NEC MultiSync FP1370 Service Manual page 28

SYMBOL PARTS No.
101 2E853031
102 2E853031
103 24851731
104 24852341
114 25283461
115 25284061
119 25283111
121 843E6C03
121 843E7C01
122 843E6B01
123 843E6D02
124 843E6A01
132 61322304
133 61322303
134 61322101
135 741X9741
136 741E9881
137 73891347
138 25534632
139 2E323932
140 2E457751
141 25430551
142 24N00301
143 33022503
145 2E548181
146 744E0351
147 24282111
148 25282131
149 73891360
150 73891333
155 73891362
156 744E0311
160 2E548061
162 744E0441
163 2E548141
164 2E548131
165 25280851
166 25281421
167 25282111
168 744E0431
169 741X4311
DESCRIPTION
CHEXIBS(CUP)*3*8*15CF
CHEXIBS(CUP)*3*8*15CF
SCREW,FT*4*16*15BF(S)
SCREW,WM*4*10*15CF(S)
EDGE SADDLE
CLAMPER,WIRE
CRAMPER WIRE (H19.5)
VIDEO PWB ASSY
VIDEO PWB ASSY
SUB PWB ASSY
DEF PWB ASSY
SW/HV PWB ASSY
COIL(50T,40H)
CORNER COIL(190T,50H)
DEGAUSSIING COIL(85T,10H)
LEAF SPRING(CRT)
LEAF SPRING
WIRE CONNECTOR CN-CE
COIL SPRING
CABINET FRONT ASSY
PUSH BUTTON(CONTROL)
CONTROL PANEL
WASHER(D20,D6.5,T2)
CRT M51LRY22X61
BRACKET(VIDEO.A)
PLATE,SHIELDING(VIDEO)
BUSHING,INSULATOR
EDGE SADDLE
WIRE CONNECTOR CN-SG
WIRE CONNECTOR CN-HT
WIRE CONNECTOR CN-CC
CASE,SHIELDING(CRT,F)
CHASSIS BASE
PLATE.SHIELDING(BOTTOM)
BRACKET(R.B)
BRACKET(L.B)
BUSHING,INSULATOR
PWB HOLDER
ANODE CLAMPER
PLATE.SHIELDING(BACK)
LEAF SPRING(CRT.B)
4-19
Qty REMARKS
54
05
06
01
01
04
01
01
01
01
01
01
01 EMF
02 EMC
01 DEG
08
02
01 CN-CE
02
01
01
01
04
01 CRT
01
01
03
03
01 CN-SG
01 CN-HT
01 CN-CC
01
01
01
01
01
02
04
01
01
01
