1. Floppy drive door. Open this door to access the floppy disk drive.
2. Optical drive door. This door opens when you eject the loading tray.
3. Eject button. Press this button to eject the loading tray of the optical drive.
4. Second optical drive door. This door covers a second optical drive bay.
5. Power button (
6. Power LED (
7. HDD LED (
written to the hard disk drive
8. Front panel I/O door. Open this door to show the front panel input/
output ports.
Storage card reader door (Deluxe models only). Open this door to
9.
access the 6-in-1 storage card reader.
10. LED panel (Deluxe models only). The LED panel displays the audio
medium (CD/FM), radio frequency, player status ( / ), real time clock,
track number, and time. See page 21 for details.
The following front panel buttons are activated only when the system is
in Audio DJ mode. The Audio DJ feature allows you to play CD audio
tracks, or tune into an FM radio station without entering the operating
system. See page 59 for details. The audio control buttons are
available on Deluxe models only.
11. CD button ( ). Press this button to put the Audio DJ function to CD
mode.
In Windows
the system in sleep mode (S3) depending on the OS setting.
12. Mode button. Press this button to switch from CD to FM radio mode
or vice versa.
13. PLAY/PAUSE button ( / ). Press this button to perform various
functions in different modes.
In CD mode, plays or pauses an audio CD track.
In Radio mode, scans the available FM stations when pressed for
less than 2 seconds or presets a station when pressed for more than
2 seconds. Refer to page 60 on how to preset a radio station.
ASUS Terminator 2 barebone system
). Press this button to turn the system on.
). When lit, this LED indicates that the system is ON.
). This LED lights up when data is being read from or
®
mode, pressing this button shuts down, restarts, or puts
