Source IP Object
Source IP Group
Time Object
Time Group
Enable Smart
Bandwidth Limit
Session Threshold
TX Limit
RX Limit
Default TX/RX Limit
Apply
Cancel
profile.
Display the source IP object profile name.
Display the source IP group profile name.
If no time schedule is set, None will be shown in this field.
Display the Time group profile selected for such application
profile.
Check this radio button to configure the default limitation for
bandwidth for any LAN IP not included in the Limitation
List.
When session number exceeds the set threshold, Smart
Bandwidth limit will work.
Define the speed of the upstream for Smart Bandwidth
Limit. If you do not set the limit in this field, the system will
use the default speed for the data transmission.
Define the speed of the downstream for Smart Bandwidth
Limit. If you do not set the limit in this field, the system will
use the default speed for the data transmission
The default limit will apply to LAN IP(s) not in the above
configuration profiles
Default TX Limit – Define the limitation for the speed of
the upstream.
Default RX Limit –Define the limitation for the speed of the
downstream.
Click it to save and exit the dialog.
Click it to discard the settings configured in this page.
