OPERATOR'S
MANUAL
OSCILLATING VERTICAL
SPINDLE SANDER
MODEL: OS-1414
Baileigh Industrial, Inc.
P.O. Box 531
Manitowoc, WI 54221-0531
Phone: 920.684.4990
Fax: 920.684.3944
sales@baileighindustrial.com
REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL, INC.
IS PROHIBITED. Baileigh Industrial, Inc. does not assume and hereby disclaims any liability for any damage or loss
caused by an omission or error in this Operator's Manual, resulting from accident, negligence, or other occurence.
Rev. 8/2012
© 2012 Baileigh Industrial, Inc.
Advertisement
Table of Contents
Related Manuals for Baileigh OS-1414
Summary of Contents for Baileigh OS-1414
- Page 1 REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL, INC. IS PROHIBITED. Baileigh Industrial, Inc. does not assume and hereby disclaims any liability for any damage or loss caused by an omission or error in this Operator’s Manual, resulting from accident, negligence, or other occurence.
-
Page 2: Table Of Contents
Table of Contents THANK YOU & WARRANTY ..................1 INTRODUCTION ......................3 GENERAL NOTES......................3 SAFETY INSTRUCTIONS ....................4 SAFETY PRECAUTIONS ....................6 TECHNICAL SPECIFICATIONS ..................9 TECHNICAL SUPPORT ....................9 GETTING TO KNOW YOUR MACHINE ............... 10 OVERALL DIMENSIONS ....................10 INSTALLATION ...................... -
Page 3: Thank You & Warranty
THANK YOU & WARRANTY Thank you for your purchase of a machine from Baileigh Industrial. We hope that you find it productive and useful to you for a long time to come. Inspection & Acceptance. Buyer shall inspect all Goods within ten (10) days after receipt thereof. Buyer’s payment shall constitute final acceptance of the Goods and shall act as a waiver of the Buyer’s rights to inspect or... - Page 4 Baileigh Industrial makes every effort to ensure that our posted specifications, images, pricing and product availability are as correct and timely as possible. We apologize for any discrepancies that may occur. Baileigh Industrial reserves the right to make any and all changes deemed necessary in the course of business including but not limited to pricing, product specifications, quantities, and product availability.
-
Page 5: Introduction
After receiving your equipment remove the protective container. Do a complete visual inspection, and if damage is noted, photograph it for insurance claims and contact your carrier at once, requesting inspection. Also contact Baileigh Industrial and inform them of the unexpected occurrence. Temporarily suspend installation. -
Page 6: Safety Instructions
IMPORTANT PLEASE READ THIS OPERATORS MANUAL CAREFULLY It contains important safety information, instructions, and necessary operating procedures. The continual observance of these procedures will help increase your production and extend the life of the equipment. SAFETY INSTRUCTIONS LEARN TO RECOGNIZE SAFETY INFORMATION This is the safety alert symbol. - Page 7 PROTECT EYES Wear safety glasses or suitable eye protection when working on or around machinery. DUST HAZARD Wear appropriate dust mask. Dust created while using machinery can cause cancer, birth defects, and long term respiratory damage. Be aware of the dust hazards associated with all types of materials.
-
Page 8: Safety Precautions
PROTECT AGAINST NOISE Prolonged exposure to loud noise can cause impairment or loss of hearing. Wear suitable hearing protective devices such as ear muffs or earplugs to protect against objectionable or uncomfortable loud noises. HIGH VOLTAGE USE CAUTION IN HIGH VOLTAGE AREAS. DO NOT assume the power to be off. - Page 9 SAFETY PRECAUTIONS (cont.) 5. Remove any adjusting tools. Before operating the machine, make sure any adjusting tools have been removed. 6. Keep work area clean. Cluttered areas invite injuries. 7. Feed Rate. Never jam a piece part against the sanding surface. This can cause the piece part to kick back causing personal injury or damage to the machine.
- Page 10 SAFETY PRECAUTIONS (cont.) 20. DO NOT bypass or defeat any safety interlock systems. 21. Know the location of the ON - OFF switch and the “E”- STOP button. 22. Keep visitors a safe distance from the work area. 23. Keep children away. Children must never be allowed in the work area. DO NOT let them handle machines, tools, or extension cords.
-
Page 11: Technical Specifications
TECHNICAL SPECIFICATIONS 14.6” x 4.6” (370 x 370mm) Table Size (L x W) Table Tilt 0~45° Spindle Speed 1400rpm Oscillations 24/min .94” (24mm) Oscillation Stroke 5.5” (141mm) Sanding Sleeve Length 3.15” (80mm) Maximum Workpiece Height 2” (50.8mm) Dust Port Diameter Motor .5 hp (0.37kw) 230V 60Hz/1ph 14.6”... -
Page 12: Getting To Know Your Machine
GETTING TO KNOW YOUR MACHINE Sanding Spindle Table Table Insert Cabinet Switch OVERALL DIMENSIONS... -
Page 13: Installation
INSTALLATION IMPORTANT: Maintain an adequate working area around the machine for safety. There should be 25” – 28” (635 – 710mm) in all directions around the machine. Have the work area well illuminated with proper lighting. Remove scrap and waste materials regularly, and make sure the work area is free from obstructing objects. -
Page 14: Electrical
Electrical CAUTION: HAVE ELECTRICAL UTILITIES CONNECTED TO MACHINE BY A CERTIFIED ELECTRICIAN! Check if the available power supply is the same as listed on the machine nameplate. WARNING: Make sure the grounding wire (green) is properly connected to avoid electric shock. Improper connection of the equipment-grounding conductor can result in a risk of electric shock. -
Page 15: Operation
OPERATION CAUTION: Always wear proper safety equipment such as eye protection with side shields, respirator, and hearing protection. 1. Select spindle that is smaller than the curve to be sanded. 2. Use an insert plate that comes closest to the spindle without touching it. 3. -
Page 16: Tilting The Table
Tilting the Table 1. Loosen the two table lock knobs (A), located under the table at both sides of the machine. 2. Tilt the table forward to the desired angle with your hands. 3. An angle scale is provided at the right side of the trunnion to indicate the degree of table tilt. -
Page 17: Selection Guide For Drum To Table Insert
SELECTION GUIDE FOR DRUM TO TABLE INSERT This machine is furnished with 10 drums. The range of drum diameter is from 1/4” to 4”. If the drum diameter is changed, the table insert needs to be changed to the proper size. WARNING: Failure to use the correct insert with the corresponding drum may result in injury. -
Page 18: Maintenance
MAINTENANCE WARNING: Make sure the electrical power is disconnected before working on the machine. Maintenance should be performed on a regular basis by qualified personnel. Always follow proper safety precautions when working on or around any machinery. Check daily for any unsafe conditions and fix immediately. ... -
Page 19: Troubleshooting
TROUBLESHOOTING WARNING: Make sure the electrical disconnect is OFF before working on the machine. TROUBLE CAUSES CORRECTION Switch is burned out. Replace the switch. Motor does not run when Connection wire is loose or T ighten or replace the wire. power switch is turned “ON”. -
Page 20: Parts Diagram 1
PARTS DIAGRAM 1... -
Page 21: Parts Diagram 2
PARTS DIAGRAM 2... -
Page 22: Parts List
PARTS LIST Item Part No. DISCRIPTION Qty. 30201001G BASE 101a 30201001a TOP PLATE W0000000 SWITCH S1006P1 STRAIN RELIEF L000000 POWER CORD S0030622M PHILIPS HEAD SCREW 10107098 RUBBER FEET S0210403 FLAT WASHER S0011600M HEX. NUT S00303040 PHILIPS HEAD SCREW S0030318 PHILIPS HEAD SCREW S0220300 GEAR WASHER S0110300... - Page 23 Item Part No. DISCRIPTION Qty. 30202006p BRACKET 30202007p WORM S0010615M HEX. SOCKET CAP SCREW 30202008P SHAFT 30204010 CRANK SHAFT S0230400 SPRING WASHER S0400415 C1106001 BEARING S0521200 C RING S0530028 C RING S0230506 SPRING WASHER S0210500C FLAT WASHER 30202009 OIL CAP 30202012 STORAGE PLATE FOR DRUMS 30202013...
- Page 24 Item Part No. DISCRIPTION Qty. S0030505M PHILIPS HEAD SCREW S0520027 C RING 30203008 5/8" SANDING SPINDLE S0400550 30203015 2" RUBBER BUSHING 30203014 1-1/2" RUBBER BUSHING 30203017 1/2" SANDING SPINDLE 30203018 1/4" SANDING SPINDLE 30203019 1/2" CLAMP 30203021 2" SANDING SLEEVE 30203010 1/4"...
- Page 25 NOTES...
- Page 26 NOTES...
- Page 27 NOTES...
- Page 28 , WI 54220 UFEK RIVE ANITOWOC : 920. 684. 4990 F : 920. 684. 3944 HONE BAILEIGHINDUSTRIAL BAILEIGH INDUSTRIAL, INC. 1455 S. C , CA 91761 AMPUS VENUE NTARIO : 920. 684. 4990 F : 920. 684. 3944 HONE BAILEIGH INDUSTRIAL LTD. U...
