NETGEAR FVS124G Reference Manual

Prosafe vpn firewall 25 with 4 gigabit lan and dual wan ports
Hide thumbs Also See for FVS124G:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Reference Manual, Configuration Manual
This chapter describes the features of the NETGEAR ProSafe VPN Firewall 25 with 4 Gigabit
LAN and Dual WAN Ports.

Key Features of the VPN Firewall

The ProSafe VPN Firewall 25 with 4 Gigabit LAN and Dual WAN Ports with 4 port switch
connects your local area network (LAN) to the Internet through an external access device such as a
cable modem or DSL modem.
The FVS124G is a complete security solution that protects your network from attacks and
intrusions. Unlike simple Internet sharing firewalls that rely on Network Address Translation
(NAT) for security, the FVS124G uses Stateful Packet Inspection for Denial of Service (DoS)
attack protection and intrusion detection. The VPN Firewall provides you with multiple Web
content filtering options, plus browsing activity reporting and instant alerts—both via e-mail.
Network administrators can establish restricted access policies based on time-of-day, Website
addresses and address keywords.
With minimum setup, you can install and use the firewall within minutes.
The VPN Firewall provides the following features:
•
Two 10/100 Mbps ports for an Ethernet connection to a WAN device, such as a cable modem
or DSL modem.
•
Dual WAN ports that provide for increased system reliability and load balancing.
•
Support for up to 10 VPN tunnels.
•
Easy, web-based setup for installation and management.
•
URL keyword Content Filtering and Site Blocking Security.
•
Quality of Service (QoS) support for traffic prioritization.
•
Built in 4-port 10/100/1000 Mbps switch.
•
Extensive Protocol Support.
•
Login capability.
•
Front panel LEDs for easy monitoring of status and activity.
v1.0, January 2007
Chapter 1
Introduction
1-1

Advertisement

Table of Contents
loading

Related Manuals for NETGEAR FVS124G

Summary of Contents for NETGEAR FVS124G

  • Page 1: Chapter 1 Introduction

    Chapter 1 Introduction This chapter describes the features of the NETGEAR ProSafe VPN Firewall 25 with 4 Gigabit LAN and Dual WAN Ports. Key Features of the VPN Firewall The ProSafe VPN Firewall 25 with 4 Gigabit LAN and Dual WAN Ports with 4 port switch connects your local area network (LAN) to the Internet through an external access device such as a cable modem or DSL modem.

  • Page 2: Dual Wan Ports For Increased Reliability Or Outbound Load Balancing

    • Virtual Private Networks (VPNs). A Powerful, True Firewall with Content Filtering Unlike simple Internet sharing NAT routers, the FVS124G is a true firewall, using stateful packet inspection to defend against hacker attacks. Its firewall features include: • DoS protection. Automatically detects and thwarts DoS attacks such as Ping of Death, SYN Flood, LAND Attack, and IP Spoofing.

  • Page 3: Autosensing Ethernet Connections With Auto Uplink

    Autosensing Ethernet Connections with Auto Uplink With its internal 4-port 10/100/1000 switch, the FVS124G can connect to either a 10 Mbps standard Ethernet network, a 100 Mbps Fast Ethernet network, or a 1000 Mbps Gigabit Ethernet.

  • Page 4: Easy Installation And Management

    • VPN Wizard The VPN Firewall includes the NETGEAR VPN Wizard to easily configure VPN tunnels according to the recommendations of the Virtual Private Network Consortium (VPNC) to ensure the VPN tunnels are interoperable with other VPNC-compliant VPN routers and clients.

  • Page 5: Maintenance And Support

    • Warranty and Support Information Card. If any of the parts are incorrect, missing, or damaged, contact your NETGEAR dealer. Keep the carton, including the original packing materials, in case you need to return the firewall for repair. v1.0, January 2007...

  • Page 6: Router Front Panel

    FVS124G ProSafe VPN Firewall 25 Reference Manual Router Front Panel The ProSafe VPN Firewall 25 with 4 Gigabit LAN and Dual WAN Ports front panel shown below Figure 1-1 contains the port connections, status LEDs, and the factory defaults reset button.

  • Page 7: Router Rear Panel

    FVS124G ProSafe VPN Firewall 25 Reference Manual Table 1-1. FVS124G front panel (continued) Object Activity Description Gigabit LAN Link/Act LED Port LEDs On (Green) The LAN port has detected a link with a connected Ethernet device. Blinking (Green) Data is being transmitted or received by the LAN port.

  • Page 8: Router Ip Address, Login Name, And Password

    Router IP Address, Login Name, and Password You need the address, login name and password to set up the Router. Check the label on the bottom of the FVS124G enclosure if you forget the following factory default information: • IP Address: http://192.168.1.1 to reach the Web-based GUI from the LAN •...
  • Page 9 FVS124G ProSafe VPN Firewall 25 Reference Manual Open a Web browser and enter http://192.168.1.1 as the URL. Figure 1-4 Once you get the login screen, enter the following information: • admin for User Name • password for Password Note: Read-only access is provided by logging in as username guest and default password password.
  • Page 10 FVS124G ProSafe VPN Firewall 25 Reference Manual 1-10 v1.0, January 2007...
