25 litre combination microwave oven with grill (36 pages)
Summary of Contents for Baumatic BTM25.5SS
Page 1
BTM25.5SS 25 Litre combination microwave oven with grill...
Page 2
User Manual for your Baumatic BTM25.5SS 25 Litre combination microwave oven with grill NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...
Environmental note o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment.
IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Baumatic Advice Line.
Page 6
You should stop using the appliance, disconnect it from the mains supply and contact the Baumatic Customer Care Department. o Only genuine Baumatic spare parts should be fitted to your appliance. These can be obtained from the Baumatic Spares Department.
Page 7
Child Safety o Baumatic strongly recommend that babies and young children are prevented from being near to the appliance and not allowed to touch the appliance at any time. o If it is necessary for younger family members to be in the kitchen, please ensure that they are kept under close supervision at all times.
Page 8
Baumatic Ltd. declines any responsibility for injury or damage, to person or property, as a result of improper use or installation of this appliance. o Heat, steam and moisture will be created during use of the appliance, take care to avoid injury and ensure that the room is adequately ventilated.
Specifications Product dimensions* Height: 305 mm Width: 513 mm Depth: 470 mm * Please refer to the installation instructions contained in this user manual, to see the ventilation gaps you will need to leave around the appliance. Product specifications o 5 power levels o 10 cooking functions: Auto-reheat Vegetables...
For future reference please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice. The rating plate for your oven can be located by opening the microwave oven door and looking on the right hand side of the chassis.
All food and food containers must ALWAYS be placed on the rotating plate during cooking. o If the rotating plate or rotating base cracks or breaks, it must be replaced immediately. Genuine Baumatic parts can be obtained from the Baumatic Spares Department.
LED display o The LED display will show the time of day, or if the microwave is in use, it will show the cooking time. Indicates that microwave cooking is taking place Indicates that convection cooking is taking place Indicates that grilling is taking place Indicates that defrosting is taking place Indicates that the safety lock is engaged Indicates that the auto menu function has been selected...
Using your microwave The adjustment dial o The adjustment dial (E) should only be turned clockwise (towards the book symbol) if you want to use the auto menu function. o For all other purposes and settings, the adjustment dial (E) should be turned anti-clockwise (towards the clock symbol).
Microwave cooking o Once the clock has been set, your microwave is then ready to use. o Use the door button (F) to open the door of the microwave. o Check that the slot for the rotating base, the rotating base and the rotating plate correctly assembled in the cavity.
+ 30 second button (Quick start) o If you want to cook on the highest power level setting for a period of time, then you can use the +30 second button (D). o Press the +30 second button (D) once and your microwave will operate on full power for 30 seconds.
Grill cooking o Press the grill button (I) once and the LED display (A) will show “P100”. o Turn the adjustment dial (E) or keep pressing the grill button (I) until “G-1” appears on the LED display. o Once “G-1” appears on the LED display (A), press the confirm button (D).
Combination cooking o Press the combination button (I) once and the LED display (A) will show “P100”. o Turn the adjustment dial (E) or keep pressing the combination button (I) until “C-1”, “C-2”, “C-3” or “C-4” appears on the LED display (see the table below to see the various combination cooking modes that can be selected).
Convection cooking o Convection cooking allows you to operate your microwave like a traditional oven. The appliance does not use microwaves to cook the food and the cavity should be preheated before food is placed inside of it. o Use the door button (F) to open the door of the microwave. o Place whatever you are cooking in the centre of the microwave cavity and then close the microwave door.
o Press the start button (D) and the microwave will start to pre- heat the oven cavity to the temperature that you have selected. o Once the required temperature inside the oven cavity has been reached, an audible signal will sound twice and the LED display will flash.
Cancelling a cooking cycle o If you wish to cancel a cooking cycle when it is in progress, you should press the stop/clear button (E). o The microwave will stop heating immediately, give an audible signal and the LED display (A) will return to showing the time of day.
Defrost by time o Press the defrost by weight/time button (H) twice and the LED display (A) will show “dEF2”. o Turn the adjustment dial (E) to set the defrost time that you require. o Press the start button (D) and your microwave will start to defrost the food.
Kitchen timer mode This allows you to set a countdown time of up to 95 minutes when the appliance is not in any cooking mode. o IMPORTANT: You must make sure that the appliance is not in any cooking mode before trying to use kitchen timer mode. o Press the clock/kitchen timer button (G) twice and the LED display will show 00.00.
Auto menu function o Your microwave has menus pre-programmed into it, where it will cook particular types of food on pre-set power levels and for pre- set periods of time. o Turn the adjustment dial (E) clockwise to access the auto menu function, the LED display (A) will show “A-1”.
Auto menu chart Auto Weight Display Power menu level 150 g 100% Reheat 250 g 350 g 450 g 600 g 1 (about 230 g) 100% Potato 2 (about 460 g) 3 (about 690 g) 150 g 100% Meat 300 g 450 g 600 g 150 g...
Safety lock o When the microwave is not heating, it is possible to switch on the safety lock. o Press and hold down the stop/clear button (C) for 3 seconds. o The microwave will emit a long audible signal and the LED display (A) will display a padlock symbol.
o You should not use ceramic or porcelain crockery, or porous earthenware inside of your microwave. These dishes could absorb moisture from the food whilst it is cooking, which could cause pressure to build up and shatter the dish. o If you are heating certain foods and any liquid, moisture will evaporate and condensation may occur.
Plastic Microwave-safe only. Follow manufacturer’s instructions. It should be labelled as “microwave safe”. Some plastic containers soften as the food inside gets hot. “Boiling bags” and tightly closed plastic bags should be slit, pierced or vented, as described by the package.
* Combination mode applies to microwave + grill and microwave + convection modes. Cleaning and maintenance Cleaning operations must only be carried out when the oven is cool. The appliance should be disconnected from your mains supply before commencing any cleaning process.
Any damage that is caused to the appliance by a cleaning product will not be fixed by Baumatic free of charge, even if the appliance is within the guarantee period. Installation...
Electrical connection o Before connecting the appliance, make sure that the supply voltage marked rating plate corresponds with your mains supply voltage. o We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply with the I.E.E.
Baumatic Customer Care Department. o The interior light bulb is not working. * Call the Baumatic Customer Care Department. The interior light bulb can only be replaced by a trained service technician. o My food is not cooking properly.
Page 32
Or any installation other than the one specified by Baumatic Ltd. has been completed. Please refer to the conditions of guarantee that appear on the...
BC005 Stainless Steel Cleaner and Protector (250 ml) o BC007 E-Cloth – General Purpose Cloth o BC008 Microwave Cover To order a Baumatic consumable product please call 0123 5437 244 and quote the product code. You can also order online from eshop.baumatic.co.uk...
