port. VigorIPPBX 3510 Series User’s Guide...

  • Page 178: Ppp General Setup

    Cisco routers. So you should enable this function when your peer router requires mutual authentication. You should further specify the User Name and Password of the mutual authentication peer. VigorIPPBX 3510 Series User’s Guide...

  • Page 179: Ipsec General Setup

    IKE Authentication Method This usually applies to those are remote dial-in user or node (LAN-to-LAN) which uses dynamic IP address and IPSec-related VPN connections such as L2TP over IPSec VigorIPPBX 3510 Series User’s Guide...

  • Page 180: Ipsec Peer Identity

    Click each index to edit one peer digital certificate. There are three security levels of digital signature authentication: Fill each necessary field to authenticate the remote peer. The following explanation will guide you to fill all the necessary fields. VigorIPPBX 3510 Series User’s Guide...
  • Page 181 Click to check the specific fields of digital signature to accept the peer with matching value. The field includes Country (C), State (ST), Location (L), Organization (O), Organization Unit (OU), Common Name (CN), and Email (E). VigorIPPBX 3510 Series User’s Guide...

  • Page 182: Remote Dial-In User

    Click each index to edit one remote user profile. Each Dial-In Type requires you to fill the different corresponding fields on the right. If the fields gray out, it means you may leave it untouched. The following explanation will guide you to fill all the necessary fields. VigorIPPBX 3510 Series User’s Guide...
  • Page 183 ISDN number or peer ID (used in IKE aggressive mode). Uncheck the checkbox-This means the connection type you select above will apply the authentication methods and security methods in the general settings. VigorIPPBX 3510 Series User’s Guide...
  • Page 184 Data Encryption Standard (DES), Triple DES (3DES), and AES. Local ID - Specify a local ID to be used for Dial-in setting in the LAN-to-LAN Profile setup. This item is optional and can VigorIPPBX 3510 Series User’s Guide...

  • Page 185: Lan To Lan

    4 subgroups. If the fields gray out, it means you may leave it untouched. The following explanations will guide you to fill all the necessary fields. For the web page is too long, we divide the page into several sections for explanation. VigorIPPBX 3510 Series User’s Guide...
  • Page 186 WAN2 Only - While connecting, the router will use WAN2 as the only channel for VPN connection. Netbios Naming Packet Pass – click it to have an inquiry for data transmission between the hosts located on both sides of VPN Tunnel while connecting. VigorIPPBX 3510 Series User’s Guide...
  • Page 187 Build a L2TP VPN connection through the Internet. You can select to use L2TP alone or with IPSec. Select from below: None: Do not apply the IPSec policy. Accordingly, the VPN connection employed the L2TP without IPSec policy can be VigorIPPBX 3510 Series User’s Guide...
  • Page 188 AES with Authentication-Use AES encryption algorithm and apply MD5 or SHA-1 authentication algorithm. Advanced Specify mode, proposal and key life of each IKE phase, Gateway etc. The window of advance setup is shown as below: VigorIPPBX 3510 Series User’s Guide...
  • Page 189 The length of the ID is limited to 47 characters. Index (1-15) in Schedule Enter the index of schedule profiles to control the call barring according to the preconfigured schedules. Refer to section Application>>Schedule for detailed configuration. VigorIPPBX 3510 Series User’s Guide...
  • Page 190 If you uncheck the checkbox, the connection type you select above will apply the authentication methods and security methods in the general settings. User Name This field is applicable when you select PPTP or L2TP with or without IPSec policy above. VigorIPPBX 3510 Series User’s Guide...
  • Page 191 VPN connection. This is usually used when you find there are several subnets behind the remote VPN router. RIP Direction The option specifies the direction of RIP (Routing Information Protocol) packets. You can enable/disable one of direction VigorIPPBX 3510 Series User’s Guide...

  • Page 192: Connection Management

    Tool and clicking Dial button. Dial Click this button to execute dial out function. Refresh Seconds Choose the time for refresh the dial information among 5, 10, and 30. Refresh Click this button to refresh the whole connection status. VigorIPPBX 3510 Series User’s Guide...

  • Page 193: Certificate Management

    Remember to adjust the time of Vigor router before using the certificate so that you can get the correct valid period of certificate. Below shows the menu items for Certificate Management. Generate Click this button to open Generate Certificate Request window. VigorIPPBX 3510 Series User’s Guide...
  • Page 194 Refresh Click this button to refresh the information listed below. View Click this button to view the detailed settings for certificate request. After clicking Generate, the generated information will be displayed on the window below: VigorIPPBX 3510 Series User’s Guide...

  • Page 195: Trusted Ca Certificate

    For viewing each trusted CA certificate, click View to open the certificate detail information window. If you want to delete a CA certificate, choose the one and click Delete to remove all the certificate information. VigorIPPBX 3510 Series User’s Guide...

  • Page 196: Certificate Backup

    CALL center to be a multi-functional communication platform. Moreover, it can save large cost in communication for the enterprise. This menu can assist users to configure most of settings in IP PBX. Below shows menu items for IP PBX: VigorIPPBX 3510 Series User’s Guide...

  • Page 197: Extension

    There are 100 groups of extension numbers that you can configure. Please click any number under Index to set detailed configuration. Note: The items listed under Outgoing Call will be changed according to the module(s) inserted into the device. VigorIPPBX 3510 Series User’s Guide...
  • Page 198 PPTP remote dial-in authentication account. E-mail Address Type an e-mail address to receive media (voice) file sent by incoming calls. Send a test e-mail: Click this button to send a test e-mail to VigorIPPBX 3510 Series User’s Guide...
  • Page 199 There are several outside lines (SIP accounts) for you to specify for such extension. Please check the one(s) you want. The available boxes listed here will be changed according to the FXS/FXO module inserted to VigorIPPBX 3510. Answer Mode Specify the way to process incoming phone calls.

  • Page 200: Line Setting

    Trunk Number Display the short number for such account. Status Display current status for the account (successful registration or failed registration). Alias List Allows you to set sub accounts for the main accounts in SIP Trunk. VigorIPPBX 3510 Series User’s Guide...
  • Page 201 SIP Authorization with SIP Registrar. If this setting value is the same as Account Name, it is not necessary for you to check the box and set any value in this field. VigorIPPBX 3510 Series User’s Guide...
  • Page 202 Extension or Group directly. Non-office hours answer Set the answering mode for such outside line in non-office time. You can specify it with Auto Attendant (AA), or mode forward it to any Extension or Group directly. VigorIPPBX 3510 Series User’s Guide...
  • Page 203 You can set 50 profiles as alias for SIP Trunk list. Click the number under Index to set detailed configuration. Active Click Enable to activate this entry. Or, click Disable to inactive this entry. Alias Type a name for such account. VigorIPPBX 3510 Series User’s Guide...
  • Page 204 Group Display the name of each entry. Trunk Number Display the default trunk number of each entry. Active V – means current trunk number is available. PSTN Trunk Auto Hunt Display the default value. VigorIPPBX 3510 Series User’s Guide...
  • Page 205 You can specify it with Auto Attendant (AA), or forward it to any Extension or Group directly. Outgoing Call Use There are several outside lines (SIP accounts) for you to specify for such extension. Please check the one(s) you want. VigorIPPBX 3510 Series User’s Guide...

  • Page 206: Dial Plan

    The available boxes listed here will be changed according to the FXS/FXO module inserted to VigorIPPBX 3510. For the convenience of user, this page allows users to edit prefix number for the SIP account with adding number, stripping number or replacing number. It is used to help user having a quick and easy way to dial out through VoIP interface.
  • Page 207 SIP accounts. Please set up one SIP account first to make this route available. This item will be changed according to the port settings configured in IP PBX>>PBX System>>Phone Settings and IP PBX>>Line Settings>>SIP Trunk. VigorIPPBX 3510 Series User’s Guide...
  • Page 208 Phone Number Type the complete phone number (maximum 19) for the client that you want to dial out. Route Choose the interface (from VoIP 1 to VoIP 6) for the phone call to dial out. VigorIPPBX 3510 Series User’s Guide...
  • Page 209 Click any index number to display the dial plan setup page. Enable Click this to enable this entry. Call Direction Determine the direction for the phone call, IN – incoming call, OUT-outgoing call, IN & OUT – both incoming and VigorIPPBX 3510 Series User’s Guide...
  • Page 210 Block Unknown Domain. Simply click the relational links to open the web page. For Block Anonymous – this function can block the incoming calls without caller ID on the interface specified in the following window. Such controlling also can be done based on preconfigured schedules. VigorIPPBX 3510 Series User’s Guide...

  • Page 211: Pbx System

    For Block Unknown Domain – this function can block incoming calls from unrecognized domain that is not specified in SIP accounts. Such controlling also can be done based on preconfigured schedules. This page allows you to set relational (advanced) settings for IP PBX device. VigorIPPBX 3510 Series User’s Guide...
  • Page 212 101; the extension 102~105 can just dial *1# to pickup the call. However, if the extension 106 wants to pickup that call, it needs to dial *1101#. RTP Local Port Start/ If your VoIP service provider gave you such information, VigorIPPBX 3510 Series User’s Guide...
  • Page 213 Group Name Display the name of such group. Group Extension Display the extension number of such group. Hunt List Display the members inside the group. Click any index number to display the hunt group setup page. VigorIPPBX 3510 Series User’s Guide...
  • Page 214 If you choose Forward to Group or Forward to Extension, a drop down box will appear for you to choose the extension / group to transfer to. VigorIPPBX 3510 Series User’s Guide...
  • Page 215 Click this button to clear all of the selections in Chosen area. Move Up Click this button to move the selected item to the upper place. Click this button to move the selected item to the lower Move Down place. VigorIPPBX 3510 Series User’s Guide...
  • Page 216 Check this box to authenticate the mail server. Authentication User Name Type a name for IP PBX to authenticate the mail server automatically while connecting. Password Type a password for IP PBX to authenticate the mail server automatically while connecting. VigorIPPBX 3510 Series User’s Guide...
  • Page 217 Specify date(s) for applying the office hour settings in Date holiday, for example, type 2,4 6 & 7 in the field of Date for Month 1. It means January 2,4,6 & 7 will apply the office hour settings configured in this page. VigorIPPBX 3510 Series User’s Guide...
  • Page 218 Click Next. The second page is configured for phone calls in non-office hours. Key 0-9 Key 0 – 9 can be set with different actions. Action Drop down menu contains Ring Extension /Plays Prompt/Ring Hunt Group/Not Used. VigorIPPBX 3510 Series User’s Guide...
  • Page 219 Drop down menu 2 contains extension name (ex. Tom, Mike)] or prompt [Prompt 1~ Prompt 10, audio files] or Hunt Group Name [(ex. Sales, RD2)]. It will be changed according to drop down menu 1. Finally, the following window will appear. VigorIPPBX 3510 Series User’s Guide...
  • Page 220 In general, it will be saved in the router’s memory after you record it. To back up the audio file(s) (saved in FLASH of the router) to your computer, please choose the one you want from the drop-down menu and click Back Up. VigorIPPBX 3510 Series User’s Guide...
  • Page 221 Type quit to close FTP client. 221 Goodbye! Router will be reboot now will appear and the router will reboot. Please follow the steps below to upload G.729 user Prompts to your router: VigorIPPBX 3510 Series User’s Guide...
  • Page 222 Please use DOS-BOX FTP client (Windows built-in FTP client utility) to login VigorIPPBX FTP server. Press Enter to pass authentication. Type get v3510_g729_userprompt.ivr. Wait for a while. The message of 226 File sent OK will appear. Type quit to close FTP client. VigorIPPBX 3510 Series User’s Guide...
  • Page 223 Congestion tone will be shown automatically on the page. If you cannot find out a suitable one, please choose User Defined and fill out the corresponding values for dial tone, ringing tone, busy tone, congestion tone by yourself for VoIP phone. VigorIPPBX 3510 Series User’s Guide...
  • Page 224 Region. Select the caller ID type for setting Dial tone, Ringing tone, Busy tone and Congestion tone respectively. This page allows user to set phone settings for FXS module. Click any index number link to open the following page for configuration. VigorIPPBX 3510 Series User’s Guide...
  • Page 225 (G.711a/u or G.726) to make sure FAX can transmit successfully. If this option is selected, the Vigor router will apply these two following settings (FAX Bypass Codec and FAX Bypass Codec Rate). VigorIPPBX 3510 Series User’s Guide...
  • Page 226 Codec Prefer Codec - Select one of five codecs as the default for your VoIP calls. The codec used for each call will be negotiated with the peer party before each session, and so may VigorIPPBX 3510 Series User’s Guide...
  • Page 227 There are several outside lines (SIP accounts) for you to specify for such extension. Please check the one(s) you want. The available boxes listed here will be changed according to the FXS/FXO module inserted to VigorIPPBX 3510. Answer Mode Specify the way to process incoming phone calls.
  • Page 228 Click Browse button in the field of Restoration to choose the correct configuration file for uploading to the router. Click Restore button and wait for few seconds, the following picture will tell you that the restoration procedure is successful. VigorIPPBX 3510 Series User’s Guide...

  • Page 229: Pbx Status

    Each page will display 50 records. CDR Export Click the Export button to export the call detail records as a file. Refresh Click it to reload the page. VigorIPPBX 3510 Series User’s Guide...

  • Page 230: Usb Application

    Vigor router, please make sure the memory format for the USB storage disk is FAT16 or FAT32. It is recommended for you to use FAT32 for viewing the filename completely (FAT16 cannot support long filename). VigorIPPBX 3510 Series User’s Guide...
  • Page 231 23 characters. Both them cannot contain any of the following--- ; : " < > * + = \ | ?. Workgroup Name – Type a name for the workgroup. Host Name – Type the host name for the router. VigorIPPBX 3510 Series User’s Guide...

  • Page 232: Usb User Management

    Note: “Admin” could not be typed here as username, for the word is specified for accessing into web pages of Vigor router only. Also, it is reserved for FTP firmware upgrade usage. Note: FTP Passive mode is not supported by Vigor Router. VigorIPPBX 3510 Series User’s Guide...
  • Page 233 Directory –Check the items (List, Create and Remove) for such profile. Before you click OK, you have to insert a USB storage disk into the USB interface of the Vigor router. Otherwise, you cannot save the configuration. VigorIPPBX 3510 Series User’s Guide...

  • Page 234: File Explorer

    Current Path Display current folder. Upload Click this button to upload the selected file to the USB storage disk. The uploaded file in the USB storage disk can be shared for other user through FTP. VigorIPPBX 3510 Series User’s Guide...

  • Page 235: Usb Disk Status

    When you insert USB storage disk into the Vigor router, the system will start to find out such device within several seconds. Such page provides real-time syslog and displays the information on the screen. VigorIPPBX 3510 Series User’s Guide...
  • Page 236 Display the information for each event. This page displays the syslog recorded on the USB storage disk. Time Display the time of the event occurred. Log Type Display the type of the record. Message Display the information for each event. VigorIPPBX 3510 Series User’s Guide...

  • Page 237: System Maintenance

    Display the IP address of the LAN interface. Subnet Mask Display the subnet mask address of the LAN interface. DHCP Server Display the current status of DHCP server of the LAN interface. Display the assigned IP address of the primary DNS. VigorIPPBX 3510 Series User’s Guide...
  • Page 238 Display the connection type. IP Address Display the IP address of the WAN interface. Default Gateway Display the assigned IP address of the default gateway. SIP Trunk/PBX System------- Index/Profile/Status Display current status for SIP profiles. VigorIPPBX 3510 Series User’s Guide...

  • Page 239: 231

    CPE. Periodic Inform Settings The default setting is Enable. Please set interval time or schedule time for the router to send notification to CPE. Or click Disable to close the mechanism of notification. VigorIPPBX 3510 Series User’s Guide...

  • Page 240: Administrator Password

    This page allows you to backup current configuration as a file. To backup or restore the configuration of the router, please download the Firmware Upgrade Utility from DrayTek website first. Run the firmware upgrade utility. You will see a dialog as the following figure. VigorIPPBX 3510 Series User’s Guide...

  • Page 241: Syslog/Mail Alert

    Click the browse button to get the IP address of VigorIPPBX 3510. Then you can specify which operation (Upgrade, Backup Setting, or Restore) you want to perform for the router. Finally click the bottom right button (e.g., Send in the above figure) to perform the operation.
  • Page 242 For viewing the Syslog, please do the following: Just set your monitor PC’s IP address in the field of Server IP Address Install the Router Tools in the Utility within provided CD. After installation, click on the Router Tools>>Syslog from program menu. VigorIPPBX 3510 Series User’s Guide...
  • Page 243 From the Syslog screen, select the router you want to monitor. Be reminded that in Network Information, select the network adapter used to connect to the router. Otherwise, you won’t succeed in retrieving information from the router. VigorIPPBX 3510 Series User’s Guide...

  • Page 244: Time And Date

    Type the IP address of the time server. Time Zone Select the time zone where the router is located. Automatically Update Interval Select a time interval for updating from the NTP server. Click OK to save these settings. VigorIPPBX 3510 Series User’s Guide...

  • Page 245: Management

    Subnet Mask - Represent a subnet mask allowed to login to the router. Default Ports Check to use standard port numbers for the Telnet and HTTP servers. User Defined Ports Check to specify user-defined port numbers for the VigorIPPBX 3510 Series User’s Guide...

  • Page 246: Reboot System

    Note: When the system pops up Reboot System web page after you configure web settings, please click OK to reboot your router for ensuring normal operation and preventing unexpected errors of the router in the future. VigorIPPBX 3510 Series User’s Guide...

  • Page 247: Firmware Upgrade

    For the detailed information about firmware update, please refer to 4.5 Upgrade Firmware for VigorIPPBX 3510 for detailed operation. There are three ways to activate WCF on vigor router, using Service Activation Wizard, by means of CSM>>Web Content Filter Profile or via System Maintenance>>Activation.
  • Page 248 CT-CF) adopted by such router. Start Date Display the starting date of WCF license activated successfully. Expire Date Display the ending date of WCF license activated successfully. Activate Click this link to access into http://myvigor.draytek.com for activating WCF function. VigorIPPBX 3510 Series User’s Guide...

  • Page 249: Diagnostics

    (e.g., ISDN, PPPoE, PPPoA, etc) is triggered by a package sending from the source IP address. Decoded Format It shows the source IP address (local), destination IP (remote) address, the protocol and length of the package. Refresh Click it to reload the page. VigorIPPBX 3510 Series User’s Guide...

  • Page 250: Routing Table

    Resolution Protocol) cache held in the router. The table shows a mapping between an Ethernet hardware address (MAC Address) and an IP address. Refresh Click it to reload the page. Clear Click it to clear the whole table. VigorIPPBX 3510 Series User’s Guide...

  • Page 251: Dhcp Table

    Click Diagnostics and click NAT Sessions Table to open the setup page. Private IP:Port It indicates the source IP address and port of local PC. #Pseudo Port It indicates the temporary port of the router used for NAT. VigorIPPBX 3510 Series User’s Guide...

  • Page 252: Ping Diagnosis

    Type in the IP address of the Host/IP that you want to ping. Click this button to start the ping work. The result will be displayed on the screen. Clear Click this link to remove the result on the window. VigorIPPBX 3510 Series User’s Guide...

  • Page 253: Data Flow Monitor

    TX rate (kbps) Display the transmission speed of the monitored device. RX rate (kbps) Display the receiving speed of the monitored device. Sessions Display the session number that you specified in Limit Session web page. VigorIPPBX 3510 Series User’s Guide...

  • Page 254: Traffic Graph

    The remaining time will be shown on the session column. Click Diagnostics and click Traffic Graph to pen the web page. Choose WAN1 Bandwidth, Sessions, daily or weekly for viewing different traffic graph. Click Refresh to renew the graph at any time. VigorIPPBX 3510 Series User’s Guide...

  • Page 255: Trace Route

    Choose a protocol (ICMP or UDP) for such route. Host/IP Address It indicates the IP address of the host. Click this button to start route tracing work. Clear Click this link to remove the result on the window. VigorIPPBX 3510 Series User’s Guide...
  • Page 256 This page is left blank. VigorIPPBX 3510 Series User’s Guide...

  • Page 257: Chapter 6: Trouble Shooting

    Turn on the router. Make sure the ACT LED blink once per second and the correspondent LAN LED is bright. If not, it means that there is something wrong with the hardware status. Simply back to “1.3 Hardware Installation” to execute the hardware installation again. And then, try again. VigorIPPBX 3510 Series User’s Guide...
  • Page 258 Go to Control Panel and then double-click on Network Connections. Right-click on Local Area Connection and click on Properties. Select Internet Protocol (TCP/IP) and then click Properties. VigorIPPBX 3510 Series User’s Guide...
  • Page 259 Double click on the current used Mac OS on the desktop. Open the Application folder and get into Network. On the Network screen, select Using DHCP from the drop down list of Configure IPv4. VigorIPPBX 3510 Series User’s Guide...

  • Page 260: Pinging The Router From Your Computer

    Open the Application folder and get into Utilities. Double click Terminal. The Terminal window will appear. Type ping 192.168.1.1 and press [Enter]. If the link is OK, the line of “64 bytes from 192.168.1.1: icmp_seq=0 ttl=255 time=xxxx ms” will appear. VigorIPPBX 3510 Series User’s Guide...

  • Page 261: Checking If The Isp Settings Are Ok Or Not

    Open Internet Access page and then check whether the ISP settings are set correctly. Check if the Enable option is selected. Check if Username and Password are entered with correct values that you got from your ISP. VigorIPPBX 3510 Series User’s Guide...
  • Page 262 Static IP setting that you got from your ISP. Check if the Enable option for PPTP Link is selected. Check if PPTP Server, Username, Password and WAN IP address are set correctly (must identify with the values from your ISP). VigorIPPBX 3510 Series User’s Guide...

  • Page 263: Backing To Factory Default Setting If Necessary

    If the router still cannot work correctly after trying many efforts, please contact your dealer for further help right away. For any questions, please feel free to send e-mail to support@draytek.com. VigorIPPBX 3510 Series User’s Guide...
  • Page 264 VigorIPPBX 3510 Series User’s Guide...

  • Page 265: Appendix: Hardware Specifications

    Operating : 0°C ~ 45°C Storage : -25°C ~ 70°C Humidity 10% ~ 90% ( non-condensing ) Max. Power Consumption 50 Watt (Max) Dimension L443 * W280.5 * H44 ( mm ) Power 100-240V, 50-60Hz, 1.0/0.5A VigorIPPBX 3510 Series User’s Guide...

Table of Contents
