GE 15147 Instructions

http://waterheatertimer.org/GE-timers-and-manuals.html
Digital 6-Outlet
Yard Stake

Countdown Timer

Turns all outlets on at dusk & off at dawn or at the time you choose
Countdown 6-Outlet Yardstake is the perfect solution for automating decorative and seasonal lighting around your home. This handy combination
provides six grounded, rain-protected outlets in one convenient location, all controlled by an easy-to-use timer. This unit can be wall mounted or staked into
the ground. Perfect for decorative and seasonal lighting (not intended for permanent installation).
• Easy-to-program timer.
• Durable rain cover for outdoor use.
• Grounded for use with 3-wire plugs and outlets.
• 18 inch 14/3 SJTW outdoor cord.
FOR STAKE MOUNTING: Attach the stake to the timer by screwing both sections of the stake into the base of the unit.
FOR WALL MOUNTING: Two Keyholes are available for wall mounting. Mount at least 3 feet above the ground with the timer on top.
IN THE EVENT OF AN OVERLOAD: The circuit breaker will trip, shutting off power to the device. Remove the source of the overload and press the circuit
breaker to reset. Circuit breaker is located under the front cover.
ALWAYS OPERATE THE DEVICE WITH THE COVER CLOSED.
TIMER INSTRUCTIONS:
When the timer is plugged in, choose from the following functions by repeatedly pressing the green selection button until the desired function appears in
the LED display window:
• (F) - POWER OFF
• (O) - POWER ON
• (1-9)* - ON at dusk, OFF (1) to (9) hours later
• (d)* - ON at dusk, OFF at dawn
• (R)* - ON at dusk, OFF (1) to (9) hours randomly
*Cycles repeat every 24 hours
• There is a 20 second delay between the timer sensing dusk and turning on the light.
• There is a 2 minute delay between the timer sensing dawn and turning off the light.
• The delays prevent false starts/stops.
DO NOT PLUG IN MORE THAN THE RATED LOAD (SEE RATINGS).
To find total watts being used: if watts are not marked on the
appliance, multiply ampere rating (on nameplate) by 125 volts
to determine equivalent watts. For lamps with multiple bulbs, sum wattage on bulbs.
WARNING
Risk of electric shock
• Keep children away
• Plug directly into a GFCI protected electrical
outlet
• Unplug timer before cleaning
• Fully insert plug
• Do not use in wet locations
• Do not use damaged cord set
Risk of re
• Do not use to control appliances that contain
heating elements (cooking appliances, heaters,
irons, etc.)
• Do not exceed electrical ratings
Ratings:
125VAC 60Hz:
15A Resistive
10A Tungsten
Not rated for use with motors
15147
Outdoor
