Parts Guide - Sharp LC-40E67U Service Manual

PartsGuide
Note:
The reference numbers on the PWB
are arranged in alphabetical order.
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL MUDULE
[3] DUNTKE266FM02 (KEY Unit)
[4] DUNTKF030FM10(LC-40E67U)/
FM14 (LC-40E77U) (MAIN Unit)
[5] DUNTKF096FM01 (LED Unit)
Parts marked with "
parts with specified ones for maintaining the safety and performance of the set.

PARTS GUIDE

CONTENTS
" are important for maintaining the safety of the set. Be sure to replace these
LCD COLOR TELEVISION
LC-40E67U
LC-40E77U
MODELS
[6] CABINET AND MECHANICAL
PARTS
[7] LCD MODULE Assembly
[8] SUPPLIED ACCESSORIES
[9] PACKING PARTS (NOT
REPLACEMENT ITEM)
[10] SERVICE JIG (USE FOR
SERVICING)
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-40E67U/LC-40E77U
No. S39X4LC40E67U
