MOVE(P)
Operation:
X:<pp> D
S X:<pp>
#xxxx X:<pp>
Y:<pp> D
S Y:<pp>
#xxxx Y:<pp>
X:<pp> X:<ea>
X:<ea> X:<pp>
X:<pp> Y:<ea>
Y:<ea> X:<pp>
Y:<pp> X:<ea>
X:<ea> Y:<pp>
Y:<pp> Y:<ea>
Y:<ea> Y:<pp>
X:<pp> X:<Rn+xxxx>
X:<Rn+xxxx> X:<pp>
X:<pp> Y:<Rn+xxxx>
Y:<Rn+xxxx> X:<pp>
Y:<pp> X:<Rn+xxxx>
X:<Rn+xxxx> Y:<pp>
Y:<pp> Y:<Rn+xxxx>
Y:<Rn+xxxx> Y:<pp>
X:<pp> P:<ea>
P:<ea> X:<pp>
Y:<pp> P:<ea>
P:<ea> Y:<pp>
Description:
Move the word operand to or from the X and Y I/O peripherals. The 7-bit I/O Short Address is one extended
permitting access to the I/O peripheral addresses located in the highest 128 locations of the X and Y data
memories. All memory addressing modes may be used for the memory effective address. The Long Dis-
placement addressing mode may also be used.
If the system stack register SSH is specified as a source operand, the system stack pointer SP is postdec-
remented by 1 after SSH is read. If the system stack register SSH is specified as a destination operand,
A - 264
Move Peripheral Data
Assembler Syntax:
MOVE(P) X: pp, D
MOVE(P) S,X: pp
MOVE(P) #Data,X: pp
MOVE(P) Y: pp, D
MOVE(P) S,Y: pp
MOVE(P) #Data,Y: pp
MOVE(P) X: pp, X: ea
MOVE(P) X: ea, X: pp
MOVE(P) X: pp, Y: ea
MOVE(P) Y: ea, X: pp
MOVE(P) Y: pp, X: ea
MOVE(P) X: ea, Y: pp
MOVE(P) Y: pp, Y: ea
MOVE(P) Y: ea, Y: pp
MOVE(P) X: pp, X:(Rn+displacement)
MOVE(P) X:(Rn+displacement),X: pp
MOVE(P) X: pp, Y:(Rn+displacement)
MOVE(P) Y:(Rn+displacement),X: pp
MOVE(P) Y: pp, X:(Rn+displacement)
MOVE(P) X:(Rn+displacement),Y: pp
MOVE(P) Y: pp, Y:(Rn+displacement)
MOVE(P) Y:(Rn+displacement),Y: pp
MOVE(P) X: pp, P: ea
MOVE(P) P: ea, X: pp
MOVE(P) Y: pp, P: ea
MOVE(P) P: ea, Y: pp
