Lyric Installation
APPLICATION
Use the THP2400A1019 wall cover assembly with the Lyric™ thermostat.
Use the THP2400A1019 wall cover assembly to cover marks on the wall or to mount the thermostat to a 2 in. x 4 in.
electrical box.
The THP2400A1019 wall cover assembly contains one wall cover, one bracket, two #6-32 x 5/8" flat head screws and
two #6-32 x 3/8" pan head screws. See Fig. 1.
INSTALLATION
When Installing this Product...
1. Read these instructions carefully. Failure to follow them could damage the product or cause a hazardous
condition.
2. Check ratings given in the instructions and on the product to make sure the product is suitable for your
application.
3. Installer must be a trained, experienced service technician.
4. After installation is complete, check out product operation as provided in these instructions.
6-3/8 (162)
3/4
(19)
TWO #6-32 X 3/8 PAN HEAD SCREWS
TWO #6-32 X 5/8 FLAT HEAD SCREWS
Fig. 1. THP2400A1019 wall cover assembly.
INSTALLATION GUIDE
BRACKET
M35406
33-00069EFS-01
Advertisement
Related Manuals for Honeywell Lyric
Summary of Contents for Honeywell Lyric
-
Page 1: Installation Guide
Lyric Installation INSTALLATION GUIDE APPLICATION Use the THP2400A1019 wall cover assembly with the Lyric™ thermostat. Use the THP2400A1019 wall cover assembly to cover marks on the wall or to mount the thermostat to a 2 in. x 4 in. electrical box. - Page 2 LYRIC INSTALLATION CAUTION Electrical Hazard. Can cause electrical shock or equipment damage. Disconnect power before beginning installation. Mount Wall Cover Mount Wall Cover Directly to Wall (See Fig. 2) 1. Pull the wires through the wire hole on the wall cover.
- Page 3 LYRIC INSTALLATION Mount Wall Cover to a Vertical 2 in. X 4 in. Electrical Box (See Fig. 3) 1. Position the bracket on the electrical box with the arrow pointing up. Insert two #6-32 X 5/8" flat head screws. Level the bracket and tighten the flat head screws.
- Page 4 Fig. 4. Mount bracket, wall cover, wall plate and thermostat to a horizontal 2 in. X 4 in. electrical box. Automation and Control Solutions Honeywell International Inc. 1985 Douglas Drive North ® U.S. Registered Trademark Golden Valley, MN 55422 © 2015 Honeywell International Inc. 33-00069EFS—01 M.S. 02-15 customer.honeywell.com Printed in United States...
-
Page 5: Guide D'installation
GUIDE D’INSTALLATION APPLICATION Utiliser l'ensemble de plaques THP2400A1019 avec le thermostat Lyric™. Utiliser l'ensemble de plaques THP2400A1019 pour couvrir les marques laissées sur le mur ou pour installer le thermostat dans une boîte électrique de 2 po x 4 po. - Page 6 LYRIC INSTALLATION MISE EN GARDE Risque de choc électrique. Peut provoquer des chocs électriques ou endommager le matériel. Couper l'alimentation électrique avant d'effectuer le raccordement. Installation de la plaque de recouvrement Installer le couvercle mural directement au mur (voir la Fig. 2) 1.
- Page 7 LYRIC INSTALLATION Installer le couvercle mural sur une boîte électrique de 2 po x 4 po en position verticale (voir la Fig. 3) 1. Placer le support sur la boîte électrique avec la flèche pointée vers le haut. Insérer deux vis #6-32 X 5/8 à tête plate.
- Page 8 Fig. 4. Installation sur une boîte électrique de 2 po x 4 po en position horizontale. Solutions de régulation et d’automatisation Honeywell International Inc. 1985 Douglas Drive North ® Marque de commerce déposée aux États-Unis © 2015 Honeywell International Inc. Golden Valley, MN 55422 Tous droits réservés 33-00069EFS—01 M.S. 02-15 customer.honeywell.com...
-
Page 9: Guía De Instalación
GUÍA DE INSTALACIÓN APLICACIÓN Utilice el conjunto de la placa de pared THP2400A1019 con los termostatos Lyric™. Utilice el conjunto de la placa de pared THP2400A1019 para cubrir marcas en la pared o para instalar el termostato en un cajetín eléctrico de 2 in. x 4 in. (5,1 cm x 10,2 cm). - Page 10 INSTALACIÓN DE LYRIC PRECAUCIÓN Peligro eléctrico. Puede causar una descarga eléctrica o daños al equipo. Desconecte la energía antes de comenzar la instalación. Monte la placa de pared Monte la placa de pared directamente en la pared (Ver Fig. 2) 1.
- Page 11 INSTALACIÓN DE LYRIC Monte la placa de pared en un cajetín eléctrico vertical de 2 in. x 4 in. (5,1 cm x 10,2 cm) (Ver Fig. 3) 1. Coloque el soporte en el cajetín de electricidad con la flecha hacia arriba. Inserte dos tornillos de cabeza plana n.°...
- Page 12 2 in x 4 in (5.1 cm x 10.2 cm). Automatización y control desenlace Honeywell International Inc. 1985 Douglas Drive North ® Marca Registrada en los Estados Unidos © 2015 Honeywell International Inc. todos Golden Valley, MN 55422 Los Derechos Reservados 33-00069EFS—01 M.S. 02-15 customer.honeywell.com...
