Panasonic S-24MF2U6 Operating Instructions Manual
Vrf system
Hide thumbs
Also See for S-24MF2U6:
- Installation instructions manual (64 pages) ,
- Operating instructions manual (9 pages) ,
- Installation instructions manual (60 pages)
Table of Contents
Advertisement
Quick Links
Model No.
Indoor Unit
Type
Indoor Unit Type
F2
Low Silhouette Ducted
Connectable outdoor unit lineup
This booklet is the operating instructions for indoor unit. Regarding the outdoor unit, see the operating
instructions supplied with the outdoor unit.
Outdoor Units
Type
Outdoor Unit Type
ME2 2WAY VRF System
MF1 3WAY VRF System
LE1 Mini VRF System
* Salt-Air Damage Resistant Specifications.
Before operating the unit, read these operating instructions thoroughly and keep them for future reference.
7
S-07MF2U6
S-09MF2U6
24
S-24MF2U6
S-36MF2U6
36
52
U-36LE1U6
U-52LE1U6
U-36LE1U6E*
U-52LE1U6E*
VRF System Air Conditioner
Nominal Capacity
9
12
S-12MF2U6
36
48
S-48MF2U6
Nominal Capacity
72
U-72ME2U9
U-96ME2U9
U-72MF1U9
U-96MF1U9
This air conditioner uses the refrigerant R410A.
Operating Instructions
15
S-15MF2U6
54
S-54MF2U6
96
120
U-120ME2U9
18
S-18MF2U6
144
U-144ME2U9
F569694
Advertisement
Table of Contents
Related Manuals for Panasonic S-24MF2U6
Summary of Contents for Panasonic S-24MF2U6
-
Page 1: Operating Instructions
Indoor Unit Type S-07MF2U6 S-09MF2U6 S-12MF2U6 S-15MF2U6 S-18MF2U6 Low Silhouette Ducted S-24MF2U6 S-36MF2U6 S-48MF2U6 S-54MF2U6 Connectable outdoor unit lineup This booklet is the operating instructions for indoor unit. Regarding the outdoor unit, see the operating instructions supplied with the outdoor unit. -
Page 2: Table Of Contents
CONTENTS Page PRODUCT INFORMATION ......................2 ALERT SYMBOLS.........................2 INSTALLATION LOCATION......................3 ELECTRICAL REQUIREMENTS ....................3 SAFETY INSTRUCTIONS......................3 OPERATION CONDITION ......................5 NAMES OF PARTS ........................6 Timer Remote Controller (Optional parts) ..................6 NOTE Refer to the Operating Instructions attached to the optional Timer Remote Controller. High-spec Wired Remote Controller (Optional parts)..............6 NOTE Refer to the Operating Instructions attached to the optional High-spec Wired Remote Controller. -
Page 3: Installation Location
INSTALLATION LOCATION • We recommend that this air conditioner be installed properly by qualified installation technicians in accordance with the Installation Instructions provided with the unit. • Before installation, check that the voltage of the electric supply in your home or office is the same as the voltage shown on the nameplate. - Page 4 • For safety, be sure to turn the air conditioner off and also to disconnect the power before cleaning or servicing. • Pull off the power plug from a receptacle, or switch off the breaker, or switch off the power disconnecting mean to isolate the air conditioner from the main power supply in case of emergency.
-
Page 5: Operation Condition
OPERATION CONDITION Use this air conditioner under the following temperature range. 3 way system Indoor Outdoor Temperature range (°F/°C) *DBT *WBT *DBT *WBT Max. 86/30 –/– 86/30 75/24 Heating & Cooling Min. 59/15 –/– 16/-8.8 14/-10 Max. 90/32 77/25 115/46 –/–... -
Page 6: Names Of Parts
NAMES OF PARTS INDOOR UNIT LOW SILHOUETTE DUCTED F2 type (standard static pressure) Bolt anchor* Air outlet duct* Suspension bolt* Air intake duct* Air outlet grille* Indoor unit Air intake grille* Ceiling material* * Field supplied Timer Remote Controller (Optional parts) Refer to the Operating Instructions NOTE attached to the optional Timer Remote... -
Page 7: Special Remarks
SPECIAL REMARKS ‘‘DRY’’ Operation How it works • Once the room temperature reaches the level that was set, the unit repeats the cycle of turning on and off automatically. • In order to prevent the humidity in the room from rising again, the indoor fan also turns off when the unit stops operating. -
Page 8: Care And Cleaning
CARE AND CLEANING 1. For safety, be sure to turn the air conditioner off and also to disconnect the power before cleaning. 2. Do not pour water on the indoor unit to clean it. This will damage the internal components and cause an electric shock hazard. Air intake and outlet side Clean the air intake and outlet side of the indoor unit with a vacuum cleaner brush, or wipe (Indoor unit) -
Page 9: Troubleshooting
TROUBLESHOOTING If your air conditioner does not work properly, first check the following points before requesting service. If it still does not work properly, contact your dealer or a service center. INDOOR UNIT Symptom Cause Noise Sound like streaming water during •... -
Page 10: Check Before Requiring Services
CHECK BEFORE REQUIRING SERVICES Symptom Cause Remedy Air conditioner does not run at Power failure or after power failure Press ON/OFF operation button on remote controller all although power is turned again. Operation button is turned off. • Switch on power if breaker is turned off. •... -
Page 11: Specifications
SPECIFICATIONS Low Silhouette Ducted (F2 type) Model Name S-07MF2U6 S-09MF2U6 S-12MF2U6 S-15MF2U6 S-18MF2U6 S-24MF2U6 Power Source 208 / 230 V, 60 Hz, 1PH BTU/h 7,500 9,600 12,000 15,000 19,000 25,000 Cooling Capacity BTU/h 8,500 11,000 14,000 17,000 21,000 27,000 Heating Capacity... - Page 12 © Panasonic Corporation 2014 F569694 Printed in China BE0414-10814...
