The temperature can be changed at any time after this step by pressing the Temp/Time or Temp/Hour "up" or "down" arrow pads. Start
does not need to be pressed again. If baking/roasting while the Timer is counting down, the set baking/roasting temperature can be
displayed for 5 seconds by pressing Bake.
3. Press OFF/CANCEL or CANCEL/OFF when finished.
BROILER
The broiler is located below the oven door. Use an oven rack for broiling. To remove a rack, pull it out to the stop position, raise the front
edge, then lift out. Reverse the steps to replace a rack. Always broil with both the broiler and the oven doors closed.
■To avoid damage to the broiler, do not step on or apply weight to the broiler door while it is open.
■ Preheat the broiler before use. Completely close broiler door during broiling.
■ Do not use broiler cavity for storage.
■ Broiling uses direct radiant heat to cook food. Changing the temperature when broiling allows more precise control when cooking. The
lower the temperature, the slower the cooking. Thicker cuts and unevenly shaped pieces of meat, fish and poultry may cook better at lower
broiling temperatures
■ For best results, use a broiler pan and grid. It is designed to drain juices and help avoid spatter and smoke.
To Broil:
1. Open the broiler door and pull the rack out to the stop position.
2. Place food on a grid in a broiler pan, then place it in the center of the oven rack.
3. Push the oven rack back to the original position. Close the door to ensure proper broiling temperature.
4. Press BROIL. The BROIL indicator light will light up.
5. Press START. The indicator light will light up. The temperature setting can be changed at any time during broiling. If broiling while the
Timer is counting down, the set broiling temperature can be displayed for 5 seconds by touching BROIL.
6. Press OFF/CANCEL or CANCEL/OFF when finished broiling.

Range Care and cleaning

Your range is designed and manufactured to last many years of service, however, it´s very important to provide care and cleaning to keep
your appliance in good conditions.
Care recommendations:
Follow these recommendations:
Cooktop

Don't leave the burners of your cooktop ON for long periods of time.

Don't put a lot of weight the grates on the cooktop with overloaded cookware. The maximum load is 20 kgs.

Avoid dropping the grates over the cooktop, don't drop cookware over the grates.
Oven door

Never use the oven door as a step to reach a cabinet or high locations, an accident may happen.

Close the oven door gently, otherwise you could damage the oven sealings and therefore reduce the performance of the oven.

Don't try to remove or disassemble the oven door for any reason.

Don't allow the children to play around the range.

General cleaning

It's very important to keep your range clean to keep an optimum performance, follow these recommendations for cleaning:

Before cleaning the range, make sure all the controls are in the off position and make sure the cooktop and oven are cold. Always
follow the instructions of the cleaning products.

Unless otherwise is noted, we recommend to use water, soap and a soft cloth or a sponge to clean the range.

Don't use caustic soda or cleaning products with this ingredient to clean the range. If you don't follow this direction, permanent
damage may occur to the surfaces cleaned with this product.
Enamel Grates (in some models)
The food splashing that contains acids, like vinegar and tomato should be cleaned as soon as the cooktop, grates
and caps are cold. This splashing may damage the finish.
To avoid cracks and chips, don't hit the grates against the caps or against any hard surface like stainless steel
cookware.
Cleaning Method:

Use non abrasive scouring pad and mild abrasive liquid cleaner.

Clean as soon as the grates are cold.
Cooktop burners
Before cleaning, make sure all the controls are off and the oven and cooktop are cold. Don't use oven cleaners, bleach or oxide removers.
Control knob
09-May-2014 18:21:12 EDT | RELEASED
DON'T USE DISHWASHER TO WASH THE GRATES.
In some European factories the letter "W" of the part code mentioned herein will be automatically
replaced by the number "4000" (e.g. "W12345678" becomes "400012345678")
