The Video Pwb Assy - NEC MultiSync FP1370 Service Manual

REMARK
Attach the CUSHION SHEET
on the SW/HV PWB ASSY.
REMARK
Clamp CN-P with the EDGE
SADDLE.
Screw the safety earth
terminal to the BRACKET
(VIDEO,A).
SAFETY
After the VIDEO PWB ASSY
mount the PWB FRAME,
connect the CN-SW1.
SYMBOL
175
SYMBOL
(*1)
104
4-9
