- Page 1 BTM25.5SS 25 Litre combination microwave oven with grill Downloaded From Microwave-Manual.com Manuals...
- Page 2 User Manual for your Baumatic BTM25.5SS 25 Litre combination microwave oven with grill NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...
-
Page 3: Table Of Contents
The appliance exterior The appliance interior Turntable and turntable support General cleaning advice 28 - 29 Installation 29 – 31 Positioning Electrical connection 30 - 31 My appliance isn’t working correctly 31 – 32 Baumatic consumables Contact details Downloaded From Microwave-Manual.com Manuals... -
Page 4: Environmental Note
Environmental note o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. Downloaded From Microwave-Manual.com Manuals... -
Page 5: Important Safety Information
IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this ooklet, please contact the Baumatic Advice Line. - Page 6 If you notice that the door seal, door surfaces, power cord and plug are damaged. You s hould stop using the appliance, disconnect it from the mains supply and contact the Baumatic Customer Care Department. o Only genuine Baumatic spare parts should be fitted to your appliance.
- Page 7 Child Safety o Baumatic strongly recommend that babies and young children are prevented from being near to the appliance and not allowed to touch the appliance at any time. o If it is nece ssary for younger family members to be in the kitchen, please ensure that they are kept under close supervision at all times.
- Page 8 Baumatic Ltd. declines any respon sibility for injury or damage, to person or property, as a result of improper use or installation of this appliance. o Heat, steam and moisture will be created during use of the...
-
Page 9: Specifications
Specifications Product dimensions* Height: 305 mm Width: 513 mm Depth: 470 mm * Please refer to the installation instructions contained in this user manual, to see the ventilation gaps you will need to leave around the appliance. Product specifications 5 power levels 10 cooking functions: Auto-rehea Vegetables... -
Page 10: Description Of The Appliance
For future reference please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invo ice. The rating plate for your oven can be cated by opening the microwave oven door and looking on the right hand side of the chassis. -
Page 11: Control Panel
AYS be placed on the rotating plate during cooking. o If the rotating plate or rotating base cra cks or breaks, it must be replaced immediately. Genuine Baumatic parts can be obtained from the Baumatic Spares Department. Downloaded From Microwave-Manual.com Manuals... -
Page 12: Led Display
ED display The LED display will show the time of day, or if the microwave is in use, it will show the cooking time. Indicates that microwave cooking is taking place Indicates that convection cooking is taking place dicates that grilling is taking place Indicates that defrosting is taking place dicates that the safety lock is engaged Indicates that the auto menu function has been selected... -
Page 13: Using Your Microwave
Using your microw The adjustment dial o The adjustment dial (E) should only be turned clockwise (towards the book symbol) if you want to use the auto menu function. o For all other purposes and se ttings, the adjustment dial (E) should be turn ed anti-clockwise (towards the clock symbol). -
Page 14: Microwave Cooking
Microwave cooking o Once the clock has been set, your microwave is then ready to use. o Use the door button (F) to open the door of the microwave. o Check that the slot for the rotating base, the rotating base and the rotating plate correctly assembled in the cavity. -
Page 15: Microwave Power Level Chart
+ 30 second button (Quick start) o If you want to cook on the highest power level setting for a period of time, then you can use the +30 second button (D). o Press the +30 second button (D) once and your microwave will operate on full power for 30 seconds. -
Page 16: Grill Cooking
Grill cooking o Press the grill button (I) once and the LED display (A) will show “P100”. Turn the adjustment dial (E) or keep pressing the grill button (I) until “G-1” appears on the LED display. o Once “G-1” appears on the LED display (A), press the confirm button (D). -
Page 17: Combination Cooking
Combination cooking Press the combination button (I) once and the LED display (A) will show “P100”. o Turn the adjustment dial (E) or keep pressing the combination button (I) until “C-1”, “C-2”, “C-3” or “C-4” appears on the LED display (see the table below to see the various combination cooking modes that can be selected). -
Page 18: Convection Cooking
Convection cooking o Convection cooking allows you to operate your microwave like a traditional oven. Th e appliance does not use microwaves to cook the food and the cavity should be preheated before food is placed inside of it. o Use the door button (F) to open the door of the microwave. o Place whatever you are cooking in the centre of the microwave cavity and then close the microwave door. -
Page 19: Interrupting A Cooking Cycle
o Press the start button (D) and the microwave will start to pre- heat the oven cavity to the temperature that you have selected. o Once the r equired temperature inside the oven cavity has been reached, an audible signal will sound twice and the LED display will flash. -
Page 20: Cancelling A Cooking Cycle
Cancelling a cooking cycle o If you wish to cancel a cooking cycle when it is in progress, you should press the stop/clear button (E). o The m icrowave will stop heating immediately, give an audible signal and the LED display (A) will return to showing the time of day. -
Page 21: Defrost By Time
Defrost by time o Press the defrost by weight/time button (H) twice and the LED display (A) will show “dEF2”. o Turn the adjustment dial (E) to set the defrost time that you require. o Press the start button (D) and your microwave will start to defrost the food. -
Page 22: Kitchen Timer Mode
Kitchen timer mode his allows you to set a countdown time of up to 95 minutes when the appliance is not in any cooking mode. IMPORTANT: You must make sure that the appliance is not in any cooking mode before trying to use kitchen timer mode. o Press the clock/kitchen timer button (G) twice and the LED display will show 00.00. -
Page 23: Auto Menu Function
Auto menu function o Your microwave has menus pre-programmed into it, where it will cook particular types of food on pre-set power levels and for pre- set periods of time. o Turn the adjustment dial (E) clockwise to access the auto menu function, the LED display (A) will show “A-1”. -
Page 24: Auto Menu Chart
Auto menu chart Auto Weight Display Power menu level 150 g 100% Reheat 250 g 350 g 450 g 600 g 1 (about 230 g) 100% Potato 2 (about 460 g) 3 (about 690 g) 150 g 100% Meat 300 g 450 g 600 g 150 g... -
Page 25: Safety Lock
Safety lock o When the microwave is not heating, it is possible to switch on the safety lock. o Press and hold down the stop/clear button (C) for 3 seconds. o The microwave will emit a long audible signal and the LED display (A) will display a padlock symbol. -
Page 26: Materials You Can Use In A Microwave Oven
o You should not use ceramic or porcelain crockery, or porous earthenware inside of your microwave. Thes e dishes could absorb moisture from the food whilst it is cooking, which could cause pressure to build up and shatter the dish. o If you are heating certain foods and any liquid, moisture will evaporate and condensation may occur. -
Page 27: Materials Not To Be Placed In A Microwave Oven
Plastic Microwave-safe only. Follow manufacturer’s instructions. It should be labelled as “microwave safe”. Some plastic containers soften as the food inside gets hot. “Boil ing bags” and tightly closed plastic bags should be slit, pierced or vented, as described by the package. -
Page 28: Cleaning And Maintenance
Combination mode applies to microwave + grill and microwave + convection modes. Cleaning and maintenance Cleaning operations must only be carried out when the oven is cool. The appl iance should be disconnected from your mains supply before commencing any cleaning process. -
Page 29: Installation
Any damage that is caused to the appliance by a cleaning product will not be fixed by Baumatic free of charge, even if the appliance is within the guarantee period. Install tion IMPORTANT:... -
Page 30: Electrical Connection
lectrical connection o Before connecting the appliance, make sure that the supply voltage marked rating plate corresponds with your mains supply voltage. o We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C. E.I.C. -
Page 31: My Appliance Isn't Working Correctly
Baumatic Customer Care Department. o The interior light bulb is not working. * Call the Baumatic Customer Care De partment. The interior light bulb can only be replaced by a trained service technician. o My food is not cooking properly. - Page 32 Or any installation other than the one specified by Baumatic Ltd. has been completed. Please refer to the conditions of guarantee that appear on the...
-
Page 33: Baumatic Consumables
BC005 Stainless Steel Cleaner and Protector (250 ml) o BC007 E-Cloth – General Purpose Cloth o BC008 Microwave Cover o order a Baumatic consumable product please call 0123 5437 244 nd quote the product code. You can also order online from shop.baumatic.co.uk... -
Page 34: Contact Details
Czech Republic United Kingdom Baumatic CR spol s .r.o. Baumatic Ltd., ìpovà 665 Baumatic Buildings, 460 01 Lib erec 4 6 Bennet Road, Czech Republic Reading, Berkshire RG2 0QX +420 483 577 200 United Kingdom atic.cz www.baum Sales Telephone Slovakia... - Page 35 Downloaded From Microwave-Manual.com Manuals...
- Page 36 Downloaded From Microwave-Manual.com Manuals...
