FVS124G ProSafe VPN Firewall 25 Reference Manual
Table 1-2. FVS124G rear panel (continued)
Item
Description
WAN Ports
Two RJ-45 WAN ports, N-way automatic speed negotiation, Auto MDI/MDIX.
(Internet ports)
AC Power
12 VDC, 1.2A
Adapter
Connection
Router IP Address, Login Name, and Password
You need the address, login name and password to set up the Router. Check the label on the bottom
of the FVS124G enclosure if you forget the following factory default information:
•
IP Address: http://192.168.1.1 to reach the Web-based GUI from the LAN
•
User name: admin
•
Password: password
LAN IP Address
User Name
Password
Figure 1-3
Logging into the Router
To log into the FVS124G once it is connected:
1-8
v1.0, January 2007
