ECHNICAL INFORMATION
Models No.
Description
C
ONCEPT AND MAIN APPLICATIONS
BTW152 is a Cordless impact wrench powered by 14.4V/3.0Ah Li-ion battery BL1430.
Compact and lightweight, but powerful 4-pole DC Motor delivers strong torque of 200N.m
while reducing the tool's overall length and weight to 158mm (6-1/4") and 1.5kg (3.3lbs).
This product is available in the following variations:
Model No.
Charger
BTW152Z
BTW253RFE
DC18RA
This model also includes the accessories listed below in "Standard equipment".
Note: This model cannot use 14.4V/1.3Ah Li-ion battery BL1415.
S
pecification
Voltage: V
Capacity: Ah
Battery
Cell
Charging time: min.
Max output (W)
Driving shank
Standard bolt
Capacities
High tensile bolt
Impacts per min.: min.-
No load speed: min.-
Max. fastening torque*: N.m (in.lbs)
Electric brake
Variable speed control by trigger
Reverse switch
LED job light
Net weight** : kg (lbs)
*
Catalog value (torque at 6 seconds after seating, when fastening M16 high tensile bolt)
** Weight according to EPTA-Procedure 01/2003, with Battery BL1430
S
tandard equipment
Belt clip ................................... 1
Note: The standard equipment for the tool shown above may differ by country.
O
ptional accessories
Sockets
Extension bar
Universal joint
Bit adapter assembly
BTW152
Cordless Impact Wrench
Battery
Battery
type
quantity
cover
No
No
No
BL1430
2
=ipm
1
=rpm
1
Battery BL1430
Fast charger DC18RA
Charger DC18SD
Charger DC24SC
Plastic
Housing
carrying case
color
No
No
Makita-blue
1
Yes
3.0 (battery BL1430)
approx. 22 with DC18RA
12.7mm (1/2") Square
M8 - M16 (5/16 - 5/8")
M8 - M12 (5/16 - 1/2")
200 (1,770)
Offered to
Dimensions: mm (")
All countries
Length (L)
Width (W)
Height (H)*
*with Battery BL1430
14.4V
Li-ion
190
0 - 3,200
0 - 2,400
Yes
Yes
Yes
Yes
1.5 (3.3)
PRODUCT
P 1/10
158 (6-1/4)
79 (3-1/8)
234 (9-1/4)
