Chapter 1. Specifications; Specifications - Sharp LC-40E67U Service Manual

LC40E67U
CHAPTER 1.

SPECIFICATIONS

[1] SPECIFICATIONS
Item
LCD panel
Resolution
TV-standard (CCIR)
TV Receiving
Function Channel
Audio multiplex
Audio out
Rear
Terminals
Side
OSD language
Power Requirement
Power Consumption
Weight
*2
Dimension
(W g H g D)
Operating temperature
*1
Emergency alert messages via Cable are unreceivable.
*2
The dimensional drawings are shown on the inside back cover.
• As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units.
There may be some deviations from these values in individual units.
Model: LC-40E67U
40" Class (40" Diagonal)
Advanced Super View & BLACK TFT LCD
2,073,600 pixels (1,920 x 1,080)
American TV Standard ATSC/NTSC System
VHF/UHF VHF 2-13ch, UHF 14-69ch
CATV 1-135ch (non-scrambled channel only)
Digital Terrestrial
2-69ch
Broadcast (8VSB)
*1
Digital cable
1-135ch (non-scrambled channel only)
(64/256 QAM)
BTSC System
10W x 2
INPUT 1 COMPONENT in
INPUT 2 COMPONENT in, S-VIDEO in
INPUT 4 ANALOG RGB (PC) in (15-pin mini D-sub female connector), Audio in (Ø 3.5 mm jack)
INPUT 6 HDMI in with HDCP, Audio in (Ø 3.5 mm jack)
INPUT 7 HDMI in with HDCP
INPUT 8 HDMI in with HDCP
ANT/CABLE 75 Unbalance, F Type x 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)
AUDIO Audio in (Ø 3.5 mm jack)
DIGITAL AUDIO OUTPUT Optical Digital audio output x 1 (PCM/Dolby Digital)
OUTPUT Audio out
RS-232C 9-pin D-sub male connector
INPUT 3 AV in
INPUT 5 HDMI in with HDCP
SERVICE Software update
English/French/Spanish
AC 120 V, 60 Hz
210 W (0.5 W Standby with AC 120 V)
TV + stand 38.6 lbs./17.5 kg
TV only 32.0 lbs./14.5 kg
7
TV + stand 38 / g 27
8
7
TV only 38 / g 24
8
e 32°F to e 104°F (0°C to e 40°C)
Service Manual
1 13
/ g 12 / inch
16 16
11 7
/ g 4 / inch
32 32
1 – 1
LC-40E67U/LC-40E77U
Model: LC-40E77U
39.7 lbs./18.0 kg
33.1 lbs./15.0 kg
