- Page 1 INSTRUCTION MANUAL Cordless Impact Wrench BTW152 009165 IMPORTANT: Read Before Using.
-
Page 2: Specifications
ENGLISH (Original instructions) SPECIFICATIONS Model BTW152 Standard bolt M12 - M16 Capacities High tensile bolt M8 - M12 Square drive 12.7 mm No load speed (min 0 - 2,400 Impacts per minute 0 - 3,200 Max. fastening torque 200 N.m... - Page 3 When operating a power tool outdoors, use an accessories, or storing power tools. Such extension cord suitable for outdoor use. Use of preventive safety measures reduce the risk of a cord suitable for outdoor use reduces the risk of starting the power tool accidentally. electric shock.
- Page 4 GEB049-2 Do not short the battery cartridge: Do not touch the terminals with any CORDLESS IMPACT WRENCH conductive material. SAFETY WARNINGS Avoid storing battery cartridge in a container with other metal objects such as Hold power tool insulated gripping nails, coins, etc. surfaces, when performing an operation where Do not expose battery cartridge to water the fastener may contact hidden wiring.
-
Page 5: Functional Description
Overloaded: • FUNCTIONAL DESCRIPTION The tool is operated in a manner that causes it to draw an abnormally high current. In this situation, release the trigger switch on CAUTION: the tool and stop the application that caused Always be sure that the tool is switched off and the •... -
Page 6: Operation
For socket without O-ring and pin NOTE: To install the socket, push it onto the anvil of the Use a dry cloth to wipe the dirt off the lens of lamp. • tool until it locks into place. Be careful not to scratch the lens of lamp, or it may To remove the socket, simply pull it off. -
Page 7: Maintenance
The fastening torque is affected by a wide variety of factors including the following. After fastening, always check the torque with a torque wrench. When the battery cartridge is discharged almost completely, voltage will drop and the fastening torque will be reduced. Socket Failure to use the correct size socket will cause •... -
Page 8: Optional Accessories
If you need any assistance for more details regarding 007458 these accessories, ask your local Makita Service Center. Raise the arm part of the spring and then place it in the Sockets •... - Page 12 Makita Corporation www.makita.com 884852B5...
