Draytek Vigor3900 User Manual page 438

4 . 1 6 . 1 . 2 I P v 6 R o u t
4 . 1 6 . 1 . 2 I P v 6 R o u t
Display the information for each route with IPv6 protocol.
Each item will be explained as follows:
Item
Refresh
Search
Destination
Next Hop
Flags
i n g T a b l e
i n g T a b l e
Description
Renew the web page.
Move the mouse cursor onto the box of Search. Click the
mouse button and type the keyword inside the box. The
system will display the records relating to the keyword.
Display the destination IP address for various routings.
Display the next hop address for such route。
Display the flag of the routing entry. Possible flags include:
U (route is up)
H (target is a host)
G (use gateway)
R (reinstate route for dynamic routing)
D (dynamically installed by daemon or redirect)
M (modified from routing daemon or redirect)
A (installed by addrconf)
C (cache entry)
! (reject route)
430
Vigor3900 Series User's Guide
