Panasonic 1740 Specifications

•
Controller for the Alert Annunciation function
•
Compact size
Alert annunciation controller
When the Alert Annunciation (AA) function
shall be used in system EBL500. The unit is
required for the related manoeuvres, i.e. to
acknowledge / reset the alarms.
For a detailed description of the Alert
Annunciation function, see system EBL500
Planning and Operating Instructions.
The unit shall be mounted close to the c.i.e.
(or an ext. FBP / Presentation unit) where
the fire alarms will be presented.
LEDs, push buttons etc.
The designation texts for the LEDs and push
buttons on the front are in Swedish.
The unit has the following LEDs:
•
Larm, indicating fire / AA alarm.
•
Drift, indicating that the unit is in
operation, i.e. the AA function is
enabled in the system. Normally a time
channel is used to enable this function.
•
Räddningstjänsten larmad, indicating
that the "Fire brigade tx" output is
activated in the c.i.e. because:
- the activated fire alarm is not an AA
alarm
- the AA function has been ended, e.g.
the acknowledge or investigation time
has run out, etc.
•
Kvittering, indicating that the AA alarm
has been acknowledged.
The unit has the following push buttons:
•
Kvittering, used to acknowledge an AA
alarm.
•
Återställning, used to reset an AA
alarm.
Panasonic Electric Works Fire & Security Technology Europe AB
Citadellsvägen 23, SE-211 18 Malmö, Sweden
Tel: +46 (0)40 697 70 00 • Fax: +46 (0)40 697 70 99
info@mfstech.com • www.panasonic-fire-security.com
Fire alarm systems

Alert annunciation

controller 1740
Compact size
The compact size enclosure is made of grey
high impact ABS. Fitted with a supple-
mentary "O" ring gasket, it will comply with
IP61, in respect of dust and moisture. The
unit has no door, i.e. the front is accessed
directly, when required. The push buttons
are disabled until they are supposed to be
used. The unit shall be wall mounted.
Miscellaneous
The LED "Kvittering" (Acknowledge) can
be turned on by the push button
"Kvittering" (Acknowledge) or by an
input, i.e. a programmable output in the
c.i.e. This is set via a jumper "JP1" in the
unit.
The unit is power supplied from the c.i.e.
or an external power supply.
One supplementary compression gland
can be used for cable entry when required.
Product application
1740 is intended to be used in the fire alarm
system EBL500 but can be used in the
systems EBL1000 / 2000 / 512 / 128 as well.
The 1740 controller is intended to succeed
the alert annunciation controller 2232.
