Instruction Manual
T
ECHNICAL INFORMATION
Models No.
Description
C
ONCEPTION AND MAIN APPLICATIONS
New series of 125mm (5") angle grinders are equipped with
"Super Joint System-SJS" for protection of user and machine
from the shock by accidental spindle lock.
9562C and 9565C are equipped with electronic feature for
constant speed, current limiting and soft start, beside
"Super Joint System-SJS".
9562CV and 9565CV are equipped with electronic
speed control, in addition to the features of 9562C and 9565C.
S
pecification
Model No.
110V 120V 220V 230V 240V
9562
9565
8.6
9562C/CV
9565C/CV
Specifications
Wheel size : mm ( " )
No load speed
: (min
= rpm)
-1
"Super joint system-S J S"
Current limiter
Speed control dial
Electronic
Soft starter
Constant speed
Cord length : m ( ft )
Net weight :Kg (lbs )
S
tandard equipment
* Grip 36 complete ............................ 1 pc.
* Lock nut wrench 20 ........................ 1 pc.
* Depressed center wheel 125-36........ 1 pc.
< Note > The standard equipment for the tool shown may differ from country to country.
O
ptional accessories
* Depressed center wheel 125-24, 36
* Rubber pad 115
* Lock nut 14-48
* Dust collection wheel guard
* Abrasive disc 125-24,30,50,120
* Wire cup brush set 90 mm
* Wheel cover for wire cup brush 90 mm set
* Inner flange 47 assembly
* Diamond wheel 125
9562, 9565, 9562C, 9562CV,9565C, 9565CV
Angle grinder 125mm (5")
Current (A)
7.0
3.8
3.7
3.5
7.9
4.3
4.1
3.9
9.6
5.3
5.0
4.8
12.0
6.7
6.4
6.1
Model No.
9562
Diameter
Hole diameter
Thickness
North America
Other countries
No
No
No
No
H
W
Model No.
Width ( W )
Height ( H )
Length ( L )
Continuous Rating (W)
Cycle (Hz)
Input
800
50 / 60
50 / 60
900
1,100
50 / 60
50 / 60
1,400
9562CV
9562C
125 ( 5 )
22.23 ( 7/8 )
6 ( 1/4 )
10,500
2,800 -10,500
11,000
2,800 -11,000
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
2.5 (8.2)
1.7 (3.7)
L
Dimensions : mm ( " )
9565, C, CV
9562, C, CV
139 (5-1/2)
139 (5-1/2)
103 (4)
103 (4)
289 (11-3/8)
Output
Max. Output(W)
480
1,000
540
1,300
1,600 (120V)
660
1,800 (220 - 240V)
2,000 (120V)
840
2,400 (220 - 240V)
9565
9565C
10,500
2,800 -10,500
2,800 -11,000
11,000
No
Yes
No
No
No
Yes
Yes
No
1.8 (4.0)
PRODUCT
P 1 / 10
299 (11-3/4)
9565CV
Yes
Yes
Yes
Yes
